VOLVO V70 (-08) & XC90

WIRING DIAGRAM

2008
TP 39113202

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V70 and is the answer not in the manual?

Questions and answers

Lee
January 21, 2025

Just want to know the color of the fuel pump wire on a 2001 v70

1 comments:
Mr. Anderson
February 4, 2025

The power wire to the fuel pump on a 2001 Volvo V70 is blue for the 12V feed, and the ground wire is black.

This answer is automatically generated

Summary of Contents for Volvo V70

  • Page 1: Wiring Diagram

    VOLVO V70 (-08) & XC90 WIRING DIAGRAM 2008 TP 39113202...
  • Page 2: Vehicles With Srs (Airbag)/Sips Bag/Ic (Inflatable Curtain)

    2. Damage or malfunction of the SRS/SIPS bag/IC system. Work involving the SRS/SIPS bag/IC systems or other components in the vehicle that may affect the SRS/SIPS bag/IC systems must always be performed by an authorized Volvo workshop. In case of doubt, consult the SRS and SIPS bag/IC service manual.
  • Page 3: Table Of Contents

    Data communication high speed CAN V70....52 Fuses Data communication high speed CAN XC90 ....53 Data communication low speed CAN V70 ....54 Engine compartment 11A/1-5 ........14 Data communication low speed CAN XC90 ....55 Engine compartment 11B/1-11 ........15 Data communication LIN 1:2........
  • Page 4 Brake lights ..............87 Reversing lights ............88 Group 39 Other Follow-me-home lighting..........89 Audio with auxiliary amplifier V70 1:2 ......125 Running/parking lights, tail lights & Audio V70 ..............127 license plate lighting V70 .......... 90 Audio XC90..............128 Running/parking lights, tail lights &...
  • Page 5 Group 59 Brake system Group 88 Internal equipment Brake control system ..........159 Remote garage door opener........183 Supplemental Restraint System module (SRS) V70 . 184 Supplemental Restraint System module Group 64 Steering (SRS) XC90 ............. 185 Electronic power steering .......... 160 Connectors..........186...
  • Page 6 TP 39113202 V70/XC90 2008...
  • Page 7: Explanations

    = Light Blue = Japan = Light Green = Korea = Orange = Norway = Pink = Netherlands = Red = Sweden = Black = United States of America = Violet = Western Europe = White = Yellow TP 39113202 V70/XC90 2008...
  • Page 8: How To Use The Wiring Diagrams 1:2

    There is a section at the end of the manual in which Service/diagnostics the appearance and location of components is Contact reel described in numerical order. Meter Ignition component/shunt Converter Optics Ground connection Branching point Connector TP 39113202 V70/XC90 2008...
  • Page 9 = Data communication 53/331 = CAN communication 53/397 = MOST communication 31/93 31/98 31/83 = MOST communication = Connection with distribution = Further connection to... = Connector between cable 10/1-2 harnesses = Connector connected in com- ponent TP 39113202 V70/XC90 2008...
  • Page 10: Electrical Distribution V70 1:2

    Electrical distribution V70 1:2 Overview 15/31 17/17 11A/1 11A/2 11A/3 11A/4 11A/5 54/1C DIESEL 4/71:2 53/399 Bi-Fuel Bi-Fuel Bi-Fuel Bi-Fuel 20/16 W/O Bi-Fuel W/O Bi-Fuel 53/329 PETROL 11B/1 11B/2 11B/3 11B/4 11B/5 11B/6 11B/7 11B/8 11B/9 11B/10 11B/11 11B/12 11B/13...
  • Page 11 Electrical distribution V70 2:2 Overview A B C D E F G DIESEL 53/415 53/403 53/3009 11C/1 11C/2 11C/3 11C/4 11C/5 11C/6 11C/7 11C/8 11C/9 11C/10 11C/11 11C/12 11C/13 3/157:1 53/408 54/40C 4/9:55/B:27 4/58 R-SB A:29 4/56 C:14 C:13 B:24...
  • Page 12: Electrical Distribution Xc90 1:2

