Page 1: User Manual
Thank you for purchasing our embedded Net DVR. Please read this User Manual carefully to ensure that you can use the device correctly and safely. The contents of this Manual are subject to change without notice. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 2: Table Of Contents
OSD Setup.......................49 Video Parameters Setup ..................53 Mask Area Setup .....................55 View Tampering Alarm ...................58 Video Loss Alarm....................60 5.10 Motion Detection Alarm ..................62 5.11 Preview Properties ....................67 5.12 Recording Setup ......................69 Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 3 UTP network connect cable made method..............97 RS-232 connect cable made method ................98 Appendix C Specifications ......................101 Appendix D Quick Search Function Table ................103 Appendix E Troubleshooting ....................105 Appendix F Product Service .....................107 Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 4: Version Description
4. Http port can be modified. Please refer to “Network” menu of DVR. 5. Old version firmware can only setup one private mask area. Version1.4 firmware can support setup 4 different private mask areas. Please refer to chapter 5.7. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 5: Chapter1 Product Introduction
Compressed video and audio are synchronous. You can select either mixed stream or only video stream. Support2CIF in Realtime. 2CIF is 704x288 Support multi area motion detection. Support OSD and changeable OSD position. Support LOGO and changeable LOGO position. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 6 Support TCP, UDP, RTP, and Multicast for network preview. Support PPPoE for board band dialup. Support remote parameters setup. Alarm information can be sent to remote center. Network control PTZ. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 7 Network download and playback the recorded files in DVR. Remote upgrade the firmware. Supprot bi-direction voice talk or one-way voice broadcast. Support IE to preview and config DVR. Support log. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 8: Chapter2 Installation
HDD and slaver HDD. 7. Plug the HDD power connector. 8. Cover and fix the DVR box. Note: After you install the HDD, you must format them. Please refer to section 6.4. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 9: Rear Panel Description
Connect network devices. Refer to Appendix B for pin UTP Network Interface definition. 8/16 Alarm in. External Alarm Input 4 Alarm out Relay Output Use switch to change AC voltage 220/110V. AC Input Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 10: External Alarm In/Out Connection
If you use AC, please open the jumper. There are 4 jumpers (JJ1, JJ2, JJ3 and JJ4) in DVR main board, corresponding with 4 alarm output. The default is closed. Warning: If you use AC input for relay output, please open the jumpers. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 11: Chapter3 Operational Instructions
Twinkle in green means data is being transmitted. Compound MENU 1. Switch preview mode into menu; Keys 2. Brush control short key【WIPER】. PLAY Cancel and back to parent menu. 1. Local playback; Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 12 1. Menu mode, use【】/【】 to select 【】/【】 to edit; ENTER 2. PTZ direction control; 3. Playback speed control. 1. Menu confirmation; or × to enable or disable; 2. Select Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 14: Ir Controller
Same as MENU key of front panel. PREV Same as PREV key of front panel. Direction Keys Same as direction keys and enter key ENTER of front panel. Same PTZ key of front panel. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 15 Check the remaining charge in the batteries. Check IR controller sensor is mask. Please change another IR controller to try again. It the problem is still existed, please contact administrator. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 16: Menu Description
RS232 parameters RS232 Sequence setup Cruise setup Preview mode Add or delete user User Switch time Password setup or modification Preview Password Enable/Disable audio preview User rights setup Preview layout Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 17 User Manual for COLOSSUS Series Embedded Net DVR Restore parameters Upgrade firmware HDD management Shut down DVR Clear alarm output PowerOff Utilities Reboot Power off View log System information Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 18: Menu Operation
【】 or 【】 key. When the “Active Frame” is located on one icon, you can press 【ENTER】key to enter into the secondary menu. For example, move the “Active Frame” to “Image” icon, press 【ENTER】to enter into the secondary menu as following: Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 19 Button: Excute a special function or enter into next sub-menu. For example, press “Policy” button to enter into sub-menu. Press【Confirm】to save parameters and return to parent menu. Press 【 Cancel】 button to cancel and return to parent menu. The button in Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 20 User Manual for COLOSSUS Series Embedded Net DVR grey means it can be operated only after it is enabled. How to exit menu Press【PREV】key to exit menu and return to preview mode. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 21: Character Input
