Abit IT5E Series User Manual page 17

Installing the Mainboard
There is no specific orientation.
suspend plug to the PN1 connector pins on the mainboard.
most cases do not support this feature, most of you ignore this instruction.
Furthermore, this feature is not necessary as it is already a part of the
mainboard.
Pin number
13
14
PN2 - Hardware Reset connector
There is no specific orientation.
cable to the PN2 connector pins on the mainboard.
Pin number
1
2
Computer
knowledge
PN2 - Speaker connector
There is no specific orientation.
the PN2 connector pins on the mainboard.
Pin number
4
5
6
7
Name or significance of the signal
Suspend
Ground
Name or significance of signal
Ground
Hardware reset signal
The "Hardware Reset" is used to reset the computer
during operation without turning the computer off and
back on. For example, if you are running an application
that stops responding to the computer, you may press the
Reset button to restart the computer.
Name or significance of signal
+5VDC
Ground
Ground
Sound Signal
Connect the two-thread hardware
Connect the two-thread hardware reset
Connect the four-thread speaker cable to
2-5
Since
