OperatiOn anD parts ManUaL
WhisperWatt™ series
MODeL Dca300ssc
MODeL Dca300sscU
60hz generatOr
(cUMMins qsL9-g3 DieseL engine)
parts List nO. c2870300204 — Dca300ssc
parts List nO. c2870300104a — Dca300sscU
Revision #1 (08/10/11)
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WhisperWatt DCA300SSC and is the answer not in the manual?

Questions and answers

Related Manuals for MULTIQUIP WhisperWatt DCA300SSC

Summary of Contents for MULTIQUIP WhisperWatt DCA300SSC

  • Page 1 WhisperWatt™ series MODeL Dca300ssc MODeL Dca300sscU 60hz generatOr (cUMMins qsL9-g3 DieseL engine) parts List nO. c2870300204 — Dca300ssc parts List nO. c2870300104a — Dca300sscU Revision #1 (08/10/11) To find the latest revision of this publication, visit our website at: www.multiquip.com...

  • Page 2: Proposition 65 Warning

    65 Warning Diesel engine exhaust and some of page 2 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 3: Reporting Safety Defects

    327-4236 (TTY: 1-800-424-9153), go to http://www.nhtsa.dot.gov; or write to: Administrator NHTSA 1200 New Jersey Avenue S.E. Washington, DC 20590 You can also obtain information about motor vehicle safety from http://www.safecar.gov. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 3...

  • Page 4: Table Of Contents

    Troubleshooting (Generator) ........50 Troubleshooting (Engine Controller) ...... 51 Troubleshooting (Diagnostic lamp) ......52 Explanation of Code in Remarks Column....54 Suggested Spare Parts ......... 55 page 4 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 5: Parts Ordering Procedures

    All orders are treated as Standard Orders and will ship the same day if received prior to 3PM PST. WE ACCEPT ALL MAJOR CREDIT CARDS! DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 5...

  • Page 6: Safety Information

    CaUtion Indicates a hazardous situation which, if not avoided, CoUlD result in minor or moDerate inJUrY. NOTICE Addresses practices not related to personal injury. page 6 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 7: General Safety

    „ alWaYS store equipment properly when it is not being used. Equipment should be stored in a clean, dry location out of the reach of children and unauthorized personnel DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 7...

  • Page 8: Engine Safety

    „ never touch the hot exhaust manifold, local Health and Safety Administrator. muffl er or cylinder. Allow these parts to cool before servicing equipment. page 8 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 9: Towing Safety

    „ Use the trailer’s swivel jack to adjust the trailer height to „ alWaYS shutdown engine before transporting a level position while parked. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 9...

  • Page 10: Electrical Safety

    „ never grab or touch a live power cord or cable with wet hands. The possibility exists of electrical shock, electrocution or death. page 10 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 11 „ alWaYS disconnect the negative battery terminal before performing service on the generator. „ alWaYS keep battery cables in good working condition. Repair or replace all worn cables. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 11...

  • Page 12: Specifications

    19.0 gal. (72.0 L)/hr at full load 15.5 gal. (58.6 L)/hr at 3/4 load Fuel Consumption 11.1 gal. (41.9 L)/hr at 1/2 load 5.9 gal. (22.4 L)/hr at 1/4 load Battery 150 Ah x 2 (24V System) page 12 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 13: Dimensions

    149.61 in. (3,800 mm) 23.03 in. (585 mm.) 70.87 in. (1,800 mm) 25.20 in. (640 mm) 55.12 in. (1,400 mm) 39.76 in. (1,010 mm) DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 13...

  • Page 14: Installation

    Figure 2. Typical Generator Grounding Application page 14 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 15 They are to resist damage to the bottom of the generator and to maintain alignment. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 15...

  • Page 16: General Information

    (load) is held to „ Water Heater (Optional) a minimum. Use the cable selection chart (Table 6) as a guide for selecting proper extension cable size. page 16 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 17: Major Components

    Enclosure Assembly Generator Assembly Output Terminal Assembly Battery Assembly Fuel Tank Assembly Generator Control Panel Assembly Engine Operating Panel Assembly Figure 3. Major Components DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 17...