Press 【A】 key to change input methods. You can select “number”, “Uppercase”, “Lowercase” or “Symbol”. Uppercase Lowercase Symbol There are 24 symbols in all. They are divided into 4 pages, and you can use【0】key to turn over page. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 22: Chapter4 Basic Operation Guide
HDD is not installed or not detected. If HDD is not detected, please contact administrator. Note: If HDD is not installed or not detected, DVR can beep for alarm. You can enable the alarm option in “Exceptions” menu. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 23: Preview
Record status of camera is as follows: Icon Icon Color Status Description White No video signal Yellow Vdieo input Pink Manual recording Green Real time recording Blue Motion detect recording External alarm recording Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 24 2 camera; and press 【1】【2】keys to preview 12 camera. Press【EDIT】key to manual cycle preview. You can set the auto preview mode in “Preview” menu, referring to 5.11. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 26: User Name And Password
For those users created by admin, they can modify their password as following: Step1: Enter into main menu Press 【 MENU】 key, in the login dialog, select your user name, input the correct password, you can enter into the main menu. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 27 “Verify” item to input the verify password. Note: In edit box, use 【】 / 【】 to move cursor and 【EDIT】 key to delete the numeral in front of the cursor. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 28: Ptz Control
DVR has 10 or more than 10 channels, you must press two numeric keys to select. For 【 0】【2】【 1】【2】 example, press to select 2 camera PTZ, and press to select 12 camera PTZ. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 29 When PTZ is in auto mode, if you exit PTZ control mode, PTZ will continue auto function.You must enter into PTZ control mode again, and press【PLAY/AUTO】key to stop. Exit PTZ contrl mode Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 31: Manual Record
Start/Stop: “ ” means you can start corresponding channl recording. “×” menas you can stop recording. Start All: Press this button to start all channels recording. Stop All: Press this button to stop all channel recording. Exit manual record Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 32: Playback
In preview mode, press【PLAY】key, in the pop-up login dialog, select username and input correct password, you can enter into “Playback” interface. In menu mode, press【PLAY】key, you can enter into “Playback” interface directly. One Channel Playback Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 33 When the cursor is at the postion of any time items, only press 【Enter】 , DVR will search and list the matched recorded files. Play from Time: Playback the recorded stream directly based on the time section. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 34 【↓】keys to select page). In the file list box, use【↑】【↓】keys to move the scroll bar to the file, press【ENTER】key to playback the file. If the second channel is selected, these two Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 35 Two Channels Playback At the bottom of image, there is an information bar and the following information is included: Volume, Play Progress, Play Speed, Played Time and File Total Time. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 36 In playback interface, press【ESC】key to enter into preview mode. In playback interface, press 【MENU】 key to enter into main menu, press 【REC】 key to enter into manual record, and press【PTZ】key to enter into PTZ control mode. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 37: Backup Recorded Files
In the playback interface, select one channel and record type, input the time section, move “Active Frame” to any time items, press 【 ENTER】 key, DVR will start to find and list the matched files. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 38 After you select all segments, press【ESC】key, a message window will pop-up. If you press “Confirm” button, DVR will start to backup the selected segments. If you press “Cancel” button, DVR will abort backup. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 39: Voice Talk
In the main menu, move “Active Frame” to “Power Off” item and press【Enter】key or enter into “Utilities” menu, move “Active Frame” to “Power Off” item and enter into power off dialog, press “Confirm” to shut down the DVR. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 40 Please avoid taking away the power cable directly. Note: In some cases, when the power supply is abnormal, DVR will be damaged. We suggest you to use those stable power supply. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 41: Chapter5 Parameters Setup Guide
Press【MENU】key, in the login dialog, select the username as “admin”, use【→】key, move cursor to password edit box, input “12345”, press “Confirm” to enter into administrator menu. Move “Active Frame” to “User” icon, press【ENTER】key to enter into “User Management” Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 42 If password and verify password are not same, a warning message box will be appeared. In this case, press【ENTER】to return password edit box, and input new password again. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 43: Add And Delete User
