MULTIQUIP Power DCA85USJ2 Operation And Parts Manual page 73

NO. PART NO.
31 M4266600004
32 0027105016
33 0601802218
33A 0601806653
33B 0601802149
34 0027103020
35 M3213500704
36 0016906016
37 M2270100204
37A M2550001404
37B M2550001504
38 M3213602704
39 M3213602804
40 0027104035
40A 0207004000
41 0027104016
41A 0207004000
42 0016906016
43 M2213603104
43-1 0317700180
44 M2213603004
45 0016906016
46 0016908020
46A 0040508000
47 M2223001203
47 M2223001213
48 0601807641
49 0601808988
50 0601801040
51 0601806859
52 0601801041
53 0601840073
56 0021004040
56A 0207004000
57 0601831340
58 0602103092
58A 0601810245
59 0602120096
60 0602122093
61 0602123092
62 0602121081
63 0602125090
64 0601810141
65 0601831330
66 0601831395
67 M122310004
DCA85USJ2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (03/22/11) — PAGE 73
CONTROL BOX ASSY. (CONTINUED)
PART NAME
RESISTOR UNIT
MACHINE SCREW
HOLDER, FUSE
FUSE (RIGHT SIDE), 20A
FUSE ( CENTER), 10A
MACHINE SCREW
CONTROL BOX COVER
HEX HEAD BOLT
SELECTOR SWITCH
DECAL : SELECTOR SWITCH NO
DECAL : SELECTOR SWITCH NO
SWITCH BRACKET
SWITCH BRACKET
MACHINE SCREW
HEX NUT
MACHINE SCREW
HEX NUT
HEX HEAD BOLT
SWITCH COVER
WEATHER STRIP
SWITCH COVER
HEX HEAD BOLT
HEX HEAD BOLT
TOOTHED WASHER
CONTROL PANEL ......................................1 ................S/N 8400985 AND BELOW
CONTROL PANEL ......................................1 ................S/N 8400986 AND ABOVE
FREQUENCY METER, 45~65Hz 240V
AC AMMETER, 0~200A/400A:5A
CHANGE - OVER SWITCH, AMMETER
AC VOLTMETER, 0~600V
CHANGE - OVER SW, VOLTMETER
RHEOSTAT, 2W 1k OHM
MACHINE SCREW
HEX NUT
SWITCH
ALARM LAMP
BULB, DC18V
TACHOMETER
OIL PRESSURE GAUGE
WATER TEMPERATURE GAUGE
CHARGING AMMETER
FUEL GAUGE
PANEL LIGHT
SWITCH, PANEL LIGHT
SWITCH, ENGINE SPEED
STOPPER
QTY. REMARKS
1
1
1
1
1
2
1
8
1
1
1
1
1
4
4
4
4
4
1
1
1
10
10
1
1
1
1
1
1
1
2
2
1
4
4
1
1
1
1
1
1
1
1
1
