Front - Gateway Notebook User Manual

Chapter 7: Using the Optional Port Replicator

Front

Kensington lock ring
Component
Power button
Docking release latch
Kensington™
lock ring
Docking port
86
Docking port
Icon Description
Press to turn the power on or off.
Press the release latch to release the notebook.
Secure your port replicator and notebook to an
object by running a Kensington cable through this
ring and locking it to the slot on the notebook. For
more information, see
on page
Connect the notebook to this port.
Warning: Power is passed through this port. This
docking connection is certified to UL 1950 for use
only with notebooks designed for your Gateway port
replicator.
www.gateway.com
Docking release latch
Power button
"Securing your port replicator"
91.
