  • Page 1 WI-2Pa Dual Socket 604 Workstation Board User’s Manual 4200-0349-22 Rev. 1.00...
  • Page 2 This document contains materials protected under International Copyright Laws. All rights reserved. No part of this manual may be reproduced, transmitted or transcribed without the expressed written permission of the manufacturer and authors of this manual. WI-2Pa...

  • Page 3: Table Of Contents

    Contents Chapter 1. Introduction ............ 1-1 1.1. Features & Specifications............1-1 1.2. Package Checklist..............1-3 1.3. Layout Diagram..............1-4 Chapter 2. Hardware Setup..........2-1 2.1. Precautions ................2-1 2.2. Installing the Workstation Board ........... 2-2 2.3. Install Xeon CPU and Heatsink ..........2-3 2.4.
  • Page 4 Security Menu ..............3-22 3.4. PC Health Menu ..............3-23 3.5. Clk/Misc. Menu..............3-25 3.6. Exit Menu ................3-26 Chapter 4. Driver Installation .......... 4-1 Appendix A. Trouble Shooting ........... A-1 Appendix B. How to Get Technical Support ..... B-1 WI-2Pa...

  • Page 5: Chapter 1. Introduction

    Introduction Chapter 1. Introduction 1.1. Features & Specifications  • Supports Dual Intel Xeon processor (603-pin or 604-pin) Chipset  • Intel E7505 chipset supports 400MHz/533MHz Front Side Bus  • Intel 82801DB (ICH4) supports PCI 2.2, Ultra DMA100 IDE protocol ...
  • Page 6 Support 6 USB ports • Support AC97, 5.1Channel (Option) • Support S/PDIF (Option) Miscellaneous • 24-pin and 8-pin EPS 12V power connectors • Extend ATX form factor (12” x 13”) Specifications and information contained herein are subject to change without notice. WI-2Pa...

  • Page 7: Package Checklist

    Introduction 1.2. Package Checklist (1) WI-2Pa Workstation board (1) Brief Installation Guide (1) Driver & Utilities CD (1) Ribbon cable for (1) 3.5” floppy disk drive (2) Ribbon cables for master and slave IDE drives (1) CPU Retention Mechanism (2) Retention Clips for 603-pin CPU...

  • Page 8: Layout Diagram

    Chapter 1 1.3. Layout Diagram WI-2Pa...
  • Page 9 Description Default Setting CCMOS1 CMOS Clear Pins 1-2 (Normal) Closed Connectors Description 6CHAUD1 Optional ABIT CA-20 Interface Connector AGP1 Slot for AGP8x/4x AGP Pro Display Card ATX12V1 8-pin EPS12V Power Connector ATXPWR1 24-pin EPS12V Power Connector CD1/AUX1 Internal Audio Sources Connectors...
  • Page 10 Chapter 1 WI-2Pa...

  • Page 11: Chapter 2. Hardware Setup

    Hardware Setup Chapter 2. Hardware Setup 2.1. Precautions Please pay attention to the following precautions before setting up any hardware. 1. Always switch off the power supply and unplug the power cord from the wall outlet before installing the board or changing any settings. 2.

  • Page 12: Installing The Workstation Board

    5. Tightens all the screw holes. ATTENTION: To prevent shorting the PCB circuit, please REMOVE the metal studs or spacers if they are already secured on the chassis base and are without mounting-holes on the workstation board to align with. WI-2Pa...

  • Page 13: Install Xeon Cpu And Heatsink

    Hardware Setup 2.3. Install Xeon CPU and Heatsink This workstation board provides you two Socket-604 sockets to install Intel Xeon CPU. The CPU you bought should have a kit of heatsink and cooling fan bundled together. If that’s not the case, buy one specially designed for Xeon Socket 604 CPU. Please refer to the diagram shown below to install CPU and heatsink.

