- Page 1 Coronis Getting Started Guide Supported displays: MDCC 2121, MDCG 2121, MDCG 3120...
- Page 2 (This page intentionally left blank.) (This page intentionally left blank.)
-
Page 3: Copyright Notice
Barco N.V. or Barco, Inc., for use only under the specific terms of a software license agreement between Barco N.V. or Barco Inc. and the licensee. No other use, duplication, or disclosure of a Barco software product, in any form, is authorized. - Page 4 Indications for use The Coronis displays are intended to be used in displaying and viewing digital images for review and analysis by trained medical practitioners. The Coronis displays are not intended for primary diagnostic review of Mammography images.
-
Page 5: Table Of Contents
Recommendations for using your display system ....... 25 Display controller installation ..........27 Display Controller Installation ............28 Which display controller? ............28 Installing a Barco display controller........28 Installation Procedure............. 31 Display installation ..............37 Installation precautions ..............38 Display parts, controls and connectors ......... - Page 6 Table of Contents Connecting the signal cables............52 Cable routing .................. 55 Cleaning instructions..............58 Precautions................58 Front glass ................58 Cabinet ..................59 Software installation ............. 61 Driver and Software Installation ........... 62 Driver and software installation prerequisites...... 62 Installing the B MXRT drivers and software ....
-
Page 7: Preface
Preface Preface... -
Page 8: Regulatory Compliance Information
The use of shielded cables for connection of the monitor to the graphics card is required to ensure compliance with FCC regula- tions. Changes or modifications to this unit not expressly approved by Barco could void the user’s authority to operate this equipment. -
Page 9: Canadian Notice
Regulatory compliance information Canadian notice This ISM device complies with Canadian ICES-001. Cet appareil ISM est conforme à la norme NMB-001 du Canada. -
Page 10: Ce Mark Notice
CE mark notice CE mark notice Declaration of Conformity in accordance with Article 10 (1) of the CE directive This product has been designed and manufactured in accordance with the essential requirements of the Directives 2004/108/EC and MDD 93/42/EEC (amended by 2007/47/EC (class II b product), and for this product the procedures of Annex II have been applied to mark the product with the CE label. -
Page 11: Environmental Information
Environmental information Environmental information Disposal Information This product consists of devices that may contain mercury, which must be recycled or disposed of in accordance with local, state, or country laws. (Within this system, the backlight lamps in the monitor display contain mercury.) This equipment has required the extraction and use of natural resources for its production. - Page 12 Environmental information Information for China ROHS compliance Table of toxic and hazardous substances/elements and their content, as required by China’s management methods for controlling pollution by electronic information products Toxic or hazardous Substances and Elements Part Name Cr6+ PBDE Metal parts Plastic parts PCB or PCBA LCD panel...
- Page 13 Environmental information LCD Monitor 零部件名稱 有毒有害物質或元素 汞 镉 六价铬 多溴联苯 多溴二苯醚 铅 （Pb） （Hg） （Cd） （Cr6+） （PBB） （PBDE） 金属机构件 塑料机构件 电路板组件 * 液晶面板 电源模块 / 适配器 电源线 外部信号连接线 *： 电路板组件包括印刷电路板及其构成的零部件，如电阻、电容、集成电路 、连接器等 ○：表示该有毒有害物质在该部件所有均质材料中的含量均在 《电子信息产品中有 毒有害物质的限量要求标准》规定的限量要求以下...
-
Page 14: Safety Instructions
Safety Instructions Safety Instructions General Recommendations Read the safety and operating instructions before operating the display. Retain safety and operating instructions for future reference. Adhere to all warnings on the display and in the operating instructions manual. Follow all instructions for operation and use. Electrical shock WARNING: To avoid the risk of electric shock, this equipment must only be connected to a supply mains with protective earth. - Page 15 Safety Instructions Power connection - display with external power supply • Power requirements: The display must be powered using the delivered medical approved 12 VDC power supply. • The medical approved DC power supply must be powered by the AC mains voltage. Power cords: •...
- Page 16 Safety Instructions Installation Place the display on a flat, solid and stable surface that can support the weight of at least 3 displays. If you use an unstable cart or stand, the display may fall, causing serious injury to a child or adult, and serious damage to the equipment.