Step 3: Setup the password for new user After you add one new user, the password is null. You can skip this step if you do not want to change the password. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 44 In the “User Management” menu, press “Confirm” button, the user’s password and rights will be saved and return main menu. If you press “Cancel” button, the user’s password and rights will be aborted. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 45 “Active Frame” to “Del” button, press【ENTER】, in the pop-up confirmation dialog, press “Confirm” button to delete the selected user and return. Press “Cancel” or 【 ESC】 to abort deleting. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 47: Unit Name And Device Id
ID. The device ID value is ranged among 01-100. After you finish the modification, press “Confirm” button to save and take effect or press “Cancel” to abort modification. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 48: Video Output Standard And Vga Setup
You can define VGA resolution, refresh frequency in “Display” menu. There are following options: 1024*768/60Hz, 800*600/60Hz and 800*600/75Hz. You can use【】【】key to select. Press “Confirm” button to save or “Cancel” to abort. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 49: Osd Setup
You can setup display properties for each camera, including display status, position and format. Of course, you can copy the properties of one camera to all cameras. In “Image Setup” menu as following, select one camera: Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 50 After you save the modification, you can find the modification will be taken into effective. You can perss “Cancel” button or【ESC】key to abort. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 51 The disable flag is “×”. If you enable the check box, you can setup the camera name position. You can copy the position to any other camera. The setup stpes are: Step 1: Enter into “Image Setup” menu. Step 2: Select one camera. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 52 “Image Setup” menu, and press “Confirm” button to save it. In the “Image Setup” menu, perss “Cancel” button or【ESC】key, you can abort the modification. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 53: Video Parameters Setup
Step 4: You can copy the video parameters of current camera to any other cameras. Or you can repeat setp2 and step3 to adjust for any other camera. After adjust, in “Image Setup” menu, press “Confirm” button to save parameters and make Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 54 User Manual for COLOSSUS Series Embedded Net DVR them into effective. Otherwise, perss “Cancel” button or【ESC】key to abort modification. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 55: Mask Area Setup
Step 2: Select one camera: You can use【】【】keys to select one camera. Step 3: Enter into advanced settings: Move “Active Frame” to “Advanced settings” item and press【Enter】to enter into advanced settings interface. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 56 Step 6: Save mask area: You can repeat step2, step3 and step4 to setup mask area for other cameras. In “Image Setup” menu, press “Confirm” button to save the mask area, press “Cancel” bbutton to abort. Here is the example for mask area function. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 58: View Tampering Alarm
Step 2: Select camera: Please use【】【】keys to select one camera. Step 3: Enter into advanced settings: Move “Active Frame” to “Advanced settings” item and press【Enter】to enter into advanced settings interface. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 59 Warning”, “Audible Warning”, “Upload to Center” and “Trigger Alarm Output”. You can use 【↑】【↓】and 【EDIT】key to enable or disable them. “×” is disable and “ ” is enable. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 60: Video Loss Alarm
Step 2: Select camera: Use【】【】keys to select one camera. Step 3: Enter into advanced settings: Move “Active Frame” to “Advanced settings” item and press【Enter】to enter into advanced settings interface. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 61 Screen Warning”, “Audible Warning”, “Upload to Center” and “Trigger Alarm Output”. You can use 【↑】【↓】and 【EDIT】key to enable or disable them. “×” is disable and “ ” is enable. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 62: Motion Detection Alarm
“Motion Area Setup” button and “Policy Setup” button. If you select low sensitivity such as 0, only when there are great motion detection, DVR can response. On the other side, for high sensitivity such as 5, DVR will response with small motion detection. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 63 Clear all motion areas: Press【A】key to clear all motion areas of this channel. The kyes used to setup motion areas are following: 【↑】【↓】【←】【→】: Move yellow panel to any position; Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 64 The motion detection area is displayed as following: Step 5: Motion alarm policy: Move “Active Frame” to the corresponding “Policy” button of motion detection alarm, press【ENTER】key to enter into “Motiomn Alarm Handle” menu: Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 65 Step 10: Save all cameras: You can repeat from step2 to step8 to setup motion detection parameters for other cameras. Also you can copy the parameters of one camera to any other cameras. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 66 Note: Motion alarm area can not be copied. If you want to disable motion alarm area and motion alarm policy, you just need to select the motion alarm sensitivity as “Off”. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 67: Preview Properties
