XC90 Owners Manual WEB EDITION...
Page 3 Volvo is one of the safest cars in mation contained in this owner's manual. the world. Your Volvo has also been designed to satisfy all current safety and environmental requirements.
Page 4: Table Of Contents
01 Safety 02 Instruments and controls Important information......... 8 Seatbelts........... 18 Overview, left-hand drive car....50 Volvo and the environment....... 12 Symbols, airbags........21 Overview, right-hand drive car....52 Airbags............22 Driver's door control panel....... 54 Activating/deactivating the airbag*... 24 Combined instrument panel......
Page 5 Table of contents 03 Climate control 04 Interior 05 Locks and alarm General information on climate control..92 Front seats..........104 Remote control key - key with remote control............. 128 Electronic Climate Control, ECC....95 Front seats - Executive ......107 Locking and unlocking......
Page 6 Table of contents 06 Starting and driving 07 Wheels and tyres 08 Car care General............ 140 General............ 184 Cleaning..........200 Refuelling..........143 Tyre pressure.......... 187 Touching up paintwork......204 Starting the engine........149 Warning triangle* and spare wheel*..188 Rustproofing........... 206 Automatic gearbox........
Page 7 Table of contents 09 Maintenance and service 10 Infotainment system 11 Specifications Volvo service........... 210 General............ 244 Type designation........286 Self-maintenance........211 Control panels, audio......245 Dimensions and weights......288 Bonnet and engine compartment... 213 Audio system functions......248 Engine specifications......291 Oils and fluids.........
Page 8 Table of contents 12 Alphabetical Index Alphabetical Index........306...
Page 9 Table of contents...
Page 10: Introduction
Important information Reading the Owner's Manual In the event of uncertainty over what is stand- lighted in the owner's manual by means of ard or an option/accessory, contact a Volvo the text being slightly larger and printed in Introduction dealer.
Page 11 Introduction Important information Information Procedure lists which, if the warning is ignored, may result in serious personal injury or fatality. Procedures where action must be taken in a certain sequence are numbered in the Risk of property damage owner's manual. When there is a series of illustrations for step-by-step instructions each step is numbered in the same way as the corres-...
Page 12 This informa- Recording data function when their associated software is tion may be stored by Volvo as long as it can installed in the car's computer system. We Your vehicle contains a number of computers...
Page 13 Volvo On Call is a supplemental service that consists of safety, security and comfort serv- ices. If the car has Volvo On Call and there is a change of owner, it is very important that these services are discontinued so that the former owner cannot access the services in the car.
Page 14: Volvo And The Environment
Introduction Volvo and the environment Volvo Cars' environmental philosophy Efficient emission control Environmental care is one of Volvo Car Cor- for our partners so that they work systemati- poration's core values which influence all cally with environmental issues. Your Volvo is manufactured following the operations.
Page 15 Interior instructions - follow the Service and War- referral to a certified/approved recycling ranty Booklet's recommended intervals. The interior of a Volvo is designed to be plea- facility. sant and comfortable, even for people with • If the car is equipped with an engine contact allergies and for asthma sufferers.
Page 16 Introduction Volvo and the environment...
Page 17 Introduction...
Page 18 Seatbelts....................18 Symbols, airbags..................21 Airbags....................22 Activating/deactivating the airbag*............24 Side airbags (SIPS bags)................ 26 Inflatable Curtain (IC)................28 WHIPS..................... 29 Roll-over protection - ROPS..............31 When the systems deploy............... 32 Child safety..................... 34 Option/accessory, for more information, see Introduction.
Page 19 S A F E T Y...
Page 20: 01 Safety
Volvo recommends that you contact • if it is pulled out too quickly an authorised Volvo workshop. If a seat- • during braking and acceleration belt has been subjected to a major load, such as in conjunction with a collision, the •...
Page 21 01 Safety Seatbelts Seatbelts and pregnancy such that they can easily maintain full control in the roof console and in the combined of the vehicle as they drive (which means they instrument panel. must be able to easily operate the foot pedals and the steering wheel).
Page 22 01 Safety Seatbelts WARNING Never insert the tongue of the passenger's seatbelt into the buckle on the driver's side. Always insert the tongue of the seat- belt into the buckle on the correct side. Do not make any damages on seatbelts nor insert any foreign objects into a buckle.
Page 23: Symbols, Airbags
The warning symbol in the combined instru- SIPS or the IC system. Volvo recommends ment panel illuminates when the remote con- that you contact an authorised Volvo trol key is turned to key position I, II or III.
Page 24: Airbags
Airbag system, left-hand drive car. WARNING The system consists of airbags and sensors. Volvo recommends that you contact an A sufficiently violent collision trips the sensors authorised Volvo workshop for repair. and the airbag(s) are inflated with hot gas. To...
Page 25 01 Safety Airbags WARNING WARNING Do not put objects in front of or above the To minimise the risk of injury if the airbag instrument panel where the passenger air- deploys, passengers must sit as upright as bag is located. possible with their feet on the floor and backs against the backrest.
Page 26: Activating/Deactivating The Airbag
128. Visit a workshop as soon as possible. booster cushion. Volvo recommends that you contact an The airbag is deactivated. With the switch authorised Volvo workshop WARNING in this position, children in a child seat or...
Page 27 01 Safety Activating/deactivating the airbag* Message WARNING Activated airbag (passenger seat): Never place a child in a child seat or on a booster cushion on the front passenger seat when the airbag is activated. This applies to everyone shorter than 140 cm. Deactivated airbag (passenger seat): No one taller than 140 cm should ever sit in the front passenger seat when the air-...
Page 28: Side Airbags (Sips Bags)
01 Safety Side airbags (SIPS bags) Side airbag Location Front passenger seat, left-hand drive Driver's seat, left-hand drive Side airbag locations. The SIPS bag system consists of side airbags and sensors. A sufficiently violent collision In a side impact collision a large proportion of trips the sensors and the side airbags are the collision force is transferred by the SIPS inflated.
Page 29 01 Safety Side airbags (SIPS bags) WARNING • Volvo recommends that repairs are only carried out by an authorised Volvo workshop. Defective work in the SIPS- bag system could cause malfunction and result in serious personal injury. • Do not put objects in the area between...
Page 30: Inflatable Curtain (Ic)
This could compromise the intended protection. Volvo recommends that you only ever use Volvo genuine parts that are approved for placement in these areas. WARNING Do not load the car higher than 50 mm under the top edge of the side windows.
Page 31: Whips
The WHIPS system is a supplement to the system yourself. Volvo recommends that sible between the head and the head seatbelts. Always use a seatbelt. you contact an authorised Volvo work- restraint. shop.
Page 32 If a seat has been subjected to extreme forces, such as due to a rear-end collision, the WHIPS system must be checked. Volvo recommends that you contact an authorised Volvo workshop. Part of the WHIPS system's protective capacity may have been lost even if the seats appear to be undamaged.
Page 33: Roll-Over Protection - Rops
01 Safety Roll-over protection - ROPS Function WARNING Volvo's Roll-Over Protection System (ROPS) Under normal driving conditions, the RSC has been designed to reduce the risk of the system improves the car's road safety, but car overturning and to provide the best possi-...
Page 34: When The Systems Deploy
Volvo workshop for repair. Do not liquid, disconnect the battery cables. Do not attempt to start the car since the air- drive with deployed airbags.
Page 35 01 Safety When the systems deploy WARNING Never drive with deployed airbags. They can make steering difficult. Other safety systems may also be damaged. The smoke and dust created when the airbags are deployed can cause skin and eye irrita- tion/injury after intensive exposure.
Page 36: Child Safety
Volvo's own child safety equipment is Child seats and airbags are not compatible. designed for your car. Volvo recommends that you use Volvo genuine equipment to best NOTE ensure that the mounting points and attach- When using other child safety products it...
Page 37 Recommended child seats Weight Front seat (with deactivated airbag) Group 0 Volvo infant seat (Volvo Infant Seat) - rear-facing child seat, secured with the car's seatbelt <10 kg Type approval: E1 04301146 Group 0+ <13 kg Group 0 Rear-facing child seat (Child Seat) - rear-facing child seat, secured with the car's seatbelt and straps.
Page 38 Child seats which are universally approved. <10 kg Group 0+ <13 kg Group 1 Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear-facing child seat, secured with the car's seatbelt and straps. 9-18 kg Type approval: E5 04192 Group 1 Rear-facing child seat (Child Seat) - rear-facing child seat, secured with the car's seatbelt and straps.
Page 39 15-36 kg Type approval: E5 04216 (UF) Group 2/3 Volvo booster seat with backrest (Volvo Booster Seat with backrest). 15-36 kg Type approval: E1 04301169 (UF) L: Suitable for specific child seats. These child seats may be intended for use in a special car model, limited or semi-universal categories.
Page 40 Second row of seats, centre seat seats in cars seating seven Group 0 Volvo infant seat (Volvo Infant Seat) - rear-facing child seat, Volvo infant seat (Volvo Infant Seat) - rear- secured with the car's seatbelt. facing child seat, secured with the car's seat- <10 kg...
Page 41 Second row of seats, outer seats Second row of seats, centre seat seats in cars seating seven Group 1 Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear-facing child seat, secured with the car's 9-18 kg seatbelt and straps. Type approval: E5 04192...
Page 42 Second row of seats, outer seats Second row of seats, centre seat seats in cars seating seven Group 2 Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear-facing child seat, secured with the car's 15-25 kg seatbelt and straps. Type approval: E5 04192...