-
Page 17: Emc Notice
EMC notice EMC notice No specific requirement on the use of external cables or other accessories except power supply. With the installation of the device, use only the delivered power supply or a spare part provided by the legal manufacturer. Using another can result in a decrease of the immunity level of the device. - Page 18 EMC notice must accept any interference received, including interference that may cause undesired operation. Interference can be determined by turning the equipment off and on. If this equipment does cause harmful interference to, or suffer from harmful interference of, surrounding equipment, the user is encouraged to try to correct the interference by one or more of the following measures: •...
- Page 19 EMC notice Voltage dips, < 5% U (> 95% < 5% U (> 95% Mains power quality short should by that of a dip in U ) for 0.5 dip in U ) for 0.5 interruptions typical commercial or cycle cycle and voltage hospital environment.
- Page 20 EMC notice Immunity IEC 60601 Level Electromagnetic environment – test test level guidance Power 3 A/m Power frequency magnetic fields should be frequency applic at levels characteristic of a typical location (50/60 Hz) able in a typical commercial or hospital magnetic field environment.
- Page 21 EMC notice sured field strength in the location in which the B Display is ARCO ORONIS used exceeds the applicable RF compliance level above, the B ARCO ORONIS Display should be observed to verify normal operation. If abnormal perfor- mance is observed, additional measures may be necessary, such as re-ori- enting or relocating the B Display.
- Page 22 EMC notice For transmitters rated at a maximum output power not listed above, the recom- mended separation distance d in meters (m) can be estimated using the equation applicable to the frequency of the transmitter. Where P is the max- imum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
-
Page 23: Explanation Of Symbols
Explanation of symbols Explanation of symbols Symbols on the display and / or power supply On the display or power supply, you may find the following symbols (nonrestrictive list): Indicates compliance to the essential require- ments of the Directive 93/42/EEC Indicates compliance with Part 15 of the FCC rules (Class A or Class B) Indicates the display is approved according to... - Page 24 Explanation of symbols Indicates the display serial no. Consult the operating instructions Indicates this apparatus must not be thrown in the trash but must be recycled, according to the European WEEE (Waste Electrical and Electronic Equipment) directive Symbols used throughout the manual: Warning: Risk of Caution: Risk of injury to human...
-
Page 25: Recommendations For Using Your Display System
To do this, go to “Power Options Properties” in the “Control Panel”. Barco recommends setting DPMS activation after 20 minutes of non-usage. 2. Use a screen saver to avoid image retention Prolonged operation of an LCD with the same content on the same screen area may result in a form of image retention. - Page 26 Recommendations for using your display system diagnostic performance of the product. To ensure optimal product quality, Barco applies strict selection criteria for its LCD panels. To learn more about LCD technology and missing pixels, consult the dedicated white paper available at www.barcomedical.com.
-
Page 27: Display Controller Installation
Display controller installation Display controller installation... -
Page 28: Display Controller Installation
Display Controller Installation Display Controller Installation Which display controller? Your Barco medical display is compatible with a large range of Barco and non-Barco display controller boards. Depending on the customer’s order details, the display can be delivered with or without display controller. - Page 29 Display Controller Installation Types of display controllers for Barco Display Systems The following models of Barco display controllers are available for your display system. Please check which of the following models is delivered with your system, and follow the corresponding installation...
- Page 30 VGA on ALL the other BarcoMed display controllers. To use a BarcoMed display controller with a third party VGA controller or with one or more Barco MXRT display controllers, do NOT enable VGA on the BarcoMed display controller.
-
Page 31: Installation Procedure
Display Controller Installation Installation Procedure The following instructions will take you step by step through the installation of the display controller(s) for your B Display ARCO ORONIS System. CAUTION – Wear a grounded, protective ESD strap when handling or during installation of the display controller. Electrostatic charges can damage the display controller. - Page 32 Display Controller Installation Align the display controller(s) for your B Display ARCO ORONIS System with the slot(s) and press it(them) in firmly until the card(s) is(are) fully seated. Note: The next step applies only to the MXRT 5100, MXRT 7100, and MXRT 7200. Connect the power cable(s) to the 6-pin power connection(s) on the graphics card.
