D Rapid charging with the BC-121N+AD-106
The optional BC-121N allows up to 6 battery packs to be
charged simultaneously. The following are additionally re-
quired.
• Six AD-106 charger adapters.
• An AC adapter (BC-157) or the DC power cable (OPC-656).
Battery
pack
AC adapter
(Purchased
separately)
IMPORTANT!:
DC power cable
Ensure the guide lobes
(OPC-656)
on the battery pack are
(Connect with the
correctly aligned with
DC power supply;
the guide rails inside
13.8 V/at least 7 A)
the charger adapter.
Transceiver
Turn power OFF
AD-106 charger
adapters are installed
in each slot.
Lobes
Guide rails
7