  • Page 14: System Memory

    Installing and Removing Memory Modules ATTENTION: Populate the DDR DIMMs in-order and in-pair (of the same type and size) by starting from DIMM0~DIMM1, DIMM2~DIMM3, to DIMM4~DIMM5. The System may hang or appear unstable if the DIMM ordering is not followed. WI-2Pa...
  • Page 15 Hardware Setup Power off the computer and unplug the AC power cord before installing or removing memory modules. 1. Locate the DIMM slot on the workstation board. 2. Hold two edges of the DIMM module carefully, keep away of touching its connectors. 3.

  • Page 16: Connectors, Headers, And Switches

    EPS12V power supplier with 460W capacity at least for Pentium 4 Xeon CPU system. NOTE: The auxiliary 12V power (ATX12V1) is necessary to support Intel Xeon CPUs. Failing to provide such extra power will result in the system’s booting failure. WI-2Pa...

  • Page 17: Fan1~6: Fan Connectors

    Hardware Setup 2.5.2. FAN1~6: FAN Connectors • FAN1: CPU1 Fan • FAN2: CPU2 Fan • FAN3: System Fan • FAN4~FAN6: System Fan (No speed monitoring support in BIOS menu) User’s Manual...

  • Page 18: Ccmos1: Cmos Memory Clearing Header

    CMOS memory. The default setting is pin 1 and pin 2 shorted for normal operation. ATTENTION: Turn the system power off first (including the +5V standby power) before clearing the CMOS memory. Failing to do so may cause your system to work abnormally or malfunction. WI-2Pa...

  • Page 19: Fpio1: Front Panel Switches And Indicators Header

    Hardware Setup 2.5.4. FPIO1: Front Panel Switches and Indicators Header This header is used for connecting switches and LED indicators on the chassis front panel. Watch the power LED pin position and orientation. The mark “+” align to the pin in the figure below stands for positive polarity for the LED connection.

  • Page 20: Fdc1, Ide0/Ide1 Connectors

    NOTE: Make sure to configure the “Master” and “Slave” relation before connecting two drives by one single ribbon cable. The red line on the ribbon cable must be aligned with pin-1 on both the IDE port and the hard-drive connector. WI-2Pa...

  • Page 21: Pci Slots

    Hardware Setup 2-11 2.5.6. PCI Slots: PCI1/PCI2: PCI 33MHz/32bit PCI3: PCI-X 100MHz/64bit PCI4/PCI5: PCI 66MHz/64bit User’s Manual...

  • Page 22: 6Chaud1: 5.1-Channel Audio Interface Header

    Chapter 2 2.5.7. 6CHAUD1: 5.1-Channel Audio Interface Header This header provides 5.1-channel audio output through optional ABIT CA-20 interface. To enable the audio function on optional CA-20 interface, use the extension cable packed with CA-20 to connect both the 6CHAUD1 headers on CA-20 and this board.

  • Page 23: Usb1/Usb3: Additional Usb Ports Headers

    Hardware Setup 2-13 2.5.8. USB1/USB3: Additional USB Ports Headers These headers each provide two additional USB ports connection. Pin Assignment Pin Assignment Data0 - Data1 - Data0 + Data1 + Ground Ground To enable the USB function on optional CA-20 interface, use the extension cable packed with CA-20 to connect the JP1 header on CA-20 and the USB1 header on this board.

  • Page 24: Cd1, Aux1: Internal Audio Connector

    2-14 Chapter 2 2.5.9. CD1, AUX1: Internal Audio Connector These connectors connect to the audio output of internal CD-ROM drive or add-on audio card. WI-2Pa...

  • Page 25: Ir1: Infrared Device Header

    Hardware Setup 2-15 2.5.10. IR1: Infrared Device Header This header connects to an optional IR device attached to chassis. This workstation board supports standard IR transfer rates. User’s Manual...

  • Page 26: Back Panel Connectors

    Blink Orange Active • USB: Universal Serial Bus connector. • MIDI/GAME Port: Joystick, game pad, MIDI or other simulation hardware devices connector. • Line Out: Audio output jack. • Line In: Audio input jack. • Mic In: Microphone input jack. WI-2Pa...