  • Page 18: Generator Control Panel

    11. Frequency meter — Indicates the output frequency controller’s over Crank protection mode. If the in hertz (Hz). Normally 60 Hz engine engages at a speed (RPM’s) that is not safe, page 18 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 19 Located behind the generator control panel is the generator Control Box. This box contains some of the necessary electronic components required to make the generator function. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 19...

  • Page 20: Engine Operating Panel

    When the cause damage to the electrical equipment. auto-oFF/reset-manual switch is set page 20 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 21 DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 21...

  • Page 22: Output Terminal Panel Familiarization

    „ Two (2) GFCI Circuit Breakers @ 20 amps „ Eight (8) Output Terminal Lugs ( U, V, W, O, Ground) Figure 6. Output Terminal Panel page 22 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 23 These receptacles can only be accessed when the voltage change-over board is configured for single-phase 240/120 application Figure 8. 120/240V Twist-Lock Auxiliary Receptacles DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 23...

  • Page 24: Output Terminal Panel Familiarization

    800A main circuit breaker is provided. Make sure to switch all circuit breakers to the oFF position prior to starting the engine. Figure 11. Over Current Relay Figure 10. Connecting Loads page 24 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 25: Load Application

    1800 3600 150 ft. 100 ft. 65 ft. 2400 4800 125 ft. 75 ft. 50 ft. CAUTION: Equipment damage can result from low voltage DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 25...

  • Page 26: Generator Outputs

    480V 3Ø line-line 1Ø line-neutral 120V 127V 139V 240V 254V 277V voltage Change-over Board Single-phase 240/120v position 1Ø line-neutral/ 120V 240V Line-Neutral Line-Line line-line page 26 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 27: Generator Outputs/Gauge Reading

    W and U terminals as indicated on the AC Voltmeter Gauge (Figure 15). Figure 14. AC Voltmeter Figure 15. AC Voltmeter Gauge Change-Over Switch (Volt reading on W-U Lug) DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 27...

  • Page 28: Output Terminal Panel Connections

    3. Connect the load wires to the UVWO terminals as shown in Figure 22. Figure 19. UVWO Terminal Lugs 1Ø-120V Figure 22. UVWO Terminal Lugs Connections page 28 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 29: Output Terminal Panel Connections

    UVWO terminals are secure and tight. The possibility of arcing exists, that could cause a fire. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 29...

  • Page 30: Inspection/Setup

    „ API Service Classification CC/SD „ API Service Classification CC/SE „ API Service Classification CC/SF table 9. recommended motor oil Figure 28. Internal Fuel Tank System page 30 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 31 #2 diesel fuel when refueling. CaUtion Do not overFill fuel system. Leave room for fuel expansion. Fuel expands when heated (Figure 32). Figure 32. Fuel Expansion DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 31...

  • Page 32: Air Cleaner

    Freezing Point Vol % Anti-Freeze °C °F NOTICE When the antifreeze is mixed with water, the antifreeze mixing ratio must be less than 50%. page 32 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 33: Inspection/Setup

    Tighten all hose clamps and check hoses for leaks. Figure 34. Battery Connections If any hose (fuel or oil) lines are defective replace them immediately. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 33...

  • Page 34: Genertor Start-Up Procedure (Manual)

    (Figure 41) is on (lit) after the engine has been started. CORRECT INCORRECT Figure 36. Engine Enclosure Doors Figure 41. Engine Running LED (ON) page 34 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 35 28 to 85 15. The generator will run until manually stopped or an abnormal condition occurs. psi. (193~586 kPa). Figure 46. Oil Pressure Gauge DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 35...

  • Page 36: Generator Start-Up Procedure (Auto Mode)

    When the MPEC control switch is placed in the aUto position, the engine glow plugs will be warmed and the engine will start automatically. page 36 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 37: Generator Shut-Down Procedures

    6. Remove all loads from the generator. 7. Inspect entire generator for any damage or loosening of components that may have occurred during operation. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 37...

  • Page 38: Maintenance

    After changing the air element, press the dust indicator button to reset the indicator. page 38 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 39 See the Cummins engine manual for details. Figure 57. Fuel Tank Cleaning DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 39...

