Appendix A HDD Capacity Calculation
Calculate total capacity needed by each DVR according to video recording (video recording type
and video file storage time).
Step 1: According to Formula (1) to calculate storage capacity
channel needed for every hour, unit Mbyte.
Step 2: After video time requirement is confirmed, according to Formula (2) to calculate the
storage capacity
, which is storage of each channel needed unit Mbyte.
m
i
Step 3: According to Formula (3) to calculate total capacity (accumulation)
all channels in the DVR during scheduled video recording.
Step 4: According to Formula (4) to calculate total capacity (accumulation)
all channels in DVR during alarm video recording (including motion detection).