- Page 33 For a detailed description of the display installation and signal connection, please refer to the “Display installation” section of this manual. Figure 6: IO-Panel for the Barco MXRT 1150 and Barco MXRT 2150 S-Video Connection This option is not supported by Barco.
- Page 34 Display Controller Installation Figure 7: IO-Panel for the Barco MXRT 2100 and Barco MXRT 5200 MXRT 2100 MXRT 5200 Head 2– DVI-I Head 1– DVI-I Connection Connection Head 1– DVI-I Head 2– DVI-I Connection Connection Note: For 6mp, connect Head 1 to left input, and Head 2 to right input.
- Page 35 Display Controller Installation Note: For 6mp, connect Head 1 to left input, and Head 2 to right input. Figure 9: IO-Panel for the Barco MXRT 7300 DisplayPort Connections DVI-I Connection Note: Disconnecting the DisplayPort cable may lock the display.
- Page 36 Note: Your Barco display(s) will be running in a basic video mode at a default refresh rate. Higher resolutions and refresh rates, such as 1536x2048@60Hz, are not available at this stage of the installation.
-
Page 37: Display Installation
Display installation Display installation... -
Page 38: Installation Precautions
Installation precautions Installation precautions Precautions • Keep your original packaging. It is designed for this display and is the ideal protection during transport. • Avoid reflections in the flat panel to reduce eye strain. • Place the display on a strong and stable table or desk. •... -
Page 39: Display Parts, Controls And Connectors
Display parts, controls and connectors Display parts, controls and connectors Front The front controls are soft touch keys. When you touch any of them while no on-screen display (OSD) is on the screen, the front illumination is switched on for a few seconds. When you touch a key again while the illumination is on, the function of the key is executed. - Page 40 Display parts, controls and connectors To display the OSD (on-screen display). In the OSD, this button acts as Enter button to make selections. Standby To put the display in standby mode. Ambient light sensor Senses the ambient light around the display. The ambient light measurement is taken into account in the DICOM display function calibration.
-
Page 41: Rear
Display parts, controls and connectors Rear Figure 12: Rear view Connector compartment cover. Detach to get access to the signal connectors. Slot for security cable (e.g., Kensington lock). Push-button to release the panel unit from the tilt & swivel foot in landscape orientation. -
Page 42: Side
Display parts, controls and connectors Connect the output of the DC power supply delivered with the display to this connector. +5 Vdc, 0.25 A power output for accessories. DVI (digital) video input. USB upstream port (to PC). USB downstream port (to peripheral USB devices). Power output for asset management. -
Page 43: Foot
Display parts, controls and connectors Foot The display stand is packaged separately from the display panels. After unpacking you have to click the panels to the stand. There are several types of stands, depending on the number of panels in the system. - Page 44 Display parts, controls and connectors Dual-head stand Figure 16: Dual-head stand (rear view) Arm covers. The covers are packaged separately from the stand. You have to click them to the arms after connecting the signal cables. Cable duct covers. Push down and turn to open before connecting the signal cables.
-
Page 45: Single-Head Installation
Single-head installation Single-head installation To attach the panel unit to the display stand: Take the display stand from the packaging and put it on a solid flat surface. Take the panel unit from the packaging and hold it in portrait position. - Page 46 Single-head installation To detach the panel unit from the display stand: Firmly push the push-button at the rear of the panel (3) or (4). Push button (3) to release the panel in landscape position. Push button (4) to release the panel in portrait position (button not visible on drawing because hidden by the display stand).
-
Page 47: Dual-Head Installation
Dual-head installation Dual-head installation To attach the panel units to the dual-head stand: Take the stand from the packaging and put it on a solid flat surface. Figure 18: Dual-head stand Unpack the panels. Slide the display brackets on the stand arms in the correct position. - Page 48 Dual-head installation Display bracket position (multi-head): Portrait orientation: 46mm Landscape orientation: 100mm Figure 19: Example of label with position for brackets 130 120 110 100 90 Figure 20: Shift brackets according to label indication Take one of the panels and hold it in the desired position (portrait or landscape).