  • Page 40: Check Oil Level

    Warning Allow engine to cool when flushing out radiator. Flushing the radiator while hot could cause serious burns from water or steam. page 40 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 41 Figure 59. Battery Charger and Jacket Water Heater Power Connections DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 41...

  • Page 42: Trailer Maintenance

    16. Application — Indicates which units can be employed on a particular trailer. 7. Coupler — Type of hitch used on the trailer for towing. page 42 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 43: Brake Adjustment

    Brake lining thickness incorrect or not adjusted correctly? linings. Dragging Brakes Replace rubber parts Enough brake fluid or correct fluid? fill with dot 4 fluid. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 43...
  • Page 44 Align wheels. Check bearing adjustment Cupping Out-of-balance. and balance tires. Wheel lockup and Avoid sudden stops when Flat Spots tire skidding. possible and adjust brakes. page 44 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 45: Trailer Maintenance

    90-120 16" 20-25 50-60 90-120 Figure 62. Wheel Lug Nuts Tightening Sequence NOTICE never use an pneumatic air gun to tighten wheel lug nuts. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 45...

  • Page 46: Trailer Wiring Diagram

    Wiring DiagraM Figure 63. Trailer/Towing Vehicle Wiring Diagram page 46 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 47: Generator Wiring Diagram

    Wiring DiagraM Figure 64. Generator Wiring Diagram DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 47...

  • Page 48: Engine Wiring Diagram

    Wiring DiagraM Figure 65. Engine Wiring Diagram page 48 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 49: Controller Wiring Diagram

    DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 49...

  • Page 50: Troubleshooting (Generator)

    Over current? Confirm load requirements and reduce. Circuit Breaker Tripped Defective circuit breaker? Check and replace. Over current Relay actuated? Confirm load requirement and replace. page 50 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 51: Troubleshooting (Engine Controller)

    Magnetic pick up out of adjustment? Adjust magnetic pick up. Loss of MPU light(s) or on. Magnetic pick up dirty? Clean magnetic pick up. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 51...

  • Page 52: Troubleshooting (Diagnostic Lamp)

    “ON” position, the engine will not be stopped even if the starter switch is turned to the “OFF” position. In such case, turn the diagnostic switch to the “OFF” position.. page 52 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 53 DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 53...

  • Page 54: Explanation Of Code In Remarks Column

    Multiquip. Other entries will for sale through Multiquip. be clarifi ed in the “Remarks” Column. page 54 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 55: Suggested Spare Parts

    1....0601808804 ..CIRCUIT BREAKER 2P 50A 2....LY2DUS24VDC ..RELAY NOTICE Part number on this Suggested Spare Parts list may supersede/replace the P/N shown in the text pages of this book. DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 55...

  • Page 56: Generator Assembly

    56 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 57 WASHER, LOCK 0041210000 WASHER, FLAT 0017112045 HEX HEAD BOLT C3154300104 COVER, BEARING C3154300004 GASKET, BEARING 0010106060 HEX HEAD BOLT 0040006000 WASHER, LOCK 0041206000 WASHER, FLAT DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 57...
  • Page 58 (cOntinUeD) page 58 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 59 HEX HEAD BOLT 0042512000 WASHER, LOCK C3132300014 COVER, FAN 0010106030 HEX HEAD BOLT 0041206000 WASHER, FLAT 0600815000 0605000012 RUBBER SUSPENSION 0030020000 HEX NUT 0040020000 WASHER, LOCK DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 59...

  • Page 60: Control Box Assembly

    60 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 61 SOCKET ............4 ....REPLACES P/N 0601823109 PYCA1 HOLDER .............4 ....REPLACES P/N 0601824400 0027104020 MACHINE SCREW 0601823240 RECTIFIER 0027104020 MACHINE SCREW M5260500204 BRACKET 0602103090 DIAGNOSTIC LAMP 0027104020 MACHINE SCREW DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 61...
  • Page 62 (cOntinUeD) page 62 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 63 HEX HEAD BOLT C2214300004 SIDE PANEL, CONTROL BOX 0017108020 HEX HEAD BOLT C2214400504 PANEL, CONTROL BOX 0017108020 HEX HEAD BOLT 0017110025 HEX HEAD BOLT DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 63...

