Icom IC-R6 Instruction Manual page 91

D RECEIVER
• Receive system : Triple-conversion superheterodyne
• Intermediate frequencies : 1st
2nd 19.65 MHz (FM/AM)
3rd
• Sensitivity (except spurious points):
FM (1 kHz/±3.5 kHz Dev.; 12 dB SINAD)
1.625–4.995 MHz 0.32 µV typical
5.000–29.995 MHz 0.25 µV typical
30.000–469.995 MHz 0.18 µV typical
470.000–832.995 MHz 0.32 µV typical
833.000–1029.995 MHz 0.28 µV typical
1030.000–1309.995 MHz 0.35 µV typical
WFM (1 kHz/±52.5 kHz Dev.; 12 dB SINAD)
76.000–108.000 MHz 1.1 µV typical
175.000–221.995 MHz 1.1 µV typical
470.000–770.000 MHz 1.8 µV typical
AM (1 kHz/30% MOD.; 10 dB S/N)
0.495–4.995 MHz 1.3 µV typical
5.000–29.995 MHz 0.89 µV typical
118.000–136.000 MHz 0.63 µV typical
222.000–246.995 MHz 0.63 µV typical
247.000–329.995 MHz 0.79 µV typical
266.7 MHz
19.95 MHz (WFM)
450 kHz (FM/AM)
750 kHz (WFM)
• Selectivity :
AM/FM More than 12 kHz/–9 dB
Less than 30 kHz/–60 dB
WFM More than 150 kHz/–6 dB
• Audio output power : (at 10% distortion/3.0 V DC)
More than 150 mW with a 16 Ω load
Internal speaker
External speaker 80 mW typical with an 8 Ω load
• Ext. speaker connector : 3-conductor 3.5 (d) mm (
14
SPECIFICATIONS
1 ")/8 Ω
⁄