Page 43 Second row of seats, outer seats Second row of seats, centre seat seats in cars seating seven Group 2/3 Volvo booster seat with backrest (Volvo Booster Seat with Volvo booster seat with backrest (Volvo Volvo booster seat backrest). Booster Seat with backrest).
Page 44 • the seatbelt is in contact with the child's Volvo's integrated booster cushion for the body and is not slack or twisted, and that centre rear seat is specially designed to pro- the seatbelt is positioned correctly across the shoulder.
Page 45 Volvo workshop. Do not make any modifi- the inside. For more information see cations or additions to the booster cush- the ISOFIX mounting points.
Page 46 Volvo recommends that you contact an the car is equipped with an activated air- authorised Volvo dealer for recommenda- Reduced size, rear-facing bag. tions about which ISOFIX child seats Volvo child seat recommends. Rear-facing infant seat NOTE Transverse infant seat, left-...
Page 47 01 Safety Child safety Type of child seat Weight Size class Passenger seats for ISOFIX installation of child seats Front seat Outer rear seat Infant seat, rear-facing max 13 kg (0 – 12 months) (IL) (IL) (IL) Child seat, rear-facing 9-18 kg (9-36 months) (IL)
Page 48 IL: Suitable for specific ISOFIX child seats. These child seats may be intended for use in a special car model, limited or semi-universal catego- ries. IUF: Suitable for front-facing ISOFIX child seats that are universally approved in this weight class. Volvo recommends rear-facing child seats for this group.
Page 49 The upper mounting points are primarily 3. Lock the seatbelt by inserting the locking intended for use with front-facing child seats. Volvo recommends that small children should tab in the buckle. A clear "click" indicates sit in rear-facing child seats to as late an age that the seatbelt has locked.
Page 50 Overview, left-hand drive car..............50 Overview, right-hand drive car..............52 Driver's door control panel..............54 Combined instrument panel..............55 Indicator and warning symbols............... 57 Information display.................. 60 Switches in the centre console............... 61 Lighting panel..................64 Left-hand stalk switch................67 Trip computer*..................
Page 51 I N S T R U M E N T S A N D C O N T R O L S...
Page 52: 02 Instruments And Controls
02 Instruments and controls Overview, left-hand drive car...
Page 53 02 Instruments and controls Overview, left-hand drive car Lighting panel Horn Panel vents Cruise control Display Direction indicators, dipped-main beam switch, READ button Temperature gauge Parking brake Odometer, trip meter, cruise control Parking brake release Speedometer Switches, reading lamps Direction indicators Passenger compartment lighting Tachometer Sunroof control...
Page 54: Overview, Right-Hand Drive Car
02 Instruments and controls Overview, right-hand drive car...
Page 55 02 Instruments and controls Overview, right-hand drive car Lighting panel Cruise control Panel vents Horn Indicator and warning symbols Combined instrument panel Fuel gauge Phone/Audio keypad Outside temperature, clock, gear position Windscreen wipers Tachometer Parking brake release Direction indicators Switches, reading lamps Speedometer Passenger compartment lighting Odometer, trip meter, cruise control...
Page 56: Driver's Door Control Panel
02 Instruments and controls Driver's door control panel Control panel Lock button, for all doors Blocking power windows in the rear doors Power window controls Door mirror control...
Page 57: Combined Instrument Panel
02 Instruments and controls Combined instrument panel Temperature gauge – Displays the tem- Switch between trip meters with one Automatic gearbox indicator – The perature of the engine cooling system. A quick press of the button. selected gear position is displayed here. message will appear on the display if the Cruise control indicator.
Page 58 02 Instruments and controls Combined instrument panel Indicator and warning symbols Direction indicators – left/right...
Page 59: Indicator And Warning Symbols
Symbols in the centre of the 3. Rectify in accordance with the instruc- instrument panel tions in the display or contact a work- shop. Volvo recommends that you seek assistance from an authorised Volvo workshop. Symbol and message text are visible until the fault has been rectified.
Page 60: Indicator Symbols
02 Instruments and controls Indicator and warning symbols Indicator symbols mended by Volvo to have the brake sys- ised Volvo workshop to have the brake tem checked. system checked. ABS fault If the BRAKE and ABS symbols If this symbol illuminates then the...
Page 61 This symbol is lit when the rear or IC system. Volvo recommends fog lamp is on. High speed that drive directly to an authorised Volvo If the car is moving faster than workshop for inspection. about 7 km/h then the symbol...
Page 62: Information Display
REGULAR Volvo recommends that SAFELY engine. Serious risk of SERVICE you engage an author- damage. ised Volvo workshop to carry out the service. STOP Stop the car in a safe The timing is deter- manner and turn off the ENGINE mined by the number of engine.
Page 63: Switches In The Centre Console
02 Instruments and controls Switches in the centre console Switch Child safety locks in the rear doors* Retractable power door mirrors* NOTE Activating or deactivating the Used to fold in the door mir- The order of the buttons may vary. electric child safety locks in rors if they are folded out or to the rear doors.
Page 64 02 Instruments and controls Switches in the centre console Active Xenon headlamps* 3. Fold the door mirror inward and then out- The remote control key must be at least in ward using the button. position I so that the socket can supply If the car is equipped with power.
Page 65 The compressor for emergency puncture where it could be a traffic hazard or obstruc- repair is tested and approved by Volvo. tion. Press the button to activate the function. For information about using Volvo's rec-...
Page 66: Lighting Panel
If necessary, the auto- ment of the headlamp beam, which could Rear fog lamp matic dipped beam can be deactivated. Volvo dazzle oncoming motorists. Avoid this by recommends that you engage an authorised Thumbwheel for adjusting instrument adjusting the height of the beam.
Page 67 02 Instruments and controls Lighting panel Active Xenon headlamps* Daytime running lights during the day. Cars with Xenon headlamps* have automatic headlamp levelling, so there is no thumb- To save fuel, daytime running lights (Daytime wheel (3). Running Light) can be selected during the day instead of the more energy-intensive dipped Instrument lighting beam.
Page 68 02 Instruments and controls Lighting panel WARNING This system help to save energy - it cannot determine in all situations when daylight is too weak or sufficiently strong, e.g. in mist and rain. The driver is always responsible for ensur- ing that the car is driven with its lights in a correct state and in accordance with appli- cable traffic regulations.
Page 69: Left-Hand Stalk Switch
02 Instruments and controls Left-hand stalk switch Stalk switch positions Direction indicators Main beam flash – Move the stalk switch gently towards the Continuous flash sequence steering wheel to position (C). – Move the stalk switch up or down to end Main beam comes on until the stalk switch is position (B).
Page 70: Trip Computer
02 Instruments and controls Trip computer* General ---- car is stationary, " " appears on the dis- NOTE play. During the period for regeneration fuel If a warning message interrupts while you consumption may increase, see page 147. are using the trip computer, this message must be acknowledged.
Page 71 02 Instruments and controls Trip computer* MPH ACTUAL SPEED.* Current speed is displayed in mph if the speedometer is graduated in km/h. If it is graduated in mph then the current speed is shown in mph. Resetting 1. Select --- KM/H AVERAGE SPEED --.- KM/L AVERAGE 2.
Page 72: Right-Hand Stalk Switch
02 Instruments and controls Right-hand stalk switch Windscreen wipers Rain sensor* Single sweep Raise the stalk switch to make a The rain sensor automatically activates the single sweep. windscreen wipers based on how much water it detects on the windscreen. The sensitivity of the rain sensor can be adjusted using the thumbwheel.
Page 73 . If the rear window wiper is This function (intermittent wiping when reversing) can be deactivated. Volvo recommends that you visit an authorised Volvo workshop to have it deactivated. Option/accessory, for more information, see Introduction.
Page 74 02 Instruments and controls Right-hand stalk switch already on at normal speed, no change is made.
Page 75: Cruise Control
02 Instruments and controls Cruise control* Activating Increasing or decreasing speed NOTE A temporary increase in speed (less than one minute) using the accelerator, such as while overtaking, does not affect the cruise control setting. When you release the accelerator, the car will return to the pro- grammed speed.
Page 76 02 Instruments and controls Cruise control* Disengaging Press CRUISE to disengage the cruise – control. CRUISE ON clears on the com- bined instrument panel. Option/accessory, for more information, see Introduction.
Page 77: Parking Brake, Electrical Socket, Etc
02 Instruments and controls Parking brake, electrical socket, etc. Parking brake 2. Depress the parking brake pedal firmly as far as possible. 3. Release the foot brake pedal and make sure that the car is at a standstill position. 4. If the vehicle rolls, the parking brake pedal must be depressed further.
Page 78 NOTE The compressor for emergency puncture repair is tested and approved by Volvo. For information about using Volvo's rec- ommended temporary mobility kit (TMK) The electrical socket can be used for various...
Page 79: Power Windows
02 Instruments and controls Power windows Operating Driver's door WARNING The power windows are operated using the If there are children in the car: controls in the doors. The key position must • Always remember to switch off the be I or II for the power windows to operate. power supply to the power windows The windows continue to work when the car by removing the remote control key if...
Page 80 02 Instruments and controls Power windows Rear power windows the window is obstructed by an object, remote control key) if you leave children in the the movement will stop. car unattended. The light in the switch is illuminated NOTE The rear door windows can only be operated The function auto up for the passenger from the driver's door.
Page 81: Windows, Rearview And Door Mirrors
02 Instruments and controls Windows, rearview and door mirrors Interior rearview mirror Interior rearview mirror with example. The button is countersunk compass* approximately 2.5 centimetres in the mirror. Correct zone on compass Dimming The upper left-hand corner of the rearview Normal position mirror has an integrated display that shows The earth is divided into 15 magnetic zones.