  • Page 64: Engine And Radiator Assembly

    64 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 65 0602014821 INTER-COOLER PIPE 0602013261 INTER-COOLER PIPE 0602015124 INTER-COOLER PIPE 0602015303 HOSE BAND 0602022563 ADAPTER 0602022561 90 DEGREE ELBOW 0603306590 CONNECTOR 0603300285 LOCKNUT 0605511395 VALVE DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 65...
  • Page 66 (cOntinUeD) page 66 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 67 WATER TEMPERATURE SWITCH 0602120481 PICK- UP TACHOMETER 4993343 ALTERNATOR 3102763 STARTER 3973114 WATER PUMP 3940632 THERMOSTAT W/O 3945603 GASKET, THERMOSTAT 4921744 SENSOR, OIL PRESSURE DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 67...

  • Page 68: Engine Operating Panel Assembly

    Operating paneL assy. page 68 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 69 HEX HEAD BOLT ..........2 ...DCA300SSC 0016910030 HEX HEAD BOLT ..........2 ...DCA300SSCU 0017110030 HEX HEAD BOLT 0030010000 HEX NUT 0040010000 WASHER, LOCK 0041610000 WASHER, FLAT DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 69...

  • Page 70: Output Terminal Assembly

    OUtpUt terMinaL assy. page 70 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 71 M9310200004 STAY RUBBER ..........2 ....DCA300SSCU 0205012000 HEX NUT 0845043704 SPRING ............2 ....DCA300SSC M9210000204 SPRING ............2 ....DCA300SSCU C2237101204 COVER ............1 ....DCA300SSC M5236100204 COVER ............1 ....DCA300SSCU DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 71...
  • Page 72 OUtpUt terMinaL assy. page 72 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 73 BRACKET ...........1 ....DCA300SSC M4236400304 BRACKET ...........1 ....DCA300SSCU 0017106020 HEX HEAD BOLT ........2 ....DCA300SSC 0016906016 HEX HEAD BOLT ........2 ....DCA300SSCU 7538070 MACHINE SCREW ........4 ....DCA300SSCU DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 73...
  • Page 74 (Dca300ssc) page 74 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 75: Battery Assembly (Dca300Ssc)

    HEX NUT 0845040414 TERMINAL CAP (+) 0845041304 TERMINAL CAP (-) 0017116030 HEX HEAD BOLT 0040516000 TOOTHED WASHER 0017112025 HEX HEAD BOLT 0040512000 TOOTHED WASHER DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 75...
  • Page 76 (Dca300sscU) page 76 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 77: Battery Assembly (Dca300Sscu)

    BATTERY CABLE M4346400314 BATTERY CABLE M5346900504 BATTERY CABLE M5346200104 EARTH CABLE 0017116030 HEX HEAD BOLT 0040516000 TOOTHED WASHER 0017112025 HEX HEAD BOLT 0040512000 TOOTHED WASHER DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 77...

  • Page 78: Muffler Assy

    MUffLer assy. page 78 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 79: Muffler Assembly

    HEX NUT .............4 ....DCA300SSC 0042512000 WASHER, LOCK .........4 ....DCA300SSC 0041612000 WASHER, FLAT ..........8 ....DCA300SSC C2331300004 COVER ............2 ....DCA300SSC M5331300004 COVER ............2 ....DCA300SSCU 0017108020 HEX HEAD BOLT DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 79...
  • Page 80 (Dca300ssc) page 80 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 81: Fuel Tank Assembly (Dca300Ssc)

    0603325026 VALVE 0132006000 PLUG, 1/2" C1367700304 LOCK PLATE 0019208020 HEX HEAD BOLT 0845039604 RUBBER SEAL 0191503400 SUCTION HOSE 0191503700 RETURN HOSE 0605515073 HOSE BAND DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 81...
  • Page 82 (Dca300sscU) page 82 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 83 O-RING 0016908020 HEX HEAD BOLT M1363400104 DRAIN HOSE 0605515198 HOSE BAND 0602042682 CONNECTION 0602042683 CONNECTION 0191503400 HOSE, SUCTION 0191503700 HOSE, RETURN 0605515198 HOSE BAND DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 83...

