Installing the Mainboard

(3) Presentation and Installation of the CPU

Jumperless MainBoard (Mainboard with no DIP Switch or Jumper)
This mainboard series can be installed with CPU without the hardware
setting of the CPU.
On other boards, when you want to install the CPU, you have, more or
less, to setup some jumpers or DIP switches. With this mainboard, you will
not need to adjust any jumper or switch. The CPU speed and model is set
up by software, in order to allow the user to complete setup and installation
procedures easily. After you have inserted the CPU on the CPU socket, you
can close the computer case and turn the computer on. You just need to
enter the CPU SOFT MENU™ located in the BIOS Setup, and to setup the
speed and the voltage of the CPU to compete the installation. Even if you
don' t need to setup any switch, we recommend you to read our presentation
of the CPUs, it will be useful information for you.
Since 1996, every two or three months, Intel adds new models to the
Pentium CPU series. That is why the CPU market is filled with a lot of
different models and brands. All CPUs have different electrical
specifications. That' s why installing a CPU is becoming more and more
complex. You can' t help that, because everybody wants to be able to
upgrade its hardware. So, you have to take a bit of time to read this section,
in order to be able to install a cheaper and better processor.
This mainboard does not only support all the CPUs listed in the
specifications, but also has reserved several circuits in order to be able to
support future processors. But before we go further in our presentation, we
must clarify that "we have only tested the CPUs listed in Chapter 1", we
cannot guarantee that this board will be able to support future products,
because we cannot forecast future developments. But we will do our best
to support any possible CPU.
Related terminology :
External clock
Also referred to as the external CPU clock, or "Bus clock", it is the
input clock of the CPU. For instance, Intel Pentium P90, P120 and
P150 all have a 60MHz external CPU clock, but have different internal
clock multiplier factors.
Clock multiplier factor
2-11