Page 82 02 Instruments and controls Windows, rearview and door mirrors 3. Press the button several times until the number for the required geographic area (1–15) is shown. After several seconds the display returns to show the compass direction, this means that the change of zone is complete.
Page 83 02 Instruments and controls Windows, rearview and door mirrors Magnetic zones for the compass.
Page 84 02 Instruments and controls Windows, rearview and door mirrors Door mirrors Calibration WARNING The compass may need calibrating to work Adjust the mirrors before you begin driv- correctly. For best results, switch off all major ing. power consumers such as interior lighting, ventilation fan, heated rear window etc.
Page 85 02 Instruments and controls Windows, rearview and door mirrors Water and dirt-repellent coating on the front side windows* Side windows treated with the water and dirt-repellent coating are marked with a small symbol. For information on glass care, see page 202. IMPORTANT Do not use a metal ice scraper to remove ice from the windows.
Page 86: Power Sunroof
02 Instruments and controls Power sunroof* Open positions Ventilation position WARNING To open: If there are children in the car: – Press the rear edge of the control (E) Switch off the supply to the power sunroof upward. by removing the remote control key if the driver leaves the car.
Page 87 02 Instruments and controls Power sunroof* To close: the handle and slide the screen forward to close it. – Press the control forward to the point of resistance (B). The sunroof moves toward Pinch protection the closed position as long as the button is held depressed.
Page 88: Homelink
02 Instruments and controls ® HomeLink General information ® Programming HomeLink WARNING • ® If HomeLink is used to operate a NOTE garage door or gate, make sure that there is no-one in the vicinity of the In certain vehicles the ignition must be switched on or in "accessory position"...
Page 89 02 Instruments and controls ® HomeLink ® 3. Depress the HomeLink button being 5. Depress and release the receiver's "pro- If programming problems persist, contact ® gramming button". The button flashes for programmed, hold it depressed for HomeLink on: www.homelink.com or ring approx.
Page 90 02 Instruments and controls ® HomeLink Programming individual buttons ® To reprogram an individual HomeLink but- ton, proceed as follows: 1. Depress the required button and do not release. ® 2. When the indicator lamp on HomeLink starts to flash, after approx. 20 seconds, start with step 1 in section "Programming HomeLink®"...
Page 91 02 Instruments and controls...
Page 92 General information on climate control........... 92 Electronic Climate Control, ECC............. 95 Fuel-driven parking heater*..............98 Option/accessory, for more information, see Introduction.
Page 93 C L I M A T E C O N T R O L...
Page 94: 03 Climate Control
Make sure that the multi-filter/pollen filter is 50 minutes after the car's ignition has been replaced regularly. Volvo recommends you switched off. The fan is then switched off Sensor location automatically after approx. 15 minutes.
Page 95 03 Climate control General information on climate control Air vents in the instrument panel Panel vents in the door pillar conventional systems where the air condition- ing cools the air to just above freezing point. Air distribution Open Open Closed Closed Lateral airflow Lateral airflow...
Page 96 03 Climate control General information on climate control Ventilated front seats (Executive) Seat heating, outer rear seats To increase the ventilation in steps: (Executive) – Press briefly on To obtain maximum ventilation: – Hold depressed for about 2 seconds. To decrease the ventilation in steps: –...
Page 97: Electronic Climate Control, Ecc
03 Climate control Electronic Climate Control, ECC Control panel AC – On/off (ON/OFF) Temperature, right-hand side cally (can be switched off using the AC but- ton). Recirculation/Multifilter with sensor* Temperature, left-hand side 2. Air quality system, recirculation/ Recirculation multifilter* Certain cars are equipped with a "Multifilter" AUTO Fan, rear passenger compartment* and air quality sensor.
Page 98 The lamp illuminates for 5 seconds • Follow the Volvo service programme for to confirm your selection. the recommended replacement interval of 4. AUTO the Multifilter. If the car is used in environ-...
Page 99 The light in selected for both front and rear* passenger Volvo recommends that an authorised Volvo the defroster button illuminates when the compartment. The button for rear passenger workshop adjusts the temperature.
Page 100: Fuel-Driven Parking Heater
60 minutes. If the parking heater does not start, despite repeated attempts, Volvo recommends that you contact an authorised Volvo workshop. A Warning decal on fuel filler flap. message is shown in the display. READ button...
Page 101 03 Climate control Fuel-driven parking heater* Direct start instrument panel illuminates and explanatory 3. Scroll with the thumbwheel to the desired text is shown in the display. hour. DIRECT 1. Scroll with the thumbwheel until START is shown in the display. When you leave the car, you will receive a 4.
Page 102 03 Climate control Fuel-driven parking heater* Battery and fuel If the battery has insufficient charge or the fuel level is too low, the parking heater will be switched off automatically. A message is shown in the display. Acknowledge the mes- sage by pressing READ once.
Page 103 03 Climate control...
Page 104 Front seats.................... 104 Front seats - Executive ................ 107 Interior lighting..................108 Storage spaces in the passenger compartment........110 Storage spaces in the passenger compartment - Executive ....115 Rear seat....................116 Loading....................118 Cargo area.................... 119...
Page 105 I N T E R I O R...
Page 106: 04 Interior
Forward/backward: lift the handle to Inlay mats* adjust the distance to the steering wheel Volvo supplies inlay mats which are espe- and pedals. Check that the seat is locked cially produced for your car. after changing position. Raise/lower the front of the seat cushion, pump up/down, (driver's and passenger side*).
Page 107: Memory Function
04 Interior Front seats Memory function* Front edge of seat cushion up/down WARNING Before setting off check that the inlaid mat Seat, forwards/backwards in the driver area is firmly affixed and Seat, up/down secured in the pins in order to avoid get- ting caught adjacent to and under the ped- Backrest rake als.
Page 108 04 Interior Front seats Key memory in remote control key WARNING All remote control keys can be used by differ- Risk of crushing. Make sure that children ent drivers to store the settings for the driv- do not play with the controls. er's seat and door mirrors .
Page 109: Front Seats - Executive
04 Interior Front seats - Executive Comfort seats, front Massage Setting lumbar Button for activating massage. Button for setting lumbar. Massage Hard massage The lumbar support is set with the same air Lumbar cushions used for massage. Adjustment can Soft massage be made steplessly both in terms of depth and height using the control button, see the Each front seat has massage in the backrest.
Page 110: Interior Lighting
04 Interior Interior lighting Reading lamps and interior lighting Rear roof lighting well as when the engine is running. The light- ing can also be activated within 10 minutes after: • the engine has been switched off and the ignition is in position 0 •...
Page 111: Automatic Lighting
Cargo area lighting The light illuminates automatically when the The programmed times, 30 seconds and cover is lifted. 10 minutes, can be changed by a Volvo work- The cargo area has a lamp on the inside of shop. the tailgate.
Page 112: Storage Spaces In The Passenger Compartment
04 Interior Storage spaces in the passenger compartment Storage spaces...
Page 113: Storage Spaces In The Passenger Compartment
04 Interior Storage spaces in the passenger compartment Pen holder Glovebox Storage compartment in third row of seats Storage compartment and cup holder Ticket clip Glovebox Storage tray in centre console ATTENTION AIRBAG Cup holder for rear seat passengers Pakjdskdl ioiuip kjöpp opoodidåuswi MY KEY Storage pocket (also on the front edge of SOUND...
Page 114 04 Interior Storage spaces in the passenger compartment Coat hanger Ashtray for rear seat passengers* Cup holder/bottle holder for rear seat passengers The coat hanger is only intended for light gar- Open the ashtray by pulling the top edge out- ments.
Page 115 04 Interior Storage spaces in the passenger compartment Storage compartment and cup holder Storage tray in centre console Cup holder (cars seating seven) The centre console contains a storage tray for Cup holder for front seat passengers. food and drinks, for example. The armrest This storage compartment can be used for Ashtray* can be folded back to make a "table"...
Page 116 04 Interior Storage spaces in the passenger compartment Storage compartment in the third row of seats (cars seating seven) This storage compartment can be used for pens and other small items.
Page 117: Storage Spaces In The Passenger Compartment - Executive
04 Interior Storage spaces in the passenger compartment - Executive Cooler box There is a cooler box under front seat's fold- ing armrest. Adjust the cooling level with the button (see illustration). The cooler box works when the engine is running or in key position WARNING Store bottles well sealed in the cooler box and make sure that the door is closed for...
Page 118: Rear Seat
04 Interior Rear seat Rear seats – second row (cars seating Sliding seat (cars seating seven) Removing the rear section of the seven) centre console The centre seat in the second row can be slid farther forward than the other seats. Sliding The centre console must first be removed if Lowering the backrest for entry into the the seat completely forward improves contact...
Page 119 04 Interior Rear seat Head restraint, rear seat – centre seat WARNING The lowest position should only be used when the backrest is to be folded down or when no one is sitting in this seat. After raising the backrests in the second and third row, it is important to make sure that the backrests have locked into posi- tion.
Page 120: Loading
Load on the roof Load carriers Load carriers designed by Volvo are recom- mended in order to avoid damaging the car and for maximum possible safety while driv- ing.
Page 121: Cargo Area
04 Interior Cargo area Extension, cargo area - seat row 2 3. Release the catch (1) and fold down the IMPORTANT backrest. Press down to lock the back- There must be no objects on the rear seat rest in its folded position. IMPORTANT when the backrest is to be folded down.