    4/46B:16 4/46B:51 4/46B:42 R-SB GN-Y GN-Y 6/104:1 GN-Y 2/90 2/91 2/182 FST1 FST2 FST3 11L/1 1(86) 3(30) 1(86) 3(30) 1(86) 3(30) 2(85) 5(87) 4(87a) 2(85) 5(87) 4(87a) 2(85) 5(87) 4(87a) GN-SB 4/56C:3 4/56C:25 GR-SB 53/331 4/56C:4 TP 39113202 V70/XC90 2008...
  • Page 13 4/56 C:14 C:13 B:24 BL-R 16/65:1 C:13 BL-R 3/157:2 D:16 BL-R BL-R B:16 53/443 BL-R C:14 4/9B:28/56 D:15 F3, 5-10, D:60 17-23, 31-32 ,34 F1-38 F1-2, 1 13-16, 54/40D 26-30, 33 D:35 D:50 A:13 A:23 31/53 TP 39113202 V70/XC90 2008...
  • Page 14: Fuses

    Fuses Engine compartment 11A/1-5 11A Fuses in engine compartment Fuse function 4/109 Glow plug control unit (GCU) 20/22-26 Glow plug 4/109 6/29 Cooling fan motor, Diesel 4/71 TP 39113202 V70/XC90 2008...
  • Page 15: Engine Compartment 11B/1-11

    Spark plug and ignition coil, not 8-cyl. 20/14 Condenser, ignition coils, 8-cyl. 20/46-53 Spark plug with ignition coil, 8-cyl. 6/44 Cooling fan, electrics box, engine compartment 7/51 Accelerator pedal sensor Electromagnetic clutch, climate control system 2/22 continues TP 39113202 V70/XC90 2008...
  • Page 16: Engine Compartment 11B/12-14

    Heated oxygen sensor 3 7/15 Front heated oxygen sensor, bank 2, 8-cyl. 7/82 Front heated oxygen sensor, bank 1, 8-cyl. 7/103 Rear heated oxygen sensor, bank 2, 8-cyl. 7/104 Rear heated oxygen sensor, bank 1, 8-cyl. continues TP 39113202 V70/XC90 2008...
  • Page 17: Engine Compartment 11B/15

    Solenoid, variable valve timing, exhaust, bank 1, 8-cyl. 4/109 Glow plug control unit (GCU) 6/143 Turbo control motor, Diesel 8/64 Solenoid valve, engine pad, Diesel 8/113 Bypass valve, EGR cooling, Diesel 8/120 EGR valve, Diesel continues TP 39113202 V70/XC90 2008...
  • Page 18: Engine Compartment 11B/16-20

    Main relay, engine management system 4/46 Engine Control Module (ECM) 10/11 Running/parking light, front left 4/56 10/12 Running/parking light, front right 4/56 10/71 Side running light, front left 4/56 10/73 Side running light, front right 4/56 TP 39113202 V70/XC90 2008...
  • Page 19: Passenger Compartment 11C/1-4

    Fuse function 4/52 Power Seat Module (PSM), V70 6/16 Driver seat motor, backrest angle, V70 4/52 6/17 Driver seat motor, up/down front edge, V70 4/52 6/18 Driver seat motor, up/down rear edge, V70 4/52 6/19 Driver seat motor, forward/backward, V70...
  • Page 20: Passenger Compartment 11C/5-7

    11C/30 11C/9 11C/19 11C/29 11C/38 11C Fuses in the passenger compartment Fuse function 3/74 Lock unit, left front door, V70 3/126 3/126 Driver/Passenger Door Module (DDM)/(PDM), V70 6/58 Front left power window motor, V70 3/126 6/62 Left power exterior rearview mirror, V70...
  • Page 21: Passenger Compartment 11C/8-10

    3/1, 4/56 4/56 Central Electronic Module (CEM), V70 4/58 Rear Electronic Module (REM), V70 11O/1 Fuses in spare fuse holder, passenger compartment V70 11O/2 Fuses in spare fuse holder, passenger compartment V70 16/65 Antenna ring/ignition switch lighting, V70 16/1 Integrated Audio Module (IAM), XC90...
  • Page 22: Passenger Compartment 11C/11-14

    4/70 10/150 Rear reading light, XC90 4/70 10/172 Reading light, third row of seats, XC90 4/70 16/60 Phone Module (PHM), V70 4/70 Upper Electronic Module (UEM), XC90 6/15 Sunroof motor, XC90 4/33 16/60 Phone Module (PHM), XC90 TP 39113202 V70/XC90 2008...
  • Page 23: Passenger Compartment 11O/1-2