  • Page 27: Chapter 3. Bios Setup

    BIOS Setup Chapter 3. BIOS Setup The BIOS is a program located in a Flash Memory chip on the workstation board. This program will not be lost when you turn the computer off. This program is also referred to as the boot program. It is the only channel the hardware circuit has to communicate with the operating system.

  • Page 28: Main Menu

    IDE Primary Master, IDE Primary Slave, IDE Secondary Master, and IDE Secondary Slave Move cursor to item “IDE Primary Master”, “IDE Primary Slave”, “IDE Secondary Master” or “IDE Secondary Slave”, and then press <Enter> key to enter a sub-menu. WI-2Pa...
  • Page 29 BIOS Setup IDE Primary/Secondary Master/Slave IDE HDD Auto-Detection This item allows you to detect the parameters of IDE drives by pressing the <Enter> key. The parameters will automatically be shown on the screen. IDE Primary Master When set to [Auto], the BIOS will automatically check what kind of IDE drive you are using.
  • Page 30 You can configure this item to sectors per track. The minimum number you can enter is 0, the maximum number you can enter is 255. WI-2Pa...
  • Page 31 BIOS Setup Drive A This item sets the type of floppy drives installed. [None]: No floppy drive installed [360K, 5.25 in.]: 5.25-inch standard drive; 360KB capacity [1.2M, 5.25 in.]: 5.25-inch AT-type high-density drive; 1.2MB capacity [720K, 3.5 in.]: 3.5-inch double-sided drive; 720KB capacity [1.44M, 3.5 in.]: 3.5-inch double-sided drive;...

  • Page 32: Advanced Menu

    3.2. Advanced Menu 3.2.1. Advanced BIOS Features CPU Hyper-Threading Leave this item to its default setting to enable the simultaneous multi-threaded (SMT) processor so as to make one physical processor looks like two logical processors to the OS and applications. WI-2Pa...
  • Page 33 BIOS Setup This option is for CPU with Hyper-Threading Technology only. For more information on “Hyper-Threading Technology”, please visit Intel Web site at http://www.intel.com/homepage/land/hyperthreading.htm http://www.intel.com/design/chipsets/ht/. Quick Power On Self Test When set to [Enabled], this item speeds up the Power On Self Test (POST) after powering on the system.
  • Page 34 The options are 1.1 and 1.4. The default setting is 1.4. If you use an older OS for dual processor executing, please set this option to 1.1. Small Logo(EPA) Show: This item determines to show the EPA logo when booting. WI-2Pa...

  • Page 35: Advanced Chipset Features

    BIOS Setup 3.2.2. Advanced Chipset Features DRAM Timing Control This item controls the DRAM timing. Press <Enter> key to enter its menu. DRAM Timing Selectable This item sets the optimal timings for the following four items, depending on the memory module you are using. The default setting “By SPD” configures these four User’s Manual...
  • Page 36 This option specifies the amount of system memory that can be used by the AGP device. The aperture is a portion of the PCI memory address range dedicated for graphics memory address space. Host cycles that hit the aperture range are forwarded to the AGP without any translation. See www.agpforum.org for AGP information. WI-2Pa...

