7 Input
Keys
8 Control
Keys
LJD Digital Security Ltd
Copyright © 2005. All rights reserved.
User Manual for COLOSSUS Series Embedded Net DVR
REC
2. 【AUTO】in PTZ mode.
EDIT 1. Manual record;
2. 【SHOT】in PTZ mode (adjust preset).
PTZ 1. In edit state, delete current cursor character;
2. 【IRIS+】 in PTZ control;
A
1. Select
1. Enter into PTZ control mode;
PREV
2. 【IRIS-】in PTZ control.
1. Input switch (number, lower case, upper case and
INFO symbol);
VOIP
2. 【FOCUS+】in PTZ control;
3. In preview mode, display or hide the channel status bar.
1. Multi screen preview switch;
2. Switch menu mode into preview;
3. 【FOCUS-】in PTZ control.
【ZOOM+】in PTZ control.
【ZOOM-】in PTZ control.
Numeric Input number, lower case, upper case character and symbols.
Keys
F1
【LIGHT】in PTZ control.
F2
【AUX】in PTZ control.
Direction
Composed of 【 】,【 】,【 】and【 】.
Keys
1. Menu mode, use【 】/【 】 to select 【 】/【 】 to
edit;
ENTER 2. PTZ direction control;
3. Playback speed control.
1. Menu confirmation;
2. Select
or × to enable or disable.
or × to enable or disable;
Page