Page 122 04 Interior Cargo area General Bear in mind that if an object weighing 20 kg WARNING is subjected to a frontal collision at a speed of Opening the tailgate Never load cargo above the backrests! If 50 km/h, its impact weight will be 1000 kg. you do so, the load could be thrown for- For information about how the tailgate is Think about the following when loading:...
Page 123 04 Interior Cargo area Safety net Fitting the safety net Only applies to cars seating seven: 1. Make sure the net lies in front of the side panel armrest when securing. 2. Tension the safety net using the anchor- ing straps. Folding up the safety net If the car is equipped with a cargo area cover, The safety net prevents luggage and cargo...
Page 124 04 Interior Cargo area Fit the protective grille as follows: 5. Insert the attaching brace through the WARNING lower mounting in the protective grille 1. Lift in the protective grille through the tail- Make sure that the upper mountings of the from underneath, as indicated in the illus- gate opening or one of the rear doorways safety net are correctly fitted and that the...
Page 125 NOTE press the end pieces of the cargo area cover The compressor for emergency puncture down into the holders. repair is tested and approved by Volvo. For information about using Volvo's rec- WARNING ommended temporary mobility kit (TMK) for emergency puncture repair, see Do not place objects on the cargo area page 194.
Page 126 04 Interior Cargo area Open the hatch in the cargo area. Hang or NOTE secure your grocery bags using the tension- Some components of the first-aid kit have ing straps or holders. an expiration date and should be replaced before this date. Cargo area compartment, contents Opening the compartment in the cargo area floor (cars seating five)
Page 127 04 Interior...
Page 128 Remote control key - key with remote control........128 Locking and unlocking................130 Child safety locks.................. 134 Alarm*....................135 Option/accessory, for more information, see Introduction.
Page 129 L O C K S A N D A L A R M...
Page 130: 05 Locks And Alarm
If you should lose one of your remote control neously. keys, you are recommended to bring the remaining keys to an authorised Volvo work- Tailgate shop. The code of the missing key must be –...
Page 131 Remote control key - key with remote control Replacing the remote control key's The panic alarm is deactivated automatically 4. Return the old battery to your Volvo work- battery after 25 seconds or by pressing any of the shop so that it is disposed of in an envi- buttons on the remote control key.
Page 132: Locking And Unlocking
05 Locks and alarm Locking and unlocking From the outside Automatic locking NOTE The car can be locked even if a door or the tailgate is open - when the door/tailgate is then closed there is a risk that the keys will be locked in.
Page 133 05 Locks and alarm Locking and unlocking • Tailgate Press the left-hand stalk switch READ All doors can be locked using the lock button button to acknowledge any messages on on the control panel by each respective door. the display. •...
Page 134 05 Locks and alarm Locking and unlocking Opening the tailgate remains unlocked and its alarm is not Deadlocks* armed after being closed. The other Deadlocks means that the opening handles doors continue to remain locked with for the doors in the passenger compartment their alarms armed.
Page 135 05 Locks and alarm Locking and unlocking Temporary deactivation message is shown on the display as long as the remote control key remains in the ignition switch. Next time the engine is started the system is reset to zero and the deadlocks function and the alarm's movement and tilt detectors are then re-engaged.
Page 136: Child Safety Locks
05 Locks and alarm Child safety locks Manual child safety locks – rear doors Child-safe position – the rear doors can- When the light in the button illuminates, the not be opened from inside: Turn out- rear power windows and rear doors are The controls for the child safety locks are wards.
Page 137: Alarm
(or sage appears on the display. In which case, a portable electric heater) shall be used - contact a workshop - an authorised Volvo direct the airflow from the air vents so that workshop is recommended.
Page 138 05 Locks and alarm Alarm* Automatic alarm activation Remote control key not working Reduced alarm level This function prevents you accidentally leav- If the alarm cannot be deac- To avoid accidental triggering of the alarm - ing the car without the alarm on. tivated with the remote con- e.g.
Page 139 05 Locks and alarm...
Page 140 General....................140 Refuelling....................143 Starting the engine................149 Automatic gearbox................151 All-wheel drive*..................154 Brake system..................155 Stability and traction control system*........... 157 Park assist syst*..................159 Blind Spot Information System - BLIS*..........161 Towing and recovery................165 Jump starting..................167 Driving with a trailer................
Page 141 S T A R T I N G A N D D R I V I N G...
Page 142: 06 Starting And Driving
06 Starting and driving General Economical driving For more information and further advice, see brake linings wet resulting in delayed brake the pages 13 and 296. function. Driving economically means driving smoothly while thinking ahead and adjusting your driv- WARNING NOTE ing style and speed to the prevailing condi- tions.
Page 143: Open Tailgate
- see engine is switched off. Instead use the I mode page 169. The Volvo XC90 is primarily designed for driv- - which uses less power. ing on main roads, but also has good han-...
Page 144 06 Starting and driving General NOTE Avoid driving on steep slopes if the fuel level is low. The catalytic converter could be damaged if the engine does not receive enough fuel. When driving on extremely steep slopes, make sure the tank is more than half full to avoid the risk of break- down.
Page 145: Refuelling
06 Starting and driving Refuelling Opening the fuel filler flap Emergency unlocking of the fuel filler flap Manual unlocking of the fuel filler flap may be necessary if it cannot be opened normally. Proceed as follows: The fuel filler cap is inside the fuel filler flap on the right-hand rear wing and hangs up on the inside of the fuel filler flap.
Page 146 06 Starting and driving Refuelling Steps 1–3. 1. Lift up the corner piece from the floor in 4. Insert your hand and locate the lock. Its the rear right-hand corner of the cargo location is approximately inside the rear area. edge of the fuel filler flap.
Page 147 A certain overpressure may arise in the tank Mixing different types of fuel or the use of WARNING in the event of high outside temperatures. fuel not recommended invalidates Volvo's Open the cap slowly guarantees, and any associated service Always avoid inhaling fuel vapour and get- agreement.
Page 148 These fuels do not fulfil the require- • An oxygen sensor monitors the oxygen con- Do not use additives not recom- ments in accordance with Volvo recom- tent of the exhaust gases leaving the engine. mended by Volvo. mendations and generate increased wear...
Page 149 06 Starting and driving Refuelling Draining condensation from the fuel The risk of condensation in the fuel tank is The rear window heating may be activated reduced if the tank is kept well filled. When automatically to increase the load on the filter refuelling, check that the area around the fuel engine during regeneration without warning.
Page 150 06 Starting and driving Refuelling NOTE The following may arise during regenera- tion: • a smaller reduction of engine power may be noticed temporarily • fuel consumption may increase tem- porarily • a smell of burning may arise. When regeneration is complete the message is cleared automatically.
Page 151: Starting The Engine
06 Starting and driving Starting the engine Before starting the engine Starting the engine Ignition switch and steering lock – Apply the parking brake. 0 – Locked position IMPORTANT The steering lock is activated Automatic gearbox when the remote control key If the engine fails to start after 3 attempts - –...
Page 152 If the engine does not start or misfires, con- in the steering wheel lock. In which case, turn tact a workshop - a Volvo workshop is rec- the wheel back and forth to make it easier to ommended.
Page 153: Automatic Gearbox
06 Starting and driving Automatic gearbox Gear positions Gear selector inhibitor The gearbox is mechanically blocked when the P position is engaged. Always apply the parking brake when parking the car. R – Reverse The car must be stationary when position R is selected.
Page 154 06 Starting and driving Automatic gearbox Manual positions Cold start While driving The manual gearshift mode can be selected When starting in low temperatures, the gear at any time while driving. The engaged gear is changes can sometimes feel hard. This is due locked until you choose another gear.
Page 155 06 Starting and driving Automatic gearbox Kick-down – Keep your foot on the brake pedal when moving the gear selector to another posi- When the accelerator pedal is pressed all the tion. way to the floor, beyond the position normally regarded as full acceleration, a lower gear is immediately engaged.
Page 156: All-Wheel Drive
06 Starting and driving All-wheel drive* All-wheel drive – AWD All-wheel drive is always engaged. All-wheel drive means that all four road wheels are driven at the same time. The power is automatically distributed between the front and rear wheels. An electronically controlled clutch system distributes the power to the pair of wheels that grips best.
Page 157: Brake System
To keep the car as safe and reliable as possi- circuit is not working. Bear in mind that driving with a trailer puts an ble, follow the Volvo service intervals as additional load on the car's brakes. specified in the Service and Warranty Book-...
Page 158 To get the most out of the ABS: and have the brake system checked - an sary. If the brake pedal is released then all authorised Volvo workshop is recom- braking ceases. 1. Depress the brake pedal with full force.
Page 159: Stability And Traction Control System
06 Starting and driving Stability and traction control system* General Reduced operation DSTC ON means that the system func tion is unchanged. The Dynamic Stability and Traction Control system DSTC (Dynamic Stability and Traction DSTC SPIN CONTROL OFF means that Control) improves the car's traction and helps system operation is reduced.
Page 160 > If the message remains when the If the warning symbol remains illuminated engine is restarted, drive to a work- then a workshop should check the sys- tem - an authorised Volvo workshop is shop. An authorised Volvo workshop is recommended. recommended.
Page 161: Park Assist Syst
Rear parking assistance is deactivated auto- minates. matically when towing a trailer if a Volvo gen- The display shows the text message PARK uine trailer cable is used.
