User's
Command
Guide
Version 4.x
PN 613-10794-00 Rev B
Gigabit
Switches
AT-9108
AT-8518
AT-8525
AT-8550
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT-9108 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Allied Telesis AT-9108

Summary of Contents for Allied Telesis AT-9108

  • Page 1 Gigabit Switches ® AT-9108 AT-8518 AT-8525 AT-8550 User’s Command Guide Version 4.x PN 613-10794-00 Rev B...
  • Page 2 Copyright 1999 Allied Telesyn International, Corp. 960 Sewart Drive Suite B, Sunnyvale CA 94086 USA All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn International, Corp. CentreCom is a registered trademark of Allied Telesyn International, Corp. All other product names, company names, logos or other designations mentioned herein are trademarks or registered trademarks of their respective owners.

  • Page 3: General Switch Commands

    Gigabit Switch User’s Command Guide General Switch Commands Command Description clear counters Clears all switch statistics and port counters. config account <username> {encrypted} Configures a user account password. Passwords must have a {<password>} minimum of 4 characters and can have a maximum of 12 characters. User names and passwords are case-sensitive.
  • Page 4 General Switch Commands Command Description enable pace Enables recognition of the PACE bit. Available only in ingress mode. help Displays a command summary list. history Displays the previous 49 commands entered on the switch. ping {continuous} {size <n>} [<ip_address> | Sends ICMP echo messages to a remote IP device.
  • Page 5 AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide Network Management and SNMP Commands Command Description clear session <number> Terminates a Telnet session from the switch. config snmp add <ipaddress> {<mask>} Adds the IP address of an SNMP management station to the access list.
  • Page 6 Network Management and SNMP Commands Command Description show management Displays network management configuration and statistics, including enable/disable states for Telnet and SNMP, SNMP community strings, authorized SNMP station list, SNMP trap receiver list, and login statistics. show session Displays the currently active Telnet, console, and Web sessions communicating with the switch.

  • Page 7: Vlan Commands

    AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide VLAN Commands Command Description config dot1p ethertype <ethertype> Configures an IEEE 802.1Q Ethertype. Use this command only if you have another switch that supports 802.1Q, but uses a different Ethertype value than 8100.
  • Page 8 VLAN Commands Command Description enable ignore-stp vlan <name> Enables a VLAN from using STP port information. When enabled, all virtual ports associated with the VLAN are in STP forwarding mode. The default setting is disabled. show gvrp Displays the current configuration and status of GVRP. show protocol {<protocol_name>...

  • Page 9: Fdb Commands

    AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide FDB Commands Command Description clear fdb {<mac_address> | vlan <name> | Clears dynamic FDB entries that match the filter. When no options <portlist>} are specified, the command clears all FDB entries. config fdb agingtime <number>...

  • Page 10: Port Commands

    Port Commands Port Commands Command Description config mirroring add [mac <mac_address> | Adds a single mirroring filter definition. Up to eight mirroring vlan <name> | port <port> | vlan <name> port definitions can be added. You can mirror traffic from a MAC address, <portlist>] a VLAN, a physical port, or a specific VLAN/port combination.
  • Page 11 AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide Command Description show ports {<portlist>} qosmonitor Displays real-time QoS statistics. show ports {<portlist>} rxerrors Displays real-time receive error statistics. show ports {<portlist>} stats Displays real-time port statistics. show ports {<portlist>} txerrors Displays real-time transmit error statistics.

  • Page 12: Syslog Commands

    Syslog Commands Syslog Commands Command Description clear log {static} Clears the log. If static is specified, the critical log messages are also cleared. config log display {<priority>} Configures the real-time log display. Options include: priority — Filters the log to display messages with the selected priority or higher (more critical).

  • Page 13: Stp Commands

    AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide STP Commands Command Description config stpd <stpd_name> add vlan <name> Adds a VLAN to the STPD. config stpd <stpd_name> hellotime <value> Specifies the time delay (in seconds) between the transmission of BPDUs from this STPD when it is the Root Bridge.
  • Page 14 STP Commands Command Description unconfig stpd {<stpd_name>} Restores default STP values to a particular STPD or to all STPDs.

  • Page 15: Qos Commands

    AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide QoS Commands Command Description config ipqos [add | delete] Adds or deletes a QoS profile (short form). <dest_ipaddress>/<mask_length> [qosprofile <qosname> | blackhole] config ipqos [add | delete] [tcp | udp | other | Adds or deletes a QoS profile (long form).

  • Page 16: Access Policy Commands

    Access Policy Commands Access Policy Commands Command Description config access-profile <access_profile> add Adds an IP address or VLAN name to the access profile. The entry {vlan <name> | ipaddress <ipaddress> must be of the same type as the access profile (for example, IP <subnet_mask>...

  • Page 17: Basic Ip Commands

    AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide Basic IP Commands Command Description config dns-client add <ipaddress> Adds a DNS name server(s) to the available server list for the DNS client. Up to three name servers can be configured. config dns-client default-domain Configures the domain that the DNS client uses if a fully qualified <domain_name>...
  • Page 18 Basic IP Commands Command Description show ipstats {vlan <name>} Displays IP statistics for the CPU of the system. show dns-client Displays the DNS configuration. show sntp-client Displays configuration and statistics associated with SNTP.
  • Page 19 AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide BootP, DHCP Proxy, and UDP Profile Commands Command Description config bootprelay add <ipaddress> Adds the IP destination address to forward BOOTP packets. config bootprelay delete [<ipaddress> | all] Removes one or all IP destination addresses for forwarding BOOTP packets.

