11. Touch the "Enter Button" to deselect the selected
parameter removing it from the list of parameters being
displayed on the 1-up display.
ENGINE SPEED
PERCENT LOAD AT CURRENT RPM
ENGINE OIL PRESSURE
ENGINE COOLANT TEMPERATURE
12. Use the "Arrow Button" to scroll and highlight the
desired parameter that has not been selected for
display.
ENGINE SPEED
PERCENT LOAD AT CURRENT RPM
ENGINE OIL PRESSURE
ENGINE COOLANT TEMPERATURE
13. Touch the "Enter Button" to select the highlighted
parameter for inclusion in the Single Engine Parameter
Display.
ENGINE SPEED
PERCENT LOAD AT CURRENT RPM
ENGINE OIL PRESSURE
ENGINE COOLANT TEMPERATURE
14. Continue to scroll and select additional parameters for
the custom 1-up Display. Touch the "Menu Button" at
any time to return to the "Custom Setup" menu.
15. Automatic Scan- Selecting the scan function will cause
the 1-Up Display to scroll through the selected set of
parameters one at a time. Use the "Arrow Buttons" to
scroll to the "Automatic Scan" function.
USE DEFAULTS
CUSTOM SETUP
AUTOMATIC SCAN OFF
DCA85USJ2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (03/22/11) — PAGE 29
1
3
2
2
1
Note that the numbers
now indicate the new order
of display for the parameters.
2
1
3
DIAGNOSTIC DISPLAY
16. Touching the "Enter Button" toggles the "Automatic
Scan" function on.
USE DEFAULTS
CUSTOM SETUP
AUTOMATIC SCAN ON
17. Touching the "Enter Button" again toggles the
"Automatic Scan" function off.
USE DEFAULTS
CUSTOM SETUP
AUTOMATIC SCAN OFF
18. Once the "Use Defaults", "Custom Setup" and
"Automatic Scan" functions have been set touch the
"Menu Button" to return to the main menu.
USE DEFAULTS
CUSTOM SETUP
AUTOMATIC SCAN ON
19. Touch the "Menu Button" to exit the Main menu and
return to the engine parameter display.
GO TO 1-UP DISPLAY
STORED CODES
ENGINE CONF G
SETUP 1-UP DISPLAY
SETUP-4-UP DISPLAY
SELECT UNITS
ADJUST BACKLIGHT
0 3000
1500
1800 RPM
ENG RPM COOL TEMP
