SpectraLink IP-DECT SERVER 400 Specifications page 2

SPECIFICATIONS
PROTOCOL SUPPORT
• Session Initiated Protocol (SIP)
OPERATION AND MAINTENANCE
• Single web portal for administration and maintenance of the
entire DECT infrastructure
• HTTP with digest authentication
• HTTPS
SYSTEM ARCHITECTURE
• The Spectralink IP-DECT Server 400 is both a radio unit and
a SIP integration unit to the SIP IP-PBX. Also, it controls and
handles all other infrastructure elements
• Single-cell: 1 x Spectralink IP-DECT Server 400
up to 3 x Spectralink DECT Repeaters (2 or 4 channel
multi-cell)
12 wireless users / six simultaneous calls
Optional 30 users / 11 simultaneous calls
• Multi-cell: 1 x Spectralink IP-DECT Server 400
up to 6 x Radio infrastructure elements (max 3 x Spectralink
IP-DECT Base Station and/or up to 3 x Spectralink DECT
Repeaters) (2 or 4 channel multi-cell)
12 wireless users / six simultaneous calls
Optional 30 users / 12 simultaneous calls
Spectralink IP-DECT Server 400 Configuration
Local Area Network
Server
IP Base Stations
Repeaters
Handsets
©2013 Spectralink
OPTIONAL LICENSES
• 12 simultaneous calls and 30 users license
• Microsoft Lync license
® TM
• Multi-cell license
• G.729 license
• Automatic Alarm Call license
SUPPORTED CODECS
• G.711 A-law and µ-law
• G.726 (32 Kbps - 4 bit ADPCM)
• G.729 (license required)
– All above mentioned Codecs will have a total maximum
of 12 speech channels available
NETWORK AND PROVISIONING
• 10/100 Mbps Ethernet port
• Manual or dynamic host configuration protocol (DHCP)
network setup
• Time and date synchronization using Network Time
Protocol (NTP)
• Event logging
• LED status indication
IP-PBX SIP
Wide Area Network
Application Server
Emergency call
Meeting
Machine failure
Fire
Man down
Heart stop
Alarm accepted
Input /
Output
Charger
In / Out
