Abit IT5E Series User Manual page 16

2-4
Computer
Knowledge
PN1 - IDE LED connector
This connector has a specific orientation.
LED connector cable attached to the case to the IDE LED connector on
the mainboard.
Pin number
7
8
PN1 - Standby connector
There is no specific orientation.
support this feature so most of you can ignore this instruction.
case has a cable for the Standby feature, you should connect this cable to
the connector on the Mainboard.
Pin number
10
11
Computer
knowledge
PN1 - Hardware Suspend switch
The "keylock switch" is used to lock the computer' s
keyboard. This disables the keyboard so that
unauthorized persons cannot use it.
is in use, you will need to use the unlock key to activate
the keyboard.
Name or significance of signal
LED' s Cathode
LED' s Anode
Name or significance of signal
Standby power supply<+5VSB>
Control signal of computer switch of the case
The "standby connector," unlike the traditional mechanical
switch, is an electronic way to turn the computer' s power
off. To use this feature, the power supply system must
permit a shutdown power supply (+5VSB), support the
electronic switch feature, and must also be used with
connector JS1 on the mainboard.
using Windows 95, your computer will automatically shut
down after having saved your work when you exit
Windows. You do not need to use the mechanical
switch to turn the computer off.
Connect the two-thread IDE
Most of the present AT cases do not
Chapter 2
When this function
If your
For example, when