    Fuses Passenger compartment 11O/1-2 11O/1-2 11O/1-2 Fuses in spare fuse holder, passenger compartment Fuse function Alcohol lock Alcohol lock 2/241 Alcohol lock TP 39113202 V70/XC90 2008...
  • Page 24: Cargo Compartment 11E/1-7

    4/56 Central Electronic Module (CEM) Main fuse for: F3, F5-F10, F17-F23, F31-F32, F34 11C/1-5 Fuses in the passenger compartment fuse box, V70 11C/1, 3-6 Fuses in the passenger compartment fuse box, XC90 11C/6-13 Fuses in the passenger compartment fuse box, V70...
  • Page 25: Cargo Compartment 11L/1

    Fuses Cargo compartment 11L/1 11L Fuse Diesel Fuse function 11B/9 Fuses in engine compartment fuse box 11B/10-15 Fuses in engine compartment fuse box 2/32 TP 39113202 V70/XC90 2008...
  • Page 26: Cargo Compartment 11M/1-2

    Fuses Cargo compartment 11M/1-2 11M/2 11M/1 11M/1-2 Fuses in spare fuse holder, cargo compartment V70 Fuse function 16/82 DVD player / control module, 30-feed 16/122 Rear Audio Separation module (RAS), 30-feed 16/82 DVD player / control module, X-feed TP 39113202 V70/XC90 2008...
  • Page 27: Central Electronic Module (Cem) F1-F14

    Occupant Weight Sensor (OWS) 7/159 Air Quality Sensor (AQS) Outlet 12V front 9/25 Outlet 12V rear 11M/2 Fuse in spare fuse holder, cargo compartment V70 Right-hand headlight wiper motor, V70 Left-hand headlight wiper motor, V70 continues TP 39113202 V70/XC90 2008...
  • Page 28: Central Electronic Module (Cem) F15-F34

    High beam, right 3/27 Switch unit, power passenger seat 16/1 Audio Module (AUM), V70 16/46 RTI display, accessory, V70 16/93 Control module, cellular phone handsfree, V70 16/109 DVD player/control module, XC90 6/31 Feed pump, ejectors 4/58 8/88 Solenoid, fuel tank, Bi-Fuel, rear...
  • Page 29: Rear Electronic Module (Rem) F1-F7

    4/58 Rear Electronic Module (REM) Fuse function 10/48 Reversing light, right 10/55 Reversing light, left 16/122 Rear Audio Separation module (RAS), V70 54/98 Connector, cable harness, rear seat entertainment, reverse gear signal, XC90 10/3 License plate lighting 10/19 Brake light extra...
  • Page 30: Rear Electronic Module (Rem) F8-F28

    16/79 Bass speaker, V70 6/76 Climate control system, rear XC90 16/79 Subwoofer Module (SUB), XC90 16/145 Satellite radio receiver, V70 6/32 Rear window wiper motor 17/38 7-pin outlet, tow hitch cable harness 17/39 13-pin outlet, tow hitch cable harness Spare...
  • Page 31: Rear Electronic Module (Rem) F29-F38

    Converter, direction indicators & brake lights, USA - running light - left-hand direction indicator 4/110 Trailer Module - brake lights - fog lights - right-hand direction indicator Main fuse for F37-F38 Heated rear window Heated rear window TP 39113202 V70/XC90 2008...
  • Page 32: Relays

    A = Corresponds to the position on the back of the relay box (wiring side) B = Corresponds to the position on the relay C = An old designation that may be found on 1(86) 3(30) the relay 2(85) 5(87) 4(87a) TP 39113202 V70/XC90 2008...
  • Page 33: Engine Compartment Fma1 - Fst3

    Relay, starter motor FMA3 2/32 Main relay, engine management system FMI2 2/22 Relay, climate control system FST1 2/90 Relay, windshield wiper, low/high speed FST2 2/91 Relay, intermittent wiping FST3 2/182 Relay, high pressure headlight washer motor TP 39113202 V70/XC90 2008...
  • Page 34: Relays Accessories