Audio preview: If you enable audio preview (“ ”), when you preview single camera, DVR will play the audio of that channel. Preview layout setup: There is a square frame divided into many windows. If you select “4 Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 68 After you define the camera perview order, you can select preview mode to meet your demand. Save setup: Press “Confirm” button to save preview properties. Press “Cancel” or 【ESC】 key to abort. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 69: Recording Setup
DVR will handle it as “Hard Disk Full” exception, please refer to chapter 5.17 for exception menu. Select Camera: Here all channels are listed. You can use【↑】【↓】keys to select one. Advanced settings: Enter into “Recording advanced settings” menu. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 70 768K-2Mbps. Of course, you will select the proper max bit rate based on the camera, background and image quality requirement. Bit rate: You can select bit rate size for fixed bit rate type. It is the same as “Max Bit Rate”. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 71 All day recording setup: Step 1: Enter into recording schedule menu In recording menu, use【ENTER】or【EDIT】key to enable record function (“ ” flag), press “Schedule” button to enter into recording schedule menu. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 72 None all day recording setup Step 1: Enter into recording schedule menu In recording menu, use【ENTER】or【EDIT】key to enable record function (“ ” flag), press “Schedule” button to enter into recording schedule menu. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 73 If record type is “Alarm” or other related types, you must setup “Alarms” in order to trigger alarm recording (refer to chapter 5.13). The time period is among 00:00—24:00. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 74: External Alarm Input And Relay Output
“Handle” option, you can active “Policy” and “PTZ Linkage” buttons on right side. Move “Active Frame” to “Policy” button and press【ENTER】key, you will enter into “Alarm in Handling” sub menu: Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 75 “Alarms” menu. In “Alarms” menu, press “Confirm” button to save the parameters. Step 8: PTZ Linkage Move “Active Frame” to “PTZ Linkage” button, press【ENTER】key to enter into “PTZ Linkage” setup menu: Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 76 “Clear Alarm” button in “Utilities” menu. So the actual alarm output time is made up of alarm input time and this delay time. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 77 Step 6: Save setup When you finish setup, in “Alarms” menu, press “Confirm” button to save all parameters. Note: If any schedule is modified, you must reboot DVR to make it into effective. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 78: Network Parameters
Gateway: The gateway IP is used to communicate in different network segments DNS address: If DVR uses PPPoE function, and get one dynamic IP address. If you set DNS Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 79 HttpPort: The port is for IE browser. The default value is 80. It can be modified. PPPoE: DVR support PPPoE dail-up function. Example: Use PPPoE function Step 1: Enter into “Network” menu. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 80 DVR to make parameters into effect. In reboot process, DVR will start dialup using PPPoE function. If DVR dialup internet successfully, DVR will display the dynamic internet IP address in “Network” menu. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 81: Ptz
Move “Active Frame” to “Setup” button on the right side of “Preset” item, press【ENTER】 key to enter into preset setup menu. You can save 128 preset number. Please make sure the PTZ Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 82 Delete preset number: In “Preset” setup menu, input one preset number, press “Delete” button, you can delete this preset number. After deleting, press “Return” button to “PTZ” menu. In “PTZ” menu, press “Confirm” button to save all modification. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 83 Please make sure the PTZ you are using can support sequence function. Cruise setup In “PTZ” menu, press “Setup” button on the right side of “Cruise” item, you can enter into “Cruise” setup menu: Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 84 Press “Return” button back to “PTZ” menu. In “PTZ” menu, press “Confirm” button to save this cruise. Please make sure the PTZ you are using can support cruise function. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 85: Rs232 Setup
RS-232 parameters: Including baud rate, data bit, stop bit, parity, flow control, etc. Work mode: The RS-232 can be used as “Console”. Console: Connect with PC serial port. You can use HyperTerminal or NetTerm to control it. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 86: Exceptions
Trigger Alarm Output: trigger local relay output. You can select more than one handle methods. After you finish setup, press “Confirm” button to save parameters. Press “Cancel” button or 【ESC】key to abort. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 87: Chapter6 Utilities