- Page 49 Dual-head installation Hook the top gaps in the rear of the panel over the top anchors of the bracket (figure 21 below). Push the bottom of the panel firmly towards the stand so that the bottom anchors clip in the bottom gaps (figure 21 below). Figure 21: Repeat steps 4.
-
Page 50: Vesa-Mount Installation
Vesa-mount installation Vesa-mount installation Important: • Use an arm that is approved by VESA (according to the VESA 100 mm standard). • Use an arm that can support a weight of at least 10 kg (22.05 lbs). To attach the panel unit to an arm stand: Unscrew the 4 screws (M4 x 8 mm) from the rear of the display panel. -
Page 51: Adjust Panel Orientation
Adjust panel orientation Adjust panel orientation To adjust the panel orientation: Before turning the display panel, lift it in its heighest position. If not, the corner of the panel might hit the foot during the rotation. To change from portrait to landscape, turn the panel counterclockwise. -
Page 52: Connecting The Signal Cables
Connecting the signal cables Connecting the signal cables To connect the signal cables to the display: Make sure the computer is turned off. To get access to the connectors, remove the connector compartment cover (1). To remove the cover, gently pull the bottom side of the cover upward or firmly press down the 2 clips at the top side (positions marked in the plastic). - Page 53 Connecting the signal cables Connect signal cables: Figure 26: Signal cable connections • Connect one end of the DVI cable to the DVI input of the display (4). Connect the other end of the DVI cable to the DVI connector of the display controller board. •...
- Page 54 Connecting the signal cables Figure 27: External DC power supply...
-
Page 55: Cable Routing
Cable routing Cable routing To route the cables: Figure 28: Display rear view Bind the cables in the connector compartment together with the cable tie inside the connector compartment. Route the cables alongside the neck and in the cable ducts in the tilt &... - Page 56 Cable routing Unpack the plastic stand arm covers and attach them to the display stand. To attach the arm covers, first slide the covers horizontally over the arms and then push them firmly against the arms so that the covers’ plastic clips hook in the grooves in the metal arms. Figure 29: Attach arm covers...
- Page 57 Cable routing Close the cable duct covers. Push the cable duct covers upward to lock them. Figure 30: Installation complete...
-
Page 58: Cleaning Instructions
Cleaning instructions Cleaning instructions Precautions • Take care not to damage or scratch the glass or LCD panel. Be careful with rings or other jewellery that can touch the glass. • Do not apply pressure on the glass or LCD panel. •... -
Page 59: Cabinet
Cleaning instructions • Detergents with ammonia • Detergents with abrasives • Steel wool • Sponge with abrasives • Steel blades • Cloth with steel thread Cabinet Proceed as follows: • Clean the cabinet using a soft cotton cloth, lightly moistened with a recognized cleaning product for medical equipment. - Page 60 Cleaning instructions (This page intentionally left blank.)
-
Page 61: Software Installation
Software installation Software installation... -
Page 62: Driver And Software Installation
MXRT family of controllers and B ARCO ARCO family of controllers is handled separately. If you install Barco displays without Barco display controllers, no drivers will be installed. Only the online user manual will be installed on your system. Driver and software installation prerequisites... - Page 63 CD-ROM into your computer’s CD/DVD drive after the operating system has started. If your CD/DVD drive’s auto-run is not enabled or the Barco Product Installation Wizard does not start automatically, you can run the Barco Product Installation Wizard manually by following these steps:...
- Page 64 The Barco Product Installation Wizard will now guide you through the installation of the driver. Click Yes to accept the terms of the Barco and ATI license agreements. The Barco setup wizard will continue with the installation only if you accept the terms of both license agreements.
-
Page 65: Reinstalling Drivers
Software should automatically detect your Barco displays and attach them to the desktop with the correct resolution. If the Barco Monitor Plug and Play Software fails to detect your Barco displays or fails to attach them to the desktop correctly please refer to the section, Setting the resolution of your Barco Display in the Configuring Windows section of this manual. - Page 66 Driver and Software Installation Figure 31: Barco MXRT Driver Removal Wizard (driver version may be different than what is pictured) Note: Vista Only: After uninstalling the driver, shutdown the machine and remove the card. If you leave the card in the system, Vista will automatically reinstall the driver.