    Relay auxiliary lights compart- ment Cargo 2/191 Relay, remote parking heater start, radio signal compart- ment Front 2/192 Relay, electric engine heater member By climate 2/240 Alcohol lock relay, wake-up control 2/241 Alcohol lock relay, interior lighting system TP 39113202 V70/XC90 2008...
  • Page 35: Ground Connections Overview

    Ground connections Overview TP 39113202 V70/XC90 2008...
  • Page 36 Ground connections 31/1 - 31/44 31/1 Right MacPherson strut tower Right-hand headlight wiper motor, V70 6/104 High pressure headlight washer motor Washer fluid level sensor 16/10 Horn 1, XC90 31/2 Left MacPherson strut tower 4/46 Engine Control Module (ECM), 6-cyl., 8-cyl., Diesel...
  • Page 37 Front left side airbag igniter 9/12 Seat Heating Module (SHM), left-hand 31/47 Rear seat riser, left-hand side 4/58 Rear Electronic Module (REM) 8/66 Left-hand inflatable curtain igniter, V70 31/48 Rear seat riser, right-hand side 4/83 Control module fuel pump 6/31 Feed pump, ejectors 6/33...
  • Page 38 Road Traffic Information module (RTI), V70 16/149 MP3 player, accessory, V70 31/73 Rear seat riser, right-hand side 2/191 Relay, remote parking heater start, radio signal, accessory, V70 4/78 Accessory Electronic Module (AEM) 4/106 Control module, remote parking heater start, accessory, V70 8/85...
  • Page 39 Infotainment Control Module (ICM), XC90 16/105 Audio Module (AUD), XC90 16/109 DVD player/control module, XC90 16/122 Rear Audio Separation module (RAS), V70 16/145 Satellite radio receiver, V70, accessory 16/145 Remote Digital Audio Receiver (RDAR), XC90, accessory 17/13 Data link connector...
  • Page 40 Spark plug with ignition coil, 8-cyl. 31/90 Engine ignition coils 20/46 Spark plug with ignition coil, 8-cyl. 20/48 Spark plug with ignition coil, 8-cyl. 31/91 Engine 4/50 Electronic Throttle Module (ETM), Bi-Fuel 9/32 PTC resistor - crankcase ventilation, Bi-Fuel TP 39113202 V70/XC90 2008...
  • Page 41 4/28 Transmission Control Module (TCM), TF-80SC / TF-80SC AWD 4/56 Central Electronic Module (CEM) 4/99 Electronic power steering control module Windshield wiper motor Left-hand headlight wiper motor, V70 6/38 Motor, left headlight adjustment 6/113 Coolant pump, 8-cyl. 6/114 Vacuum pump...
  • Page 42 16/108 Multimedia Module (MMM), XC90 31/83 Ground connection 31/99 Left-hand side window 7/135 Glass breakage sensor, left-hand, V70 31/100 Engine ignition coils 20/50 Spark plug with ignition coil, 8-cyl. 20/52 Spark plug with ignition coil, 8-cyl. TP 39113202 V70/XC90 2008...
  • Page 43 2/192 Relay (230V), engine heater, accessory 31/120 Cargo compartment, accessory 4/110 Trailer Module 16/15 CD changer, V70 16/45 Road Traffic Information module (RTI), V70 16/46 RTI display, V70 16/79 Bass speaker, V70 16/79 Subwoofer Module (SUB), XC90 16/145 Satellite radio receiver, V70...
  • Page 44: Control Modules Overview Positions V70

    Control modules Overview positions V70 4/110 PDM/ 4/31 4/71 DDM/ 17/13 TP 39113202 V70/XC90 2008...
  • Page 45: Overview Designations V70

    Suspension Module (SUM) 3/254 Steering Wheel Module (SWM) 4/28 Transmission Control Module (TCM) 4/70 Upper Electronic Module (UEM) 4/31 4/31 Fan control module 4/71 4/71 Cooling fan control module 4/110 4/110 Trailer Module 17/13 17/13 Data link connector TP 39113202 V70/XC90 2008...
  • Page 46: Overview Positions Xc90

    Control modules Overview positions XC90 RDAR 4/110 PDM/ 4/31 DDM/ 4/71 17/13 TP 39113202 V70/XC90 2008...
  • Page 47: Overview Designations Xc90

