APPeNDIX g - Fibre modules and cables

To suit your installation layout, two fibre modules are available for the ALIF dual units
to suit various fibre optic cables. The specifications for all are summarized in the table
below:
Fibre Type Fibre size Fibre Type
OM1 (62.5/125) Multimode
(TIA-492AAAA)
OM2 (50/125) Multimode
(TIA-492AAAB)
OM3 (50/125) Multimode
(850 nm Laser-optimized)
(TIA-492AAAC)
OM4 (50/125) Multimode
(850 nm Laser-optimized)
(TIA-492AAAC)
OS1 and OS2 (9/125) Single-mode
(TIA-492C000 / TIA-492E000)
Coding
Normal Military
Applications Applications
Orange Slate
Orange Orange
Aqua Undefined
Aqua Undefined
Yellow Yellow
Distance
at
Suggested Print 1Gbps
Nomenclature
62.5/125 220m
50/125 550m
850 LO 50 /125 550m
850 LO 50 /125 550m
SM/NZDS, SM 10Km
Adder part Bar Conn.
number for color type
SFP module
SFP-MM-LC Black LC
" " "
" " "
" " "
SFP-SM-LC Blue LC