- Page 67 Insert the B Display System Installation CD-ROM into ARCO ORONIS your CD/DVD drive. When the Barco Product Installation Wizard starts click “Cancel”. Click the Start button in the task bar. Click Run. Click Browse and Browse to the root directory of the B...
-
Page 68: Installing The B
Run MXRT driver cleaner.bat by double clicking on it (this will either be installed as an icon on your desktop, or can be found on the Barco Display System installation CD at: drivers\2KXP\ATI). This will remove all the previous installed MXRT driver files. - Page 69 If your CD/DVD drive’s auto-run is not enabled or the Barco Product Installation Wizard does not start automatically, you can run the Barco Product Installation Wizard manually by following these steps: Click the Start button in the task bar.
- Page 70 Next to accept the default settings or if you know the settings required for your viewing application, you may select them now and then click Next. You may change these settings later by accessing the Barco Driver tab within the Windows Display Control Panel. Figure 33: Please refer to your application manuals for information on the correct Palette and Drawing modes to select.
- Page 71 Software should automatically detect your Barco displays and attach them to the desktop with the correct resolution. If the Barco Monitor Plug and Play Software fails to detect your Barco displays or fails to attach them to the desktop correctly please refer to the section, Setting the resolution of your Barco Coronis Display in the Configuring Windows section of this manual.
- Page 72 To install the drivers and software silently, please follow the steps below: Insert the B Display System Installation CD-ROM into ARCO ORONIS your CD/DVD drive. When the Barco Product Installation Wizard starts click “Cancel”. Click the Start button in the task bar. Click Run. Click Browse and...
- Page 73 Driver and Software Installation Browse to the root directory of the B Display ARCO ORONIS System Installation CD-ROM. Click on the file, Setup.exe, and click Open. Browse to the root directory of the location where you saved the contents of your B Display System ARCO ORONIS...
- Page 74 Driver and Software Installation (This page intentionally left blank.)
-
Page 75: Where To Get More Information
The online user guide is installed on the system PC during the system driver installation. To open the online user guide, select Start>Program Files>Barco>Documentation>Coronis online user guide from the Windows Start menu. The online user guide uses Java scripts to create the html pages. In Windows XP, SP2, it is possible that Internet Explorer blocks them for security reasons. - Page 76 Where to get more information • In the Security section, check the option Allow active content to run in files on My Computer...
-
Page 77: Troubleshooting
Troubleshooting Troubleshooting... -
Page 78: General Tips
General tips General tips • If one display from a multi-head system exhibits problems, try to eliminate the problem by switching video cables or power supplies. In that way you can find out if the problem resides in the display or not. If the display screen remains black after installation: Possible causes: •... -
Page 79: Configuring Windows
Setting”. Click on the Settings tab (the Settings tab is not present in Vista). Select the rectangle that represents the Barco display whose settings you wish to change. Note: If you are using the VGA capabilities of your B ARCO display controller, the resolution for the first display may be set to a VGA resolution of “640 x 480”... - Page 80 Configuring Windows rectangle for the virtual display representing the two heads controlled by each BarcoMed display controller output. If you installed your B Display System drivers in ARCO ORONIS DualView mode (default for Windows XP) there will be a rectangle representing each head controlled by each output of the display controller.
-
Page 81: Setting The Color And Palette Modes
Display System you must be logged in using an account ORONIS with administrator privileges. If you are using a color display in conjunction with your Barco grayscale display(s) you should configure your desktop before setting the resolution of the your Barco grayscale display(s). - Page 82 Configuring Windows (This page intentionally left blank.)
-
Page 83: Technical Specifications
Technical Specifications Technical Specifications... - Page 84 Technical Specifications Item MDCG 2121 MDCG 3120 Product acronym MDCG 2121 MDCG 3120 Screen technology TFT AM LCD Dual TFT AM LCD Dual Domain IPS Domain IPS Active screen size 541 mm (21.3") 528 mm (20.8") (diagonal) Active screen size (H 432 x 324 mm (17.0 424 x 318 mm (16.7 x V)
- Page 85 Technical Specifications Item MDCG 2121 MDCG 3120 Maximum lumi- 1650 cd/m² 1000 cd/m² nance* DICOM calibrated 500 cd/m² 500 cd/m² luminance (ULT off)* Contrast ratio (typi- 850:1 900:1 cal)* Response time (Tr + 23 ms 50 ms Scanning frequency 30-150 kHz; 15-80 30-150 kHz;...