Save factory default parameters into FLASH memory. You can reboot DVR to make them into effective. Restore Parameters Restore factory parameters for DVR. The IP address, gateway and port number will not be restored. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 88: Upgrade
If you select “USB” mode, please make sure you connect one USB flash memory with DVR and the firmware file is in its root directory. Reboot after successfully upgrading, the system will use the new firmware. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 89: Hard Disk Management
Reboot Reboot DVR. Power Off Shut down DVR. View Log To view the log recorded in DVR HDD. In “Utilities” menu, press “View Log” to enter into “Log” menu: Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 90 All, External Alarm In, External Alarm Out, Motion Detect Start, Motion Detect Stop, View Tamper Start, View Tamper Stop . Step 3: Move “Active Frame” to “Search Log” button, press 【 ENTER】 key to start searching. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 91 Step 4: Move “Active Frame” to “Search Log” button and press【ENTER】key to start searching. Step 5: After finish searching, DVR will list the matched log information. Step 6: Press “Return” button back to “Utilities” menu. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 92: System Information
User Manual for COLOSSUS Series Embedded Net DVR System Information Press “System Info” icon in “Utilities” menu, you can get DVR system information: Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 93: Chapter7 Firmware Upgrade
Create new user. Click “new user’. New user dialog pops up. Input user name “target”. Click “OK”. In the password dialog, input password “target” in “New Password” and “Verify Password” edit box. Click “OK” to save and exit the dialog box. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 94: Upgrade Mode
Please input [u/U] or [ESC] key Release "ctrl" and "u" keys. Step 4: Press “u” key. In the message line of “IP address of NET DVR”, input any one Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 95 FTP server, and download the firmware file (digicap) through network. Please make sure FTP server and firmware file are setup and run correctly. After upgrade finished, press any key to reboot DVR. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 96: Appendix Ahdd Capacity Calculation
Step 4: According to Formula (4) to calculate total capacity (accumulation) that is needed for all channels in DVR during alarm video recording (including motion detection). ∑ ×a% In the formula：a% means alarm occurrence rate Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 97: Appendix Bdvr Connect Cable Definition
100m), 2 standard RJ45 head, one tool for RJ45. Suggestion: have a network cable test tool to test each cable made. Pin definition To make the network cable according to the actual situation, there are two options: Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 98: Connect Cable Made Method
The corresponding relationship of cross cable 3 RS-232 connect cable made method Material and tool One twisted cable (8 pins), one standard RJ45 head, one or more DB25 or DB9 plug-in, a Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 99 Connection for RJ45 and DB25 (DTE) (2) When the serial port of the DVR is connected with DTE device with DB9 plug-in, the corresponding relationship is as follows: Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 100 (3) When the serial port of DVR is connected with DCE device (like MODEM), one end of the cable is 8-pin RJ45 plug-in, the other end is DB25 pin plug-in, the corresponding relationship is as following: Connection for RJ45 and DB25 (DCE) Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 101: Appendix C Specifications
IDE interface 2000GB USB interface 1 USB interface, USB1.1, can support USB flash memory, USB HDD and USB CR-R/W VGA interface 1 VGA interface, support resolution: 800×600/60Hz, 800×600/75Hz, 1024×768/60Hz Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 102 4/8/16 Relay output Power supply 90--135VAC or 180--265VAC, 47--63 HZ Power 20－42W (without HDD) consumption Working -10℃--＋55℃ temperature Working 10％--90％ humidity Size 19” Standard (450mm*450mm*95mm) ≤8Kg (without HDD) Weight Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 103: Appendix D Quick Search Function Table
TCP, UDP, RTP, Multicast. Control Control DVR through network. Alarm Send alarm information to host PC through network. 5.14 PTZ control Remote control PTZ. Remote setup Remote setup DVR parameters. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 104 Remote upgrade firmware. upgrade Using IE to access DVR OSD setup LOGO Logo setup Utilities View log View log Voice talk Two way voice talk or one way voice broadcast Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 105: Appendix E Troubleshooting
RS-485 cable connected correctly broken. PTZ parameters error. RS-485 port of DVR is broken. Client software can not view DVR live image. Network is error. Connect wrong DVR (wrong Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 106 If the circuit board is wet, dust on circuit board can cause a short circuit. The circuit board, plug and socket, housing fan and housing should be cleaned by brushing regularly. Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
Page 107: Appendix F Product Service
Cut off User’s Information Card and fax or post it to us after the card is filled in. Address: Post Code: Fax: Page LJD Digital Security Ltd Copyright © 2005. All rights reserved.