  • Page 37: Integrated Peripherals

    BIOS Setup 3-11 3.2.3. Integrated Peripherals In this menu, you can change the onboard I/O device, I/O port address and other hardware settings. Onboard IDE-1 Controller This item enables or disables the onboard IDE-1 controller. Onboard IDE-2 Controller Its description is the same as the Onboard IDE-1 Controller. USB Controller Two options are available: Enabled and Disabled.
  • Page 38 You also need to note the compatibility issue with your PS/2 mouse. Some PS/2 mice cannot wake up the system because of compatibility problems. Also, if the specs of your keyboard are too old, it may fail to power on. WI-2Pa...
  • Page 39 BIOS Setup 3-13 KB Power ON Password This option allows you to set a password required in order to Power ON your computer. You will be asked to enter your password and then to confirm it. Do not forget your password. Should you forget your password, you will have to open your computer case, clear the CMOS and reset all parameters again in order to be able to utilize this function.
  • Page 40 This item sets the address of the onboard midi port connector. Midi Port IRQ This item sets the IRQ of the onboard midi port connector. If you choose disable the Midi Port Address, then this field is not available. WI-2Pa...
  • Page 41 BIOS Setup 3-15 NOTE: If you bought an audio adapter and wanted to replace the use of onboard audio solution, you have to disable three items in BIOS. Otherwise, your audio adapter may not work well. These three items are: AC 97 Audio: set to Disabled Game Port Address: set to Disabled Midi Port Address: set to Disabled...

  • Page 42: Power Management Setup

    Devices states are compatible with the current Power Resource states. Only devices which solely reference Power Resources which are in the ON state for a given device state can be in that device state. In all other cases, the device is in the D3 (off) state. WI-2Pa...
  • Page 43 BIOS Setup 3-17 • Devices that are enabled to wake the system and that can do so from their current device state can initiate a hardware event which transitions the system state to S0. This transition causes the processor to continue execution where it left off.
  • Page 44 On Ring/LAN) prior to the date and time set in these items, the system will give priority to the incoming calls or network instead. Date (of Month) Alarm [0]: This option power-on the system everyday according to the time set in the “Time (hh:mm:ss) Alarm” item. WI-2Pa...
  • Page 45 BIOS Setup 3-19 [1-31]: This option selects a date you would like the system to power-on. The system will power-on on the date set, and the time set in the “Time (hh:mm:ss) Alarm” item. Time (hh:mm:ss) Alarm This item sets the time you would like the system to power-on. User’s Manual...

  • Page 46: Pnp/Pci Configurations

    Manual to set which IRQ is assigned to PCI PnP cards. The following figure shows you the screen of IRQ resources. Each item has two options: PCI Device and Reserved. The default setting is PCI Device. WI-2Pa...
  • Page 47 BIOS Setup 3-21 User’s Manual...

  • Page 48: Security Menu

    This option protects the BIOS configuration or restricts access to the computer itself. The User Password requires all users to enter a password in order to use the system, and/or enter the BIOS setup (but can’t change its contents). WI-2Pa...

  • Page 49: Pc Health Menu

    BIOS Setup 3-23 3.4. PC Health Menu CPU Shutdown Temperature: Once the system or CPU temperature exceeds the temperature specified, the CPU will shutdown automatically to avoid damaging. This function only works for an ACPI OS such as Windows 98/ Windows 2000 with ACPI activated. The options are Disabled, 70°C/158°F, 75°C/167°F, 80°C/176°F, and 85°C/185°F.
  • Page 50 NOTE: The hardware monitoring features for temperatures, fans and voltages will occupy the I/O address from 294H to 297H. If you have a network adapter, sound card or other add-on cards that might use those I/O addresses, please adjust your add-on card I/O address to avoid using these addresses. WI-2Pa...

  • Page 51: Clk/Misc. Menu

    BIOS Setup 3-25 3.5. Clk/Misc. Menu CPU Clock Ratio This option selects the CPU clock ratio. Please type in the correct multiple for your CPU. Case-Open Detection This option controls the function for case-opening detection via JP3 header. BIOS Protect Control This option protects for accidentally BIOS writing attempt.

  • Page 52: Exit Menu

    This option loads the BIOS default values that are factory settings for optimal-performance system operations. Save & Exit Setup This option saves your selections and exits the setup menu. Exit Without Saving This option exits the setup menu without saving any change. WI-2Pa...