Page 162 06 Starting and driving Park assist syst* switched on again with the switch and the IMPORTANT lamp illuminates. In certain conditions the parking assis- tance system may produce incorrect warn- Cleaning the sensors ing signals that are caused by external sound sources that emit the same ultra- sonic frequencies that the system works with.
Page 163: Blind Spot Information System - Blis
06 Starting and driving Blind Spot Information System - BLIS* General Blind spots BLIS is an information system that under cer- tain conditions can help to draw the driver's attention to vehicles moving in the same direction in the so-called "blind spot". The system is designed to work most effec- tively when driving in dense traffic on multi- lane highways.
Page 164 06 Starting and driving Blind Spot Information System - BLIS* Activate/deactivate designed to detect motor vehicles such as IMPORTANT cars, trucks, buses and motorcycles. The lenses are electrically heated to melt In darkness the system reacts to the head- ice or snow. If necessary, brush snow lamps of surrounding vehicles.
Page 165 Repair of the BLIS system components itself when the data must only be performed by a workshop - transmission between an authorised Volvo workshop is recom- the BLIS system's mended. camera and the car's electrical system returns to normal.
Page 166 06 Starting and driving Blind Spot Information System - BLIS* Own shadow on large light smooth surface, e.g. noise barrier or concrete road surface. Low stationary sunlight shining into the camera. Option/accessory, for more information, see Introduction.
Page 167: Towing And Recovery
06 Starting and driving Towing and recovery Start assistance The towing eye is in the tool kit in the cargo WARNING area. Use a donor battery if the battery is dis- The steering lock remains in the position it charged and the engine does not start. Do was in when the power was cut off.
Page 168 06 Starting and driving Towing and recovery 3. Screw the eye securely into place right up to the flange (C). You can use a wheel wrench. • After use, unscrew the towing eye and refit the cover. IMPORTANT On certain cars with fitted towbar the tow- ing eye cannot be secured in the rear mounting.
Page 169: Jump Starting
06 Starting and driving Jump starting Starting with a donor battery 3. If the donor battery is installed in another 9. Start the engine of the "donor car" and car - switch off the donor car's engine allow it to run a few minutes at a speed and make sure that the two cars do not slightly higher than idle touch each other.
Page 170 06 Starting and driving Jump starting WARNING • The battery can generate oxyhydrogen gas, which is highly explosive. A spark can be formed if a jump lead is con- nected incorrectly, and this can be enough for the battery to explode. •...
Page 171: Driving With A Trailer
If the towing bracket is fitted by an authorised Trailer weights Volvo workshop, then the car is delivered with Overheating For information on Volvo's permitted trailer the necessary equipment for driving with a weights, see page 288.
Page 172 06 Starting and driving Driving with a trailer Level control Parking on a hill 1. Depress the foot brake. If your car is equipped with automatic level- ling, the rear suspension always retains the 2. Activate the parking brake. correct ride height regardless of load. When 3.
Page 173: Towing Equipment
If the car is equipped with a detachable tow- bar, the installation instructions for the loose section must be followed carefully, see page 173. WARNING If the car is fitted with a Volvo detachable towbar: • Follow the installation instructions carefully.
Page 174 06 Starting and driving Towing equipment* Specifications Dimensions for mounting points (mm) Fixed or detachable towbar 1110 1081 Side member Ball centre Option/accessory, for more information, see Introduction.
Page 175: Detachable Towbar
06 Starting and driving Detachable towbar* Fitting the towbar 2. Ensure that the mechanism is in the 3. Check that the indicator window (3) unlocked position by turning the key shows red. If the window does not show 1. Remove the protective cover by first clockwise.
Page 176 06 Starting and driving Detachable towbar* 5. Check that the indicator window shows green. 4. Insert the towbar until you hear a click. 7. Check that the towbar is secure by pull- ing it up, down and back. WARNING 6. Turn the key anticlockwise to locked position.
Page 177 06 Starting and driving Detachable towbar* Removing the towbar 8. Safety cable. 2. Push in the locking wheel (1) and turn it anticlockwise (2) until you hear a click. 1. Insert the key and turn it clockwise to the WARNING unlocked position.
Page 178 06 Starting and driving Detachable towbar* 3. Turn the locking wheel down fully, until it 4. Push on the protective cover. comes to a stop. Hold it in this position while pulling the towbar rearward and upward. WARNING Secure the towbar safely if it is stored in the car, see page 171.
Page 179: Adjusting Headlamp Pattern
06 Starting and driving Adjusting headlamp pattern Correct light pattern for left or right- Xenon headlamps should align with the red dot on the respec- hand traffic tive template. The long red line on the illustra- Copy templates 3 and 4. Check the measure- tions corresponds to the line in the headlamp ments to ensure they are correct.
Page 180 06 Starting and driving Adjusting headlamp pattern Left-hand drive car in left-hand traffic. Masking on right-hand halogen lens Masking on left-hand halogen lens Masking on right-hand Xenon lens Masking on left-hand Xenon lens Control point in headlamp lens.
Page 181 06 Starting and driving Adjusting headlamp pattern Right-hand drive car in right-hand traffic. Masking on left-hand halogen lens Masking on right-hand halogen lens Masking on left-hand Xenon lens Masking on right-hand Xenon lens Control point in headlamp lens.
Page 182 06 Starting and driving Adjusting headlamp pattern Templates for masking.
Page 183 06 Starting and driving...
Page 184 General....................184 Tyre pressure..................187 Warning triangle* and spare wheel*............188 Changing wheels................... 191 Emergency puncture repair*..............194 Option/accessory, for more information, see Introduction.
Page 185 W H E E L S A N D T Y R E S...
Page 186: 07 Wheels And Tyres
07 Wheels and tyres General Driving characteristics and tyres Speed ratings New tyres The tyres greatly affect the car's driving cha- The car is approved as a whole, which means racteristics. The type of tyre, dimensions, tyre that dimensions and speed ratings must not pressure and speed rating are important for differ from those specified on the vehicle reg- how the car performs.
Page 187 A suitable dis- cially the studs, a longer service life. tance for the first change is approx. 5000 km and then at 10 000 km intervals. Volvo rec- NOTE ommends that you contact an authorised...
Page 188 WARNING Use Volvo genuine snow chains or equiva- The arrow shows the tyre's direction of rotation lent chains designed for the car model, When summer and winter wheels are and tyre and rim dimensions.
Page 189: Tyre Pressure
07 Wheels and tyres Tyre pressure Recommended tyre pressure Checking the tyre pressure Tyre pressure affects travelling comfort, road noise and steering characteristics. Check the tyre pressure regularly. NOTE Tyre pressure decreases over time, this is a natural phenomenon. Tyre pressure also varies depending on ambient temperature.
Page 190: Warning Triangle* And Spare Wheel
07 Wheels and tyres Warning triangle* and spare wheel* Warning triangle After use: IMPORTANT – Pack everything in reverse order. The car must never be driven fitted with more than one "Temporary Spare" wheel. Make sure that the warning triangle with case is securely fastened in the compartment.
Page 191 07 Wheels and tyres Warning triangle* and spare wheel* Spare wheel – removing The spare wheel is located under the car. The The location of the jack varies: 4. Loosen the tyre by cranking anticlockwise jack*, tool kit* and crank are located under until you reach the stop.
Page 192 This is not strong enough to use to lift the car. If you are unsure about the location of the jacking points, Volvo recommends that Spare wheel – refitting you contact an authorised Volvo work- It is best to have two people put the spare shop.
Page 193: Changing Wheels
NOTE the car should be done using workshop jacks and axle stands under the part of the Volvo recommends only using the jack* car that is raised. that belongs to the car model in question, which is indicated on the jack's label.
Page 194 07 Wheels and tyres Changing wheels 5. Use the wheel brace to loosen the wheel the jack so that its foot is positioned verti bolts ½-1 turn. Turn anticlockwise. cally under the anchorage. See illustra- tion. IMPORTANT The ground must be firm, smooth and level.
Page 195 NOTE This wheel bolt may also be used for steel wheel rims. Make sure to use the correct type of bolt. Volvo recommends that you contact the near- est Volvo workshop if you are in any doubt.
Page 196: Emergency Puncture Repair
NOTE The compressor for temporary emergency puncture repair has been tested and The emergency puncture repair kit is only approved by Volvo. intended for sealing tyres with a puncture in the tread. Label, maximum permitted speed Taking out the emergency puncture...
Page 197 Do not unscrew the bottle, it is equipped after the emergency tyre repair kit has with a reverse catch to prevent leakage. been used. Volvo recommends that you visit an authorised Volvo workshop for 5. Unscrew the wheel's dust cap and screw...
Page 198 Risk of overheating. The compressor must ficiently sealed. The journey should not not run for more than 10 minutes. 7. Volvo recommends that you drive to the be continued. Contact a tyre centre. nearest authorised Volvo workshop for 4. If the tyre pressure is higher than 1.3 bar 9.
Page 199 07 Wheels and tyres Emergency puncture repair* Inflating the tyres IMPORTANT NOTE The car's original tyres can be inflated by the Risk of overheating. The compressor must Leave the container at a collection point compressor. not run for more than 10 minutes. for storing dangerous waste.
Page 200 Cleaning....................200 Touching up paintwork................. 204 Rustproofing..................206...
Page 201 C A R C A R E...
Page 202: 08 Car Care
An authorised Dirty headlamps have impaired functional- Wash away bird droppings from the paint- ity. Clean them regularly, when refuelling Volvo workshop is recommended for the work as soon as possible. Bird droppings for example. removal of any discoloration.
Page 203 The car does not need to be polished until it Rinse the entire car to remove loose dirt. A special cleaning agent available from Volvo is at least one year old. However, the car can When using a pressure washer: Make sure dealers is recommended for the cleaning and be waxed before this time.
