OPERATION AND PARTS MANUAL
WHISPERWATT™ SERIES
MODEL DCA400SSI
60HZ GENERATOR
(ISUZU 6WG1X DIESEL ENGINE)
PARTS LIST NO. C3871301004
Revision #2 (11/03/08)
To fi nd the latest revision of this
publication, visit our website at:
www.mqpower.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