  • Page 53: Chapter 4. Driver Installation

    Driver Installation Chapter 4. Driver Installation After all the hardware has been installed, you must first install the operating system and then the software drivers. The necessary drivers are all included within the Drivers & Utilities CD that came packaged with your workstation board. The display shown in the following figure should appear after inserting this CD into your CD-ROM drive, if not, enter [My Computer]...
  • Page 54 A self-diagnostic system to protect hardware by monitoring several critical items including fan speed, voltages, CPU and system temperature. (Only supported in the Xeon processor type of 604-pin package) • Browse CD Browse the contents of this CD-ROM. • Close Exit the CD setup items. WI-2Pa...

  • Page 55: Appendix A. Trouble Shooting

    Trouble Shooting Appendix A. Trouble Shooting Why the system shows incorrect CPU speed in Win2K If you run Msinfo32.exe on a computer that has an Intel Pentium 4 Xeon 2.2-GHz or faster processor, a very high processor speed may be shown. The Processor information on the System Summary page shows the correct name, family, model and stepping for the processor, but the approximate speed may be 37,000 MHz or faster.
  • Page 56 Open the Boot.ini file, and then add the /PAE parameter to the ARC path, as shown in bold format in the following example: multi(0)disk(0)rdisk(0)partition(2)\WINNT= “Windows 2000 Advanced Workstation” /PAE /basevideo /sos On the File menu, click Save. Restore the read-only attribute to the Boot.ini file. WI-2Pa...
  • Page 57 Trouble Shooting Even with PAE enabled, the underlying architecture of the system is still based on 32-bit linear addresses. This effectively retains the 2GB of application space and the 2GB of kernel mode space because only 4GB of addresses are available. However, multiple processes can immediately benefit from the increased RAM because they are less likely to encounter physical memory restrictions and begin paging.
  • Page 58 Appendix A Appendix A WI-2Pa WI-2Pa...

  • Page 59: Appendix B. How To Get Technical Support

    3. Check the ABIT Technical Terms Guide and FAQ on our Website. We are trying to expand and make the FAQs more helpful and information rich. Let us know if you have any suggestions.
  • Page 60 How they serve you is also a good reference for your next purchase. 6. Contacting ABIT. If you feel that you need to contact ABIT directly you can send email to the ABIT technical support department. First, please contact the support team for the branch office closest to you.
  • Page 61 Stevenage, Herts SG1 4QX, U.K. Tel: 44-1438-228888 Fax: 44-1438-226333 sales@abitcomputer.co.uk technical@abitcomputer.co.uk Germany, Benelux (Belgium, Netherlands, Luxembourg), Denmark, Norway, Sweden, Finland, and Switzerland: AMOR Computer B.V. (ABIT’s European Office) Van Coehoornstraat 7, 5916 PH Venlo, The Netherlands Tel: 31-77-3204428 Fax: 31-77-3204420 sales@abit.nl technical@abit.nl...
  • Page 62 Appendix B Japan: ABIT Computer (Japan) Co. Ltd. Fax: 81-3-5396-5110 http://www.abit4u.jp Shanghai: ABIT Computer (Shanghai) Co. Ltd. Tel: 86-21-6235-1829 Fax: 86-21-6235-1832 http://www.abit.com.cn Russia: ABIT Computer (Russia) Corporation Ltd. Fax: 7 (095) 937 8237 http://www.abit.ru France: ABIT Computer France SARL 4, Place La Defense,...
  • Page 63 Please contact the reseller from whom you bought the product. You should be able to get RMA service there. 8. Reporting Compatibility Problems to ABIT. Because of tremendous number of email messages we receive every day, we are forced to give greater weight to certain types of messages than to others.
  • Page 64 Appendix B Technical Support Form Company Name: Phone Number: Contact Person: Fax Number: E-mail Address: Model BIOS ID # Motherboard Model No. DRIVER REV OS/Application Hardware Name Brand Specifications IDE1 IDE2 IDE1 CD-ROM-Drive IDE2 System Memory ADD-ON CARD Problem Description: WI-2Pa...