Page 204 Paintwork damage caused by Vacuuming is important prior to using clean- such treatments is not covered by Volvo ing agents. warranty. IMPORTANT Carpets and cargo area Sharp objects and Velcro may damage the Remove inlaid carpets for separate cleaning fabric upholstery.
Page 205 • movements. Leather needs to breathe. Never cover your Volvo dealer. Make sure the seatbelt is the leather steering wheel with protective dry before allowing it to retract. 3. Dab accurately with the sponge on the plastic.
Page 206: Touching Up Paintwork
08 Car care Touching up paintwork Paintwork Stone chips and scratches Repairing minor paint damage such as stone chips and scratches Paint is an important part of the car's rust- 1. Apply a piece of masking tape over the proofing and should therefore be checked regularly.
Page 207 08 Car care Touching up paintwork NOTE If the stone chip has not penetrated down to the meal and an undamaged layer of paint remains in place, fill in with base coat and clear coat as soon as the surface has been cleaned.
Page 208: Rustproofing
The car's rustproofing does not normally require treatment for approximately 12 years. After this period, it should be treated at three- year intervals. If the car needs further treat- ment, Volvo recommends that you engage an authorised Volvo workshop for assistance.
Page 209 08 Car care...
Page 210 Volvo service..................210 Self-maintenance.................. 211 Bonnet and engine compartment............213 Oils and fluids..................215 Wiper blades..................219 Battery....................221 Replacing bulbs..................224 Fuses..................... 231...
Page 211 M A I N T E N A N C E A N D S E R V I C E...
Page 212: 09 Maintenance And Service
It was checked again in accordance with Volvo Car Corporation regu- lations before it was handed over to you. To keep your Volvo as safe and reliable as possible, follow the Volvo service programme specified in the Service and Warranty Book- let.
Page 213: Self-Maintenance
It is therefore important to at temperatures around freezing point. handle the battery in an environmentally cor- • Brake and clutch fluid – The level must be rect manner. Let your Volvo dealer assist you. between the MIN and MAX marks. WARNING WARNING NOTE...
Page 214 09 Maintenance and service Self-maintenance If you raise the car using a two-pillar work- shop lift, ensure that the front and rear lift arms are fixed under the lifting points. See previous illustration.
Page 215: Bonnet And Engine Compartment
09 Maintenance and service Bonnet and engine compartment Opening the bonnet WARNING Close the bonnet by placing your hand on its top and pressing down. Do not close it by holding the grille. Engine components on the inside could injure your fingers. 1.
Page 216 The air conditioning system contains fluores- Engine oil dipstick cent tracing agents. Use ultraviolet light when Engine oil filling looking for leaks. Washer fluid reservoir Volvo recommends that you contact an authorised Volvo workshop. Reservoir for power steering fluid (loca- tion depends on engine variant.)
Page 217: Oils And Fluids
If the car is driven in adverse con- consumption and environmental impact. ditions, Volvo recommends using an oil of a An approved engine oil must be used in higher grade, see page 292.
Page 218 09 Maintenance and service Oils and fluids Washer fluid, topping up Checking the oil cantly below, then an additional amount is required. 6. If required, check the level again, do it after driving a short distance. Then repeat steps 1 - 4. WARNING Never fill above the MAX mark.
Page 219 In the event of any doubt about water quality, used ready-mixed Coolant can be very hot. If the coolant requires topping up when the engine is at coolant in accordance with Volvo rec- operating temperature, unscrew the ommendations. expansion tank cap slowly to gently •...
Page 220 09 Maintenance and service Oils and fluids Checking and topping up the brake Check the level frequently. The fluid does not WARNING and clutch fluid require changing. The level must lie between If the brake fluid is under the MIN level in the ADD and FULL marks.
Page 221: Wiper Blades
09 Maintenance and service Wiper blades Wiper blades Replacing the wiper blades, windscreen NOTE Cleaning The wiper blades are different lengths. The blade on the driver's side is longer than on For cleaning wiper blades and windscreen, the other side. see page 200.
Page 222 09 Maintenance and service Wiper blades 2. Remove the wiper blade by moving it up/out (see illustration) towards the tail- gate. 3. Press the new wiper blade into position. 4. Check that the blade is firmly installed.
Page 223: Battery
09 Maintenance and service Battery Operation Symbols on the battery NOTE The service life and function of the battery is Use protective goggles. The life of the battery is shortened if it influenced by factors such as the number of becomes discharged repeatedly.
Page 224 09 Maintenance and service Battery Changing the battery WARNING Avoid sparks and naked flames. Removal Connect and remove the positive and neg- ative cables in the correct order. 5. Detach the red positive cable. 6. Detach the ventilation hose from the bat- Risk of explosion.
Page 225 09 Maintenance and service Battery > Check that it is correctly connected to both battery and outlet in the body. 4. Connect the red positive cable. 5. Connect the black negative cable. 6. Fit the cover and bracket.
Page 226: Replacing Bulbs
• High-level brake light bulbs, do the following and then consult the ommend that you visit an authorised Volvo In the event of a fault in the daytime running instructions for the specific lamp. workshop.
Page 227 09 Maintenance and service Replacing bulbs Location of bulbs in front lamp Dipped beam, halogen IMPORTANT Do not pull the electrical cable, only the connector 5. Unplug the connector by first pressing in the catch from underneath and then pull- ing it up a bit from above.
Page 228 09 Maintenance and service Replacing bulbs 8. Screw the cover back into place; the 5. Press the clamp spring upwards and a lit- 4. Fit the bulb holder back in place and turn marking HAUT should be at the top. tle to the left so that it secures in its clockwise.
Page 229 09 Maintenance and service Replacing bulbs Bulbs in rear lamp cluster Direction indicators Reversing lamp...
Page 230 09 Maintenance and service Replacing bulbs Bulb replacement 1. Switch off all lights and turn the remote 7. Loosen the extra length of cable for bet- 14. Refit the insert against the bolt holes. control key to position 0. ter accessibility. Press the insert into place.
Page 231 09 Maintenance and service Replacing bulbs Rear fog lamp Number plate lighting Courtesy lighting 1. Insert a slotted screwdriver as indicated 1. Switch off all lights and turn the remote There is courtesy lighting under the instru- by the arrow in the illustration. control key to position 0.
Page 232 09 Maintenance and service Replacing bulbs Bulb in cargo area Vanity mirror lighting 1. Insert a screwdriver and gently turn so Removal of lamp lens that the lamp housing comes loose. 1. Insert a screwdriver under the lamp lens and gently prize up the lock lugs on the 2.
Page 233: Fuses
09 Maintenance and service Fuses General Cable routing may vary slightly due to engine variant. However, the components listed are in the same positions. All electrical functions and components are Fuse box in the passenger compartment 2. Pull out the fuse and check from the side protected with a number of fuses to protect at dashboard end on driver's side.
Page 234 There are also pliers which facilitate the removal and fitting of fuses. If the same fuse fails repeatedly then there is a fault in the component. In which case, Volvo recommends that you visit an author- ised Volvo workshop for this to be checked.
Page 235 09 Maintenance and service Fuses Relay/fuse box in the engine compartment 30 A Transmission control module Engine control module (ECM) (TCM) 15 A (petrol), injection valves (pet- 30 A rol), mass air flow sensor (pet- Ignition coils (petrol), engine rol) 15 A High-pressure washer, head- control module (ECM), injec-...
Page 236 09 Maintenance and service Fuses Lambda-sond (petrol) 20 A Lambda-sond (diesel) 10 A Crankcase ventilation heater (petrol), AC connection (pet- rol), solenoid valves, ECM, (petrol), glow heating control (diesel) 15 A Dipped beam, left 20 A Dipped beam, right 20 A Engine control module (ECM) supply, engine relay Position lamp...
Page 237 09 Maintenance and service Fuses Relay/fuse box in the passenger compartment within the sound barrier on the driver's side Seat heating, right side 15 A Brake lamp switch feed ABS, DSTC Seat heating, left side 15 A Combined instrument panel Electronic power steering (DIM), climate control (CCM), (ECPS)*, Active Xenon head-...
Page 238 09 Maintenance and service Fuses Transmission control module (TCM) 10 A See also fuse 8 in the section entitled "Relay/fuse box in the passenger compartment at dashboard end on driver's Main beam, left 10 A side". Main beam, right 10 A Power passenger seat*, Rear Seat Entertainment (RSE)* Fuel pump...
Page 239 09 Maintenance and service Fuses Relay/fuse box in the passenger compartment at dashboard end on driver's side A decal which specifies the positions and amperages of the fuses is located in the end box cover. Climate control system fan 30 A Ignition switch, SRS-sys- tem, engine control mod- Audio (amplifier)*...
Page 240 09 Maintenance and service Fuses Sunroof* 15 A Telematics*, Bluetooth* 15– See also fuse 28 in the section entitled "Relay/fuse box in the passenger compartment within the sound barrier on the driver's side". Option/accessory, for more information, see Introduction.
Page 241 09 Maintenance and service Fuses Fuses in the cargo area Reversing lamp 10 A Towing bracket wiring* (30- Rear air conditioning (A/C)* 15 A feed) 15 A Position lamps, rear fog lamp, cargo area lighting, Electrical socket, cargo area 15 A number plate lighting, lamps Rear right door: Power win- in brake lighting...
Page 242 09 Maintenance and service Fuses Rear window defroster 20 A Rear window defroster 20 A 7.5 A Park Assist* Main fuse: Towing bracket wiring, parking assistance, 30 A Central locking system (PCL) 15 A Trailer lighting, left: Position lamps, direction indicator* 25 A Trailer lighting, right: Brake light, rear fog lamp, direction...
Page 243 09 Maintenance and service Fuses Fuses in the cargo area - Executive* The fuse box is located behind the cover panel on the left-hand side. Relay, seat heating, rear seat, Relay, massage seat, front Seat heating, rear seat, left 15 A Seat heating, rear seat, right 15 A Ventilated seat front, Massage...
