Abit IT5E Series User Manual page 70

A-4
H/W Reset connector:
pins 1 and 2. Insert the two-threads hardware reset connector into the
correct pins of connector PN2 on the mainboard.
Pin number
1
2
Installing speaker connector:
orientation for pin 4 to pin 7. Connect the four-threads speaker cable to
the correct pins of connector PN2 on the mainboard
Pin number
4
5
6
7
Installing Turbo LED connector:
orientation for pins 9 and 10. Connect the two-threads connector to the
correct pins of connector PN2 on the mainboard.
Pin number
9
10
PN2 - There is no specific orientation for
Name of the signal or signification
Ground
Hardware Reset Signal
Name of the signal or signification
+5VDC
Ground
Ground
Sound Signal
Name of the signal or signification
Anode terminal of Turbo LED
Cathode terminal of Turbo LED
PN2 - There is no specific
.
PN2 - There is not specific
Appendix A
