PN2 - Turbo switch LED connector
This connector has a specific orientation.
switch LED plug to the PN2 connector pins on the mainboard.
Pin number
9
10
Computer
knowledge
JS1 - Power Control connector
This has a specific orientation. The present power supply units of AT
computer do not support this feature, so you can ignore this connector. If
your power supply unit features this connector, insert plug JS1, but be sure
that the signification of the signal cable is the same, and be sure to use this
feature in connection with the Standby connector on connector PN1.
Pin number
1
2
3
Name or significance of signal
Anode terminal of Turbo LED
Cathode terminal of Turbo LED
The "hardware Turbo LED" indicates the status of
hardware operating speed.
Name of the signal or signification
Power supply control signal <PS_ON>
Standby power supply <+5VSB>
Ground
Connect the two-thread turbo