  • Page 84: Enclosure Assy

    84 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)

  • Page 85: Enclosure Assembly

    ACOUSTIC SHEET ........1 ....DCA300SSC M5494101604 ACOUSTIC SHEET ........1 ....DCA300SSCU 0019208020 HEX HEAD BOLT 0845042703 FILLER BRACKET ........1 ....DCA300SSC 0019208020 HEX HEAD BOLT ........4 ....DCA300SSC M5433000002 CENTER FRAME DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 85...
  • Page 86 (cOntinUeD) page 86 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 87 WINDOW PLATE .........2 ....DCA300SSCU 0207306000 SELF- LOCKING U-NUT 0041206000 WASHER, FLAT B9114000102 DOOR HANDLE ..........1 ....DCA300SSC M9113000202 DOOR HANDLE ..........1 ....DCA300SSCU 0021806016 MACHINE SCREW 0030006000 HEX NUT DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 87...
  • Page 88 (cOntinUeD) page 88 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 89 ACOUSTIC SHEET ........1 ....DCA300SSC M5493502004 ACOUSTIC SHEET ........1 ....DCA300SSCU M5423200103 COVER, FRONT FRAME 0019208020 HEX HEAD BOLT M5453200002 SPLASHER PANEL 0019208065 HEX HEAD BOLT DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 89...
  • Page 90 (cOntinUeD) page 90 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 91 GUTTER ............2 C2464500304 GUTTER ............2 ....DCA300SSC M5463500104 GUTTER ............2 ....DCA300SSCU 0019208020 HEX HEAD BOLT 0019116025 HEX HEAD BOLT ........1 ....DCA300SSCU 0042416000 WASHER, FLAT ..........1 ....DCA300SSCU DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 91...

  • Page 92: Rubber Seals Assembly

    92 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 93 0228900710 SEAL RUBBER 0229201300 SEAL RUBBER 0221200705 SEAL RUBBER 0228801210 SEAL RUBBER 0228100510 SEAL RUBBER 0228100120 SEAL RUBBER 0229200470 SEAL RUBBER 0229201130 SEAL RUBBER DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 93...

  • Page 94: Nameplt.and Decals Assy. (Dca300Ssc)

    DecaLs assy. (Dca300ssc) page 94 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 95 DECAL : WARNING ELECTRIC SHOCK HAZARD ..1 ....B93110050 C0551000404 DECAL : 3- PHASE OUTPUT TERMINAL ....1 ....C05100040 C1551000803 DECAL : RECEPTACLE & CIRCUIT BREAKER ..1 ....C15100080 DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 95...
  • Page 96 DecaLs assy. (cOntinUeD Dca300ssc) page 96 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 97 STRIPE 9-12 M5560101203 STRIPE 9-13 C9504000304 DECAL : CAUTION ..........1 ...... C90400030 9-14 M9504200004 DECAL : WARNING START FIRES ......1 ...... M90420000 DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 97...

  • Page 98: Nameplt. And Decals Assy. (Dca300Sscu)

    DecaLs assy. (Dca300sscU) page 98 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 99 DECAL : 3-PHASE OUTPUT TERMINAL ....1 ....M92000070 M9520100404 DECAL : DANGER HIGH VOLTAGE ......1 ....M92010040 M9520100503 DECAL : WARNING ELECTRIC SHOCK HAZARD ..1 ....M92010050 DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 99...
  • Page 100 DecaLs assy. (cOntinUeD Dca300sscU) page 100 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 101 DECAL : WARNING START FIRES ......1 ...... M90420000 9-11 M9510000104 DECAL : DOCUMENT BOX LOCATED ....1 ...... M91000010 9-12 M9512000004 DECAL : SUPPORT HOOK ........2 ...... M91200000 DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 101...

  • Page 102: Terms And Conditions Of Sale - Parts

    Multiquip’s designated receiving point. page 102 — DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11)
  • Page 103 DCa300SSC / DCa300SSCU gen. • operation anD partS manUal — rev. #1 (08/10/11) — page 103...
  • Page 104 © COPYRIGHT 2011, MULTIQUIP INC. Multiquip Inc and the MQ logo are registered trademarks of Multiquip Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their respective owners and used with permission.
