Hardware Monitoring Function
Appendix H Hardware Monitoring Function
(Installing the Winbond Hardware
Doctor Utility)
Winbond Hardware Doctor is a self-diagnostic system for PCs and must be used with the
Winbond chipset: W83627HF IC series products.
It protects PC hardware by monitoring several critical items including power supply
voltages, CPU & system fan speeds and CPU and system temperatures. These items are
important for the operation of the system. Errors may result in permanent damage to the PC.
Once any item is out of its normal range, a warning message will pop up and remind the user
to take the proper measures.
The following description will tell you how to install and use the Hardware Doctor. You
should have the Winbond Hardware Doctor utility on a CD-ROM or floppy diskette. If you
have a floppy diskette, just insert diskette 1 and execute the Setup.exe file to start
installation.
H-1
®
Step 1. In Windows 95/98, place
the CD-ROM into the computer.
The main menu will appear. Click
the Hardware Doctor Install
button. The HWDoctor Setup screen
will show up. Please refer the to
figure below.
Step 2. Click the "OK" button and
the screen below will appear.
