Options - Icom IC-R6 Instruction Manual

15

OPTIONS

• BC-196SA/SD
ac adapter
• BC-153SC
ac adapter
For regular charging of the installed Ni-MH batteries. Same
as supplied one. (Not supplied with some receiver version.)
BC-196SA/SD : 4.5 V DC/400 mA output
BC-153SC : 6.0 V DC/1 A output
• CP-18A/E
cigarette lighter cable with dc
Allows you to operate the receiver through a 12 V cigarette
lighter socket. You can also charge the installed Ni-MH bat-
teries.
• BC-194
charger stand
Allows you to charge the receiver on the desktop. Requires
an AC adapter or cigarette lighter cable.
• AD-92SMA
antenna connector adapter
Allows you to connect an external antenna with a BNC
connector.
• SP-13
earphone
Provides clear audio in noisy environments.
• HP-4
headphone
Light weight monaural headphone.
• LC-146A
carrying case
Helps protect the receiver from scratches, etc.
• CT-17
-
ci v level converter
For receiver remote control using a PC.
79
• OPC-474
For receiver-to-receiver cloning.
• OPC-478/OPC-478UC
Used for data cloning between receiver and a PC with
CS-R6 (cloning software).
• CS-R6
-
dc converter
Provides quick and easy programming of such settings as
memory channels and Set modes contents via your PC's
RS-232C terminal (using OPC-478), or USB port (OPC-
478UC). Either OPC-478 or OPC-478UC is required.
Approved Icom optional equipment is designed for optimal
performance when used with an Icom receiver.
Icom is not responsible for the destruction or damage to an
Icom receiver in the event the Icom receiver is used with
equipment that is not manufactured or approved by Icom.
cloning cable
cloning cable
cloning software