Page 244 General....................244 Control panels, audio................245 Audio system functions................. 248 Radio functions..................253 CD functions..................259 Menu structure – audio system............. 262 Phone functions*................... 263 Menu structure – phone................ 270 Bluetooth handsfree*................274 RSE - Rear Seat Entertainment system - Dual Screen* ....... 280 Option/accessory, for more information, see Introduction.
Page 245 I N F O T A I N M E N T S Y S T E M...
Page 246: General
You can easily and conveniently use your Infotainment system by means of the joint control panel or the steering wheel keypad. XC90 can be equipped with Dolby Surround Pro Logic II . This offers an optimal sound experience very close to being there with a broad, natural sound profile.
Page 247: Control Panels, Audio
10 Infotainment system Control panels, audio Audio controls CD – shortcuts PHONE - Phone On/Off/Standby MENU – menu selection buttons VOLUME - Volume (knob control) MY KEY – programmable shortcut key for CD and CD changer eject* your favourite function POWER - Audio On/Off CD player and CD changer* SELECTOR - select audio source (rotary...
Page 248 10 Infotainment system Control panels, audio Steering wheel keypad Menus Shortcuts Menu options are numbered and can also be Audio – Phone* selected directly with the keypad 1-6. My own shortcut button – MY KEY Use MY KEY to store a favourite function in the menu, e.g.
Page 249 10 Infotainment system Control panels, audio Control panel with headphones tracks or to search for radio stations automat- socket* ically. Limitations The audio source (FM, AM, CD etc.) played back in the speakers cannot be controlled from the rear control panel. RDS messages may not appear if the radio is playing back in the headphones while another audio source is playing back in the speakers.
Page 250: Audio System Functions
10 Infotainment system Audio system functions On/Off switch – Audio Volume control Turn the knob clockwise or anticlockwise to raise or lower the volume respectively. The volume control is electronic and has no end position. Volume can also be raised (+) or lowered (–) using the steering wheel keypad.
Page 251 10 Infotainment system Audio system functions USB* 2. Connect your iPod®, MP3 player or USB IMPORTANT memory stick to the USB connection*, The cover for the cup holders must be see preceding illustration. open when the connector is in the AUX >...
Page 252 Bluetooth function in the car's audio sys- control, radio reception and vehicle speed. before being connected. tem. Volvo recommends that you contact an authorised Volvo dealer or visit The controls that are explained in these oper- ® Streaming audio via Bluetooth www.volvocars.com for information on...
Page 253 10 Infotainment system Audio system functions Audio mode Surround* NOTE Surround settings govern the spatial percep- The level for the centre speaker can only tion of the sound. The settings, including acti- DPL II be set if Dolby Pro Logic II ( ) or vating and deactivating for each respective 3-CH...
Page 254 10 Infotainment system Audio system functions 5. Press ENTER until you come to menu Equalizer front mode to save any changes. This function is used to fine-tune the sound from the front speakers. AUDIO MODE 1. Select in the menu and press ENTER.
Page 255: Radio Functions
10 Infotainment system Radio functions Tuning Manually seek known frequency AUTOSTORE – autostoring stations 1. Hold the button depressed. is shown in the display. The radio slowly scrolls in the desired direction, increasing its tempo after a few AM FM MY KEY PHONE seconds.
Page 256 10 Infotainment system Radio functions Volume control – NEWS/TP/ALARM 3. Close using SCAN or EXIT. If there is no station with an adequately strong signal then the display shows Storing a station station found NOTE A selected station can be stored as a preset Cancelling automatic storage of If a CD for example is playing when the while SCAN is active.
Page 257 10 Infotainment system Radio functions Press the EXIT button. The news broadcast is finished, the audio system – function message is broadcast. This function is used returns to the previous audio source and remains active and the radio waits for the to warn motorists of major accidents and cat- resumes the previous volume setting.
Page 258 10 Infotainment system Radio functions and press ENTER. 3. Select Programme types Programme types 4. Select Select PTY and press ENTER. Current affairs Pop music 5. Press ENTER for one or more of the lis- Religion Travel ted programme types you select. The PTY symbol in the display illuminates Varied speech Rock music...
Page 259 10 Infotainment system Radio functions Traffic information – TP STATION News – NEWS STATION Automatic frequency update – AF Here, you set from which station traffic infor- Here, you set from which station news is to The AF function selects one of the strongest mation is to be heeded.
Page 260 10 Infotainment system Radio functions Enhanced Other Networks – EON Resetting RDS functions The EON function is especially useful in urban Resets all radio settings to the original factory areas with many regional radio stations. It settings. allows the distance between the car and the 1.
Page 261: Cd Functions
10 Infotainment system CD functions Inserting a CD (CD changer) Audio files – Select an empty position with the number Apart from normal music CDs, the CD player buttons 1 - 6 or Up/Down on the naviga- supports MP3 and WMA format audio files. tion button.
Page 262 10 Infotainment system CD functions Fast-wind/change CD tracks and audio Different messages appear depending on NOTE which random function is active: files It is only possible to scroll between ran- • Short presses right/left on the RANDOM means that the tracks from dom CD tracks on the current disc.
Page 263 10 Infotainment system CD functions WARNING Only use standard discs (12 cm in diame- ter). Do not use CDs with adhesive disc labels. The heat in the CD player may cause the label to come off, damaging the CD player.
Page 264: Menu Structure - Audio System
10 Infotainment system Menu structure – audio system AM MENU FM-MENU 1. AUDIO SETTINGS* 1. News 2. TP CD MENU 3. Radio text 1. Random 4. RADIO SETTINGS 2. News 4.1. PTY 3. TP 4.2. TP 4. Disc text 4.3. NEWS STATION 5.
Page 265: Phone Functions
10 Infotainment system Phone functions* Phone system components Option/accessory, for more information, see Introduction.
Page 266: Phone Functions
• Volvo recommends that an authorised tions. When in active mode, phone infor- Volvo workshop carries out phone system mation is always shown in the control servicing. panel display. Microphone - The microphone for...
Page 267 Continuing with system in standby mode: pletely during a phone call, see page 272. 1. The phone will continue in standby mode This function only applies to the Volvo inte- with a brief press of the PHONE button or grated phone system.
Page 268: Sim Card
10 Infotainment system Phone functions* Menu shortcuts SIM card Contact your network operator if you experi- ence difficulties with the SIM card. Once you have used the menu button to enter the menu system, you can use numbers instead of the arrows and the ENTER button Making and receiving calls to select the right menu in the main menu To call:...
Page 269 10 Infotainment system Phone functions* Last dialled numbers Functions during a call Using speed dial 1. To make a call, press and hold the The phone automatically stores the last The following functions are available during a desired speed dial button for about two phone numbers/names called.
Page 270 10 Infotainment system Phone functions* Call volume Storing phone numbers with names Choose from the following alternatives: Phone Increase or decrease call volume during calls 1. Press the MENU button, select 1. Press ENTER and scroll with the arrows by pressing the + or - buttons in the steering book and press ENTER.
Page 271 10 Infotainment system Phone functions* Double SIM cards Specifications Used if two characters are to be ended with the same button. Output + 0 @ * # & $ £ / % SIM card small, 3 V Switch between upper and lower Memory entries case.
Page 272: Menu Structure - Phone
10 Infotainment system Menu structure – phone Overview 2.4. Speed dial 4.6.2 When engag. 1. Call register 2.4.1 Active 4.6.3 Not answered 1.1. Missed calls 2.4.2 Select numbers 4.6.4 Not reachable 1.2. Received calls 2.5. Erase SIM 4.6.5 Fax calls 1.3.
Page 273 10 Infotainment system Menu structure – phone 2.4. Speed dial 6.2.3 Automatic 1.4.2. Missed A number stored in the phone book can be 6.3. Change PIN code 1.4.3. Received stored as a speed dial number. 6.4. Audio 1.4.4. Dialled 2.5. Erase SIM 6.4.1 Ring volume Erase the entire SIM card memory.
Page 274 10 Infotainment system Menu structure – phone 6. Phone settings settings. Normally, these settings should not This setting only applies during the call in be altered. progress. 6.1. Network 3.3.1. SMSC number 4.6.2. When engag. Choose a network automatically or manually. The selected network is shown in the display 3.3.2.
Page 275 10 Infotainment system Menu structure – phone Mute radio. 6.4.4. Msg. beep 6.5. Factory default Reset the system's factory settings.
Page 276: Bluetooth Handsfree
NOTE Only a selection of mobile phones are fully compatible with the handsfree function. Volvo recommends that you seek assis- tance from an authorised Volvo dealer or visit www.volvocars.com for information on compatible phones. System overview. Centre console control panel.
Page 277 For 2. Activate the handsfree function with 3. Select My Volvo Car in the list of units general information on menus, see page 246. PHONE. detected in your mobile phone.
Page 278 10 Infotainment system Bluetooth handsfree* Making and receiving calls To call NOTE 1. Make sure that the text PHONE is shown Incoming call A new call cannot be started during an at the top of the display and that the ongoing call.
Page 279 10 Infotainment system Bluetooth handsfree* Phone book system searches for the last phone con- AND VOLUME Ring signals Ring nected its name is shown in the display. To signal 1 etc. All use of the phone book presupposes that change over to manual connection of another the text PHONE is shown at the top of the...
Page 280 3.1.1. Add phone function. Volvo recommends that you con- 268. 3.1.2. Added phones tact an authorised Volvo dealer or visit A short press on EXIT deletes an input char- www.volvocars.com for information on 3.2. Remove phone acter. One long press on EXIT clears all input compatible phones.
Page 281 10 Infotainment system Bluetooth handsfree* 4. CALL OPTIONS 3.2. Connect fr. mobile phone 4.1. Automatic answer 3.3. Bluetooth info. for the car 4. CALL OPTIONS 4.2. Voice mail no. 5. PHONE SETTINGS 4.1. Automatic answer 5.1. SOUNDS AND VOLUME 4.2. Voice mail no.: 5.1.1.
Page 282: Rse - Rear Seat Entertainment System - Dual Screen