- Page 86 Technical Specifications Item MDCG 2121 MDCG 3120 Dimensions with Portrait: 369 x Portrait: 369 x stand (W x H x D) 558~658 x 285 mm 558~658 x 285 mm Landscape: 477 x Landscape: 477 x 504~604 x 285 mm 504~604 x 285 mm Dimensions w/o Portrait: 369 x 477 x Portrait: 369 x 477 x...
- Page 87 Technical Specifications Item MDCG 2121 MDCG 3120 Certifications IEC 60950-1:2005, IEC 60950-1:2005, IEC 60601-1:1988 + IEC 60601-1:1988 + A1:1991 + A2:1995, A1:1991 + A2:1995, IEC 60601-1:2005, IEC 60601-1:2005, IEC 60601-1-2:2007, IEC 60601-1-2:2007, UL 60950-1, 1st edi- UL 60950-1, 1st edi- tion, 2007, UL tion, 2007, UL 60601-1, 1st edition...
- Page 88 NEMA 5-15P), Chi- nese (CCC)) nese (CCC)) USB 2.0 cable USB 2.0 cable External power sup- External power sup- Optional accessories Barco Diagnostic Barco Diagnostic Medical LCD Display Medical LCD Display Dual Head Stand Dual Head Stand QA software MediCal QAWeb...
- Page 89 Technical Specifications Item MDCC 2121 Product acronym MDCC 2121 Screen technology TFT AM LCD Dual Domain IPS Active screen size 541 mm (21.3") (diagonal) Active screen size (H 432 x 324 mm (17.0 x 12.8") x V) Aspect ratio (H:V)
- Page 90 Technical Specifications Item MDCC 2121 Contrast ratio (typi- 1100:1 cal)* Response time (Tr + 17 ms Scanning frequency 30-150 kHz; 15-80 Hz (H; V) Housing color Gray Video input signals DVI-D Dual Link Video inout termi- nals USB ports 1 upstream (endpoint), 3 downstream...
- Page 91 Technical Specifications Item MDCC 2121 Net weight w/o 9.0 kg stand Net weight pack- 19.0 kg aged with stand Net weight pack- 12.0 kg aged w/o stand Height adjustment 100 mm range Tilt -5° / +25° Swivel -45° / +45°...
- Page 92 Main cables (UK, European (CEBEC/KEMA), USA (UL/CSA; adaptor plug NEMA 5-15P), Chinese (CCC)) USB 2.0 cable External power supply Optional accessories Barco Diagnostic Medical LCD Display Dual Head Stand QA software MediCal QAWeb Units per pallet Pallet dimensions (W x H)
-
Page 93: Warranty Statement
Any claim under the Warranties must be notified to Barco in writing within 8 days from the date the defect or failure has been discovered or noticed the first time. The Customer, upon the occurrence of... - Page 94 All software installed on the system, whether they are acquired from Barco nv, MID or third party. An exception is made for software delivered by Barco nv, MID that would prove to be a cause for the mal functioning of the hardware covered under this Agreement.
- Page 95 LCD luminance uniformity that is in within the product specifications or luminance uniformity performance that is inherent to LCD technology. Barco nv, MID does not warrant a minimum life time nor a performance of any of the consumables.
- Page 96 If there is an indication that the equipment was used – even temporary – outside its specifications, Barco nv, MID is entitled not to perform warranty repairs and terminate the warranty agreement. Any actions that have been taken by Barco nv, MID in this respect, may be invoiced to the Customer at normal pricing.
- Page 97 Barco nv, MID shall not be responsible for machine failure and/or its failure to render service or maintenance due to causes beyond its reasonable control.
- Page 98 Warranty Statement...
- Page 99 Warranty Statement...
- Page 100 B410578-05 April 2013 Barco nv President Kennedypark 35 8500 Kortrijk Belgium www.barco.com...
