- Page 1 Grandstream Networks, Inc. HandyTone-502 Dual FXS Port Analog Telephone Adaptor HT–502 User Manual www.grandstream.com Firmware Version 1.0.0.29 support@grandstream.com...
-
Page 2: Table Of Contents
Firmware and Configuration File Prefix and Postfix.............26 Managing Firmware and Configuration File Download............26 RESTORE FACTORY DEFAULT SETTING....................27 FACTORY RESET........................... 27 GLOSSARY OF TERMS ..........................28 Grandstream Networks, Inc. HT-502 User Manual Page 2 of 31 Firmware 1.0.0.29 Last Updated: 01/2007... - Page 3 CREENSHOT OF ASIC ETTINGS ONFIGURATION 3. S FXS P CREENSHOT OF ONFIGURATION OGIN 4. S FXS P CREENSHOT OF ONFIGURATION 5. S CREENSHOT OF TATUS ONFIGURATION Grandstream Networks, Inc. HT-502 User Manual Page 3 of 31 Firmware 1.0.0.29 Last Updated: 01/2007...
-
Page 4: Ht-502 User Manual
Thank you for purchasing Grandstream’s HT–502, the affordable, feature rich Analog Telephone Adaptor. Grandstream HandyTone-502 is a new addition to the popular HandyTone ATA product family. It features the rich audio quality, a broad range of voice codecs, and functionality of the HT–502, including two (2) -
Page 5: Configure Your Ht-502
FXS port to be connected to analog phones. PHONE2 (RJ-11) FXS port to be connected to analog phones. There are five (5) LED buttons that help you manage the status of your HandyTone. Grandstream Networks, Inc. HT-502 User Manual Page 5 of 31 Firmware 1.0.0.29... -
Page 6: Configure Your Ata
5. Insert the power adapter into the HT–502 and connect it to a wall outlet. 2: C HT–502 IGURE ONFIGURING THE Internet ADSL/Cable Modem Ethernet Analog Phone Analog Phone Cordless Phone Cordless Phone Grandstream Networks, Inc. HT-502 User Manual Page 6 of 31 Firmware 1.0.0.29 Last Updated: 01/2007... -
Page 7: Product Overview
Voice Mail Remote DHCP Pass – Voice Codec Ports Port Indicator Configuration through iLBC, T.38, Server/ G.711, G.723, 2 RJ-45 (LAN) TFTP/HTTP Client G.726, G.728, G.729A/B/E Grandstream Networks, Inc. HT-502 User Manual Page 7 of 31 Firmware 1.0.0.29 Last Updated: 01/2007... -
Page 8: Table 3: Ht-502 Technical
3-way conferencing Caller ID Bellcore Type 1 & 2, ETSI, BT, NTT, and DTMF-based CID Polarity Reversal / Wink EN55022/EN55024 and FCC part15 Class B Safety Grandstream Networks, Inc. HT-502 User Manual Page 8 of 31 Firmware 1.0.0.29 Last Updated: 01/2007... -
Page 9: Basic Operations
Press “9” to move to the next selection in the list: • PCM U / PCM A • G-723 • G-729A/B/E • G-726-32 • G728 • iLBC Grandstream Networks, Inc. HT-502 User Manual Page 9 of 31 Firmware 1.0.0.29 Last Updated: 01/2007... -
Page 10: Placing A Phone Call
Direct IP calling allows two parties, that is, a FXS Port with an analog phone and another VoIP Device, to talk to each other in an ad hoc fashion without a SIP proxy. Grandstream Networks, Inc. HT-502 User Manual Page 10 of 31 Firmware 1.0.0.29... -
Page 11: Call Hold
2. Caller A dials *87 then dials caller C’s number, and then # (or wait for 4 seconds) 3. Caller A can hang up. NOTE: “Enable Call Feature” must be set to “Yes” in web configuration page. Grandstream Networks, Inc. HT-502 User Manual Page 11 of 31 Firmware 1.0.0.29... -
Page 12: 3-Way Conferencing
3. If Caller C answers call, then Caller A presses “flash” to bring Parties B & C into conference. 4. If Caller C does not answer the call, Caller A can press “flash” to resume call with Caller B. Grandstream Networks, Inc. HT-502 User Manual Page 12 of 31 Firmware 1.0.0.29... -
Page 13: Call Features
T.38, pass-through mode may be used. To send or receive faxes in fax pass through mode, users must select all the Preferred Codecs to be PCMU/PCMA (G.711-u/a). Grandstream Networks, Inc. HT-502 User Manual Page 13 of 31 Firmware 1.0.0.29... -
Page 14: Configuration Guide
1) always check, 2) check when pre/suffix changes, and 3) never upgrade WAN P : Select voice menu option 12 to enable WAN Port Wed Access of the device CCESS configuration pages. Grandstream Networks, Inc. HT-502 User Manual Page 14 of 31 Firmware 1.0.0.29 Last Updated: 01/2007... -
Page 15: Configuring Ht-502 With Web Browser
NOTE: If using a web browser to enter the configuration page, strip the leading “0”s because the browser will parse in octet. (i.e. if the IP address is: 192.168.001.014, please type in: 192.168.1.14). Grandstream Networks, Inc. HT-502 User Manual Page 15 of 31 Firmware 1.0.0.29... -
Page 16: End User Configuration
NOTE: If you cannot log into the configuration page by using default password, please check with the VoIP service provider. The service provider may have provisioned and configured the device for you. The Basic Configuration Page is the first web GUI the user will see. Grandstream Networks, Inc. HT-502 User Manual Page 16 of 31 Firmware 1.0.0.29... -
Page 17: Table 7: Ht-502 Basic Configuration Settings Definitions
