1.
To make assembly easier, read the information
on page 5 before you begin assembling the
elliptical exerciser.
While another person lifts the Base (1), attach the
Front Stabilizer (6) to the Base with two M10 x 82mm
Button Screws (82).
Next, hold the Left Stabilizer Cover (118) and the Right
Stabilizer Cover (119) around the Base (1). Attach the
Stabilizer Covers with six M4 x 16mm Round Head
Screws (101) (only three screws are shown).
2. Remove the indicated screw and the shipping bracket
from the rear of the Base (1). Discard the screw and
the shipping bracket.
Next, turn the Base Foot (26) into the Base (1) as far
as possible.
3. Attach the Rear Stabilizer (7) to the Frame (2) with two
M10 x 127mm Button Screws (83).
Next, hold the handle on the Frame (2), press the
Latch Button (68), and lower the Frame until the Rear
Stabilizer (7) rests on the floor.
1
82
6
118
101
2
3
Handle
6
119
1
1
Shipping
Bracket
26
Screw
83
7
2
68