  • Page 20: Ip Arp Commands

    IP ARP Commands IP ARP Commands Command Description config iparp add <ipaddress> <mac_address> Adds a permanent entry to the ARP table. Specify the IP address and MAC address of the entry. config iparp delete <ipaddress> Deletes an entry from the ARP table. Specify the IP address of the entry.

  • Page 21: Ip Route Commands

    AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide IP Route Commands Command Description config iproute add <ipaddress> <mask> Adds a static address to the routing table. Use a value of <gateway> <metric> 255.255.255.255 for mask to indicate a host entry config iproute add blackhole <ipaddress>...

  • Page 22: Icmp Commands

    ICMP Commands ICMP Commands Command Description config irdp <mininterval> <maxinterval> Configures the router advertisement message timers, using seconds. <lifetime> <preference> Specify: mininterval — The minimum amount of time between router advertisements. The default setting is 450 seconds. maxinterval — The maximum time between router advertisements.
  • Page 23 AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide IP RIP Commands Command Description config rip add vlan [<name> | all] Configures RIP on an IP interface. If no VLAN is specified, then all is assumed. When an IP interface is created, per-interface RIP configuration is disabled by default.
  • Page 24 IP RIP Commands Command Description show rip stat {vlan <name>} Displays RIP-specific statistics for one or all VLANs. unconfig rip {vlan <name>} Resets all RIP parameters to match the default VLAN. Does not change the enable/disable state of the RIP settings. If no VLAN is specified, all VLANs are reset.
  • Page 25 AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide IP OSPF Commands Command Description config ospf add virtual-link <routerid> Adds a virtual link connected to another ABR. Specify the following: <areaid> routerid — Far-end router interface number. areaid — Transit area used for connecting the two end- points.
  • Page 26 IP OSPF Commands Command Description config ospf spf-hold-time {<seconds>} Configures the minimum number of seconds between Shortest Path First (SPF) recalculations. The default setting is 3 seconds. config ospf spf-hold-time {<seconds>} Configures the minimum number of seconds between Shortest Path First recalculations.
  • Page 27 AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide Command Description delete ospf area [<areaid> | all] Deletes and OSPF area. Once an OSPF area is removed, the associated OSPF area and OSPF interface information is removed. disable ospf Disables OSPF.

  • Page 28: Ip Multicast Commands

    IP Multicast Commands IP Multicast Commands Command Description clear igmp snooping {vlan <name>} Removes one or all IGMP snooping entries. clear ipmc cache {<group> {<src_ipaddress> Resets the IP multicast cache table. If no options are specified, all IP <mask>}} multicast cache entries are flushed. config igmp <query_interval>...
  • Page 29 AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide Command Description unconfig igmp Resets all IGMP settings to their default values and clears the IGMP group table.

  • Page 30: Dvmrp Commands

    DVMRP Commands DVMRP Commands Command Description config dvmrp add vlan [<name> | all] Enables DVMRP one or all IP interfaces. If no VLAN is specified, DVMRP is enabled on all IP interfaces. When an IP interface is created, DVMRP is disabled by default. config dvmrp delete vlan [<name>...

  • Page 31: Pim-Dm Commands

    AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide PIM-DM Commands Command Description config pim-dm add vlan [<name> | all] Enables PIM-DM on an IP interface. When an IP interface is created, per-interface PIM-DM configuration is disabled by default. config pim-dm delete vlan [<name> | all] Disables PIM-DM on an interface.

  • Page 32: Ipx Commands

    IPX Commands IPX Commands Command Description config ipxmaxhops <number> Configures the IPX maximum hop count when forwarding IPX packets. The default setting is 16. Change this only if NetWare Lin Services Protocol (NLSP) is running in the IPX network. config ipxroute add [<dest_netid> | default] Adds a static IPX route entry in the IPX route table.
  • Page 33 AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide IPX/RIP Commands Command Description config ipxrip add vlan [<name> | all} Configures one or all IPX VLANs to run IPX/RIP. IPX/RIP is enabled by default when you configure the IPX VLAN. config ipxrip delete vlan [<name> | all] Disables IPX/RIP on one or all interfaces.
  • Page 34 IPX/SAP Commands IPX/SAP Commands Command Description config ipxsap add vlan [<name> | all] Configures an IPX VLAN to run IPX/SAP routing. If no VLAN is specified, all VLANs are configured to run IPX/SAP routing. IPX/SAP routing is enabled by default when the IPX VLAN is configured. config ipxsap delete vlan [<name>...
  • Page 35 AT-9108, AT-8518, AT-8525, and AT-8550 User’s Command Guide Configuration and Image Commands Command Description download bootrom <ipaddress> <filename> Downloads a BOOT ROM image from a TFTP server. The downloaded image replaces the BOOT ROM in the onboard FLASH memory. Note: If this command does not complete successfully it could prevent the switch from booting.