10 Infotainment system RSE - Rear Seat Entertainment system - Dual Screen* General Music Different playback options The disc can be played back in different The RSE system can be used at the same Playing back a CD disc ways, scroll with the navigation buttons to time as the car's infotainment system.
Page 283 10 Infotainment system RSE - Rear Seat Entertainment system - Dual Screen* AUX input, Electrical socket 12 V System Connecting the RSE AUX input The input allows you to connect other equip- Formats supported by the system. ment. Always follow the instructions included Audio for- CD-DA, DVD Audio Playback, with the external equipment, or from the man-...
Page 284 10 Infotainment system RSE - Rear Seat Entertainment system - Dual Screen* 1. Unscrew the screw and detach the bat- 3. Fit the cover and screw in the screw. DVX(R) tery cover. REGISTRATION NOTE 2. Remove the used batteries, turn the new PREFERENCES TV TYPE batteries in accordance with the symbols...
Page 285 10 Infotainment system...
Page 286 Type designation................... 286 Dimensions and weights............... 288 Engine specifications................291 Engine oil....................292 Fluids and lubricants................294 Fuel....................... 296 Wheel and tyres, dimensions and pressure ......... 298 Catalytic converter................299 Electrical system................... 300 Type approval..................302 Symbols in the display................303...
Page 287 S P E C I F I C A T I O N S...
Page 288: 11 Specifications
11 Specifications Type designation Label location...
Page 289: Type Designation
NOTE identification and engine numbers can facili- The labels shown in the owner's manual tate all contact with an authorised Volvo are not provided as exact reproductions of dealer regarding the car and when ordering those in the car. The purpose is to show spare parts and accessories.
Page 290: Dimensions And Weights
11 Specifications Dimensions and weights Dimensions Weights Dimensions Dimensions Kerb weight includes the driver, the fuel tank Wheelbase 2857 Rear track 1624 90% full and all fluids. The weight of passengers and accessories, Length 4807 Load width, floor 1064 and towball load (when a trailer is hitched, Load length, floor, folded seat 2018 Width...
Page 291 11 Specifications Dimensions and weights Max. total weight NOTE WARNING The documented kerb weight applies to The car's driving characteristics change Max. train weight (car+trailer) cars in the standard version - i.e. a car depending on how heavily it is loaded and Max.
Page 292 11 Specifications Dimensions and weights Max. weight unbraked trailer, kg Max. towball load, kg...
Page 293: Engine Specifications
11 Specifications Engine specifications NOTE Not all engines are available in all markets. Engine Engine Output Output Torque (Nm/ No. of Bore Stroke Swept Com- (kW/rpm) (hp/rpm) rpm) cylinders (mm) (mm) volume pression code (litres) ratio B5254T9 154/5000 210/5000 320/1500-4500 92,3 2,497 9.0:1...
Page 294: Engine Oil
(below +5 °C). Volvo Car Corporation disclaims all war- ranty liability if engine oil of the prescribed grade and viscosity is not used. Volvo recommends that oil changes are carried out at an authorised Volvo work- shop.
Page 295 11 Specifications Engine oil Engine oil grade Engine Engine code Recommended oil grade Volume, incl. oil filter (litres) B5254T9 Oil grade: ACEA A5/B5 approx 5.5 Viscosity: SAE 0W–30. B6324S5 approx 6.8 D5244T18 approx. 5.7 D5244T5 approx. 5.7 Certain markets For filling engine oil, see page 215.
Page 296: Fluids And Lubricants
Petrol: see page 143 Diesel engine approx. 68 Diesel: see page 143 Water quality must fulfil the standard STD 1285.1. Refrigerant quantity varies depending on engine variant. Volvo recommends that you contact an authorised Volvo workshop for the correct information.
Page 297 Do not mix with any other transmis- sion fluid. If the transmission is topped up with a different fluid, contact a workshop nearby for servicing. Volvo recommends that you contact the nearest authorised Volvo workshop. NOTE...
Page 298: Fuel
11 Specifications Fuel emissions and fuel consumption 3.2 AWD 374 (384) 16.1 (16.5) 203 (203) 8.7 (8.7) 265 (269) 11.4 (11.5) – (275) – (10.5) – (176) – (6.7) – (212) – (8.1) D5 AWD – (275) – (10.5) – (180) –...
Page 299 11 Specifications Fuel • The driver's driving style. ECO tyre pressure for best results, see the tyre pressure table on page 298. • If the customer has specified wheels • larger than those fitted as standard on the Choice of tyres can affect fuel consump- model's basic version, then resistance tion - seek advice on suitable tyres from a increases.
Page 300: Wheel And Tyres, Dimensions And Pressure
11 Specifications Wheel and tyres, dimensions and pressure Approved tyre pressures Engine Tyre size Speed (km/h) Load, 1-3 persons Max. load ECO pressure Rear (kPa) Front (kPa) Rear (kPa) Front (kPa) 0–160 235/65R17 235/60R18 160+ – 0–160 255/50R19 255/45R20 160 + –...
Page 301: Catalytic Converter
11 Specifications Catalytic converter General The purpose of the catalytic converter is to purify exhaust gases. It is located in the flow of exhaust gases close to the engine so that it quickly reaches operating temperature. The catalytic converter consists of a monolith (ceramic or metal) with channels.
Page 302: Electrical System
11 Specifications Electrical system General The battery capacity is dependent upon the IMPORTANT equipment level in the vehicle. The car has a voltage-regulated AC alterna- If the battery is replaced, replace it with a tor. The electrical system is single-pole and battery of the same cold start capacity and uses the chassis and engine casing as a con- reserve capacity as the original (see the...
Page 303 11 Specifications Electrical system Lighting Output (W) Type Front courtesy lighting Socket SV8.5 Length 38 mm Glovebox lighting Socket SV8.5 Length 43 mm Vanity mirror lighting T5 Socket W2x4.6d Cargo area lighting Socket SV8.5 Length 43 mm Number plate lighting C5W LL Rear direction indicators PY21WSV...
Page 304: Type Approval
11 Specifications Type approval Remote control key system Country EUROPE...
Page 305: Symbols In The Display
11 Specifications Symbols in the display General Symbol Meaning Page Symbol Meaning Page There are a variety of different symbols in the Fault in the ABS 58, 156 Airbags - SRS 21, 59 display in the car. The symbols are divided system into warning, indicator and information sym- bols.
Page 306 11 Specifications Symbols in the display Other information symbols in the combined instrument panel Symbol Meaning Page Cruise control* Information symbols in the centre console display Symbol Meaning Page Audio files Directory in CD disc Traffic information 255, 257 Information symbol in rearview mirror Symbol Meaning Page...
Page 307 11 Specifications...
Page 308 12 Alphabetical Index Air vents Automatic gearbox......151, 152 instrument panel........93 lock-up function........152 ABS fault............ 58 safety systems........153 Alarm towing and recovery......165 Active Xenon headlamps..... 62, 65 alarm indicator........135 trailer........... 169 alarm signals........136 Adaptive system........152 W button..........
Page 309 12 Alphabetical Index BLIS........... 63, 161 Checking and topping up the coolant..217 Checking the engine oil level....215 Bluetooth Calls handsfree..........274 Children............. 34 functions during a call......267 mute microphone....... 276 child safety locks....43, 61, 134 incoming..........276 transfer call to mobile......
Page 310 12 Alphabetical Index Clutch fluid, checking & topping up..218 Defroster............ 97 Coat hanger..........112 Detectors........... 62 ECC, electronic climate control... 92, 95 Cold start Diesel............146 Economical driving........140 automatic gearbox......152 Diesel: engine preheater......59 ECO pressure.......... 187 Collision Diesel particle filter........
Page 311 12 Alphabetical Index Engine preheater........59 Front seat lumbar..........107 Engine specifications....... 291 massage..........107 Handbrake..........75 Environmental labelling, FSC, owner's FSC, environmental labelling..... 13 Hazard warning flashers......63 manual............13 Fuel Headlamp levelling........64 EON - Enhanced Other Networks.... 258 fuel consumption, display.....
Page 312 12 Alphabetical Index lighting panel, passenger compart- ment............64 Ignition keys..........150 Kerb weight..........288 main/dipped beam....... 64 position/parking lamps......64 IMEI number..........269 Key............128 reading lamps........108 remote control key......128 Immobiliser........128, 150 rear fog lamp........65 Keypad in the steering wheel....
Page 313 12 Alphabetical Index load carriers........118 Menu structure roof load..........118 audio system........262 phone, menu options......271 News..........254, 257 Load on the roof........118 phone, overview......... 270 Locking/unlocking Messages in BLIS........163 glovebox..........131 inside..........131 Messages in the information display..60 outside..........
Page 314 12 Alphabetical Index Parking heater traffic safety........266 frequency update........ 257 battery and fuel........100 volume reduction during phone call... 265 news........... 254, 257 general..........98 PTY............. 255 Phone book..........268 symbols and display messages.... 98 radio settings........253 Phone system.......... 263 time setting...........
Page 315 12 Alphabetical Index heating..........63 Roll-over protection Side airbag, SIPS........26 interior........... 79 ROPS (Roll Over Protection System)..31 SIM card..........266 retractable..........61 Roof load..........118 double..........269 Rear window, defrosting......63 ROPS (Roll Over Protection System)..31 SIPS bag – decal........26 Recirculation Rustproofing..........
Page 316: Storage Spaces In The Passenger Com
12 Alphabetical Index indicator..........59 Switching installation........... 173 symbols..........157 main and dipped beam......67 removing..........175 specifications........172 Stains............202 Symbols indicator symbols......... 58 Towing eye..........165 Standby mode, phone......265 stability system........157 TP – Traffic information....255, 257 Start assistance........
Page 317 12 Alphabetical Index Weights kerb weight......... 288 USB, connection........249 trailer weight........169 Wheels changing..........191 installation........... 192 removal..........191 Ventilation fan function......92 snow chains........186 spare wheel........189 Vibration damper........171 Whiplash injury.......... 29 Volume control......... 248 WHIPS child seat/booster cushion....
Page 318 12 Alphabetical Index...

Volvo XC90 Owner's Manual

Introduction

1 Safety

2 Instruments and Controls

3 Climate Control

4 Interior

5 Locks and Alarm

6 Starting and Driving

7 Wheels and Tyres

8 Car Care

9 Maintenance and Service

11 Specifications

Quick Links

Owners Manual

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo XC90

Summary of Contents for Volvo XC90

Table of Contents
