Installing Firmware On Printer; Adding The Second Material Bay - Stratasys uPrint User Manual

d. Enter the IP Address for your printer in the appropriate field. It will
be the same address as entered in step 6.
e. Select your printer type from the drop down list, either uPrint or
uPrint Plus.
Note:
list.
f. Click Add Printer and close the Add 3D Printer window.
3. If you are unable to connect the printer to your workstation, contact your Network
Administrator.

Installing Firmware on printer

1. From the display panel, press Maintenance.
2. Press System.
3. Press Load Upgrade. "Send upgrade from workstation" and the printer IP address will be
displayed.
4. From your workstation, open the CatalystEX by double clicking on the CatalystEX icon.
5. Click the Printer Services tab.
6. Select your printer from the drop down list then click the Update Software button.
7. Navigate CatalystEX to the directory where the firmware file is located and select the
uPrint.upg file for uPrint or select the uPrintPlus.upg file for uPrint Plus. Firmware will now begin
to download to the printer.
Note:
8. When firmware verification is complete, the printer display will show Reboot to complete
upgrade? Press Yes. The printer will then load the firmware then reboot and return to Idle.
Note:

Adding the second Material Bay

You have the option of adding a second material bay to extend printing times without having to
reload material while the model is printing.
Installing the uPrint Material Bay:
1. Remove the uPrint Material Bay, material bay cable, material spools and material carriers from
the box.
2. Unload the model and support material from the printer.
3. Open the material bay doors by gently pressing in to release and pulling outwards.
14
If you only have one printer connected, it will be the only printer in the
Default uPrint firmware location for 32 bit systems:
C:\Program Files\Dimension\uPrint <version>
Default uPrint firmware location for 64 bit systems:
C:\Program Files (x86)\Dimension\uPrint <version>
Default uPrint Plus firmware location for 32 bit systems:
C:\Program Files\Dimension\uPrint Plus <version>
Default uPrint Plus firmware location for 64 bit systems:
C:\Program Files (x86)\Dimension\uPrint Plus <version>
Loading firmware will take approximately 10 minutes.