Forward all WAN IP traffic to a specific IP address if no matching port is used by HT–502 or defined in port forwarding. Port Forwarding Forwards a matching (TCP/UDP) port to a specific LAN IP address with a specific (TCP/UDP) port. Grandstream Networks, Inc. HT-502 User Manual Page 17 of 31 Firmware 1.0.0.29 Last Updated: 01/2007... -
Page 18: Advanced User Configuration
CREENSHOT OF DVANCED ONFIGURATION Grandstream Device Configuration Password Login All Rights Reserved Grandstream Networks, Inc. 2005-2006 Each FXS SIP account has its own configuration page. Their configurations are identical. Grandstream Networks, Inc. HT-502 User Manual Page 18 of 31 Firmware 1.0.0.29... -
Page 19: Table 9: Ht-502 Advanced Configuration
Via HTTP Server The URL for the HTTP server used for firmware upgrade and configuration via HTTP. For example, ttp://provisioning.mycompany.com:6688/Grandstream/1.0.0.36 “:6688” is the specific TCP port where the HTTP server is listening; it can be omitted if using default port 80. - Page 20 The Syslog uses USER facility. In addition to standard Syslog payload, it contains the following components: GS_LOG: [device MAC address][error code] error message Example: May 19 02:40:38 192.168.1.14 GS_LOG: [00:0b:82:00:a1:be][000] Ethernet link is up Grandstream Networks, Inc. HT-502 User Manual Page 20 of 31 Firmware 1.0.0.29 Last Updated: 01/2007...
-
Page 21: Table 10: Ht-502 Individual Account Settings Definitions
FXS port 1 is 5060. The default value for FXS port 2 is 5062. Defines the local RTP-RTCP port pair the HT–502 will listen and transmit. Local RTP port Grandstream Networks, Inc. HT-502 User Manual Page 21 of 31 Firmware 1.0.0.29... - Page 22 This feature is NOT designed to work with and should NOT be enabled for direct IP-to-IP calling. Dial Plan Prefix Sets the prefix added to each dialed number. Grandstream Networks, Inc. HT-502 User Manual Page 22 of 31 Firmware 1.0.0.29...
- Page 23 Configure ring or tone frequencies according to preference. By default Call Progress/ Ring Tones tones are set to North American frequencies. Frequencies should be configured with known values to avoid uncomfortable high pitch sounds. Grandstream Networks, Inc. HT-502 User Manual Page 23 of 31 Firmware 1.0.0.29 Last Updated: 01/2007...
-
Page 24: Saving The Configuration Changes
EMOTE The HT–502 can be remotely reboot by clicking the “Reboot” button at the bottom of the configuration page. When finished, re-login to the HT–502 after waiting about 30 seconds. Grandstream Networks, Inc. HT-502 User Manual Page 24 of 31 Firmware 1.0.0.29... -
Page 25: Software Configuration
FQDN of the HTTP server. It can also be in IP address format. “:6688” is the TCP port the HTTP server listening to, default http server listens to port 80. “/Grandstream/1.0.0.29” is the RELATIVE directory to the root dir on HTTP web server. TFTP PGRADE THROUGH To upgrade firmware via TFTP, set the field “Firmware Upgrade and Provisioning: Upgrade Via”... -
Page 26: No Local Tftp Server
OCAL ERVER For users who do not have a local TFTP server, Grandstream provides a NAT-friendly TFTP server on the public Internet for users to download the latest firmware upgrade automatically. Please check the Services section of Grandstream’s Web site to obtain this TFTP server IP address. Alternatively, user can download and install a free TFTP or HTTP server in his LAN for a firmware upgrade. -
Page 27: Restore Factory Default Setting
Restoring the Factory Default Setting will DELETE all configuration information of the phone. Please BACKUP or PRINT out all the settings before you approach to following steps. Grandstream will not take any responsibility if you lose all the parameters of setting and cannot connect to your VoIP service provider. -
Page 28: Glossary Of Terms
DID Direct Inward Dialing. The ability for an outside caller to dial to a PBX extension without going through an attendant or auto-attendant. Digital Signal Processor. A specialized CPU used for digital signal processing. Grandstream products all have DSP chips built inside. - Page 29 Grandstream is the second-level domain, and and.com is the top level domain. FXS Foreign eXchange Office. An FXS device can be an analog phone, answering machine, fax, or anything that handles a call from the telephone company like AT&T. They should also operate the same way when connected to an FXS interface.
- Page 30 SIP Session Initiation Protocol, An IP telephony signaling protocol developed by the IETF (RFC3261). SIP is a text-based protocol suitable for integrated voice-data applications. SIP is designed for voice transmission and uses fewer resources and is considerably less complex than H.323. All Grandstream products are SIP based...
- Page 31 VoIP Voice over the Internet. VoIP encompasses many protocols. All the protocols do some form of signaling of call capabilities and transport of voice data from one point to another. e.g.: SIP, H.323, etc. Grandstream Networks, Inc. HT-502 User Manual Page 31 of 31 Firmware 1.0.0.29...