    Subwoofer Module (SUB) 3/254 Steering Wheel Module (SWM) 4/28 Transmission Control Module (TCM) 4/70 Upper Electronic Module (UEM) 4/31 4/31 Fan control module 4/71 4/71 Cooling fan control module 4/110 4/110 Trailer Module 17/13 17/13 Data link connector TP 39113202 V70/XC90 2008...
  • Page 48: Central Electronic Module (Cem) 1:2

    10/15, 6/62:12 54/10 54/11 A:29 GN-W 10/16, 6/63:12 4/58A:20 A:16 54/36:5 D:43 54/36:3 D:44 54/36:1 D:45 54/36:2 D:29 7/12:4 D:30 7/12:1 D:42 7/12:5 B:25 16/35:1 54/25 A:22 GN-R 3/27:3 54/24 GN-R 3/27:3 16/1A:2 XC90 RSE 16/109A:7 TP 39113202 V70/XC90 2008...
  • Page 49 54/23 C:20 10/2A:3 XC90 10/12:1 54/22 C:19 10/1A:3 XC90 10/11:1 6/3:2 B:19 6/4:2 54/24 A:19 9/12:A4 54/25 A:18 9/13:A4 XC90 54/25:11 XC90 D:27 54/24:11 XC90 54/25:12 XC90 D:28 54/24:12 XC90 53/454 53/301 53/397 31/93 31/6 31/10 TP 39113202 V70/XC90 2008...
  • Page 50: Rear Electronic Module (Rem) 1:2

    GN-BN GN-BN 3/86:5 B:30 2/139:3 3/86:1 3/86:3 54/20 3/76:2 3/76:5 2/138:1 W/O PCL A:27 3/76:8 A:24 3/76:6 A:23 3/76:4 C:10 3/76:7 XC90 9/2B:1 XC90 54/13 7/136A:1 V70 USA B:27 BL-R 16/145A:7 A:32 D:12 53/602 31/47 31/72 TP 39113202 V70/XC90 2008...
  • Page 51: Rear Electronic Module 2:2

    USA V70/XC90 26/4:3 GN-W 4/110B:3 USA V70/XC90 GN-W 26/4:1 BN-W 4/110B:4 4/110A:7 4/110A:8 B:11 10/18B:1 XC90 10/18A:2 10/18A:3, 10/17A:3 13 POLE 17/39:8 53/735 7 POLE Y-SB 4/110A:2, 17/38:2 7 POLE BL-Y 13 POLE 17/39:10 USA XC90 17/38:5 TP 39113202 V70/XC90 2008...
  • Page 52: Data Communication High Speed Can V70

    Control modules Data communication high speed CAN V70 4/50 4/46 A:37 4/56 Bi-Fuel A:55 D:33 D:48 3/254 5 CYL B:13 4/28 4/68 B:13 DSTC D:31 AW55-51SN AW51AWD D:46 DSTC AUTO B:14 C:21 C:22 4/46 AUTO HS CAN B:22 High AUTO...
  • Page 53: Data Communication High Speed Can Xc90

    B8444S TF-80SC (AWD) B8444S 4/118 AUTO 53/585 HCM AWD 53/584 HCM AWD 4/82 AWD W/O HCM AWD W/O HCM 54/74 7/164 4/16 54/3.1 54/3.1 2WD W/O HCM DSTC DSTC D:32 2WD W/O HCM D:47 DSTC DSTC TP 39113202 V70/XC90 2008...
  • Page 54: Data Communication Low Speed Can V70

    Control modules Data communication low speed CAN V70 4/56 3/112 C°/F° D:37 B:24/52 B:23/51 A:10 D:52 B:26/54 B:25/53 A:11 3/126 16/1 54/10 DDM/PDM D:39 D:54 4/70 16/60 54/13 53/433 D:38 D:53 53/434 3/127 54/11 PDM/DDM D:34 D:49 LS CAN High...
  • Page 55: Data Communication Low Speed Can Xc90

    53/433 D:38 A:12 D:53 A:11 53/434 3/127 54/11 PDM/DDM D:34 D:49 LS CAN High D:40 4/52 D:55 54/24 LHD 54/25 RHD D:36 D:51 4/58 D:35 C:14 D:50 C:13 4/78 D:30 D:19 4/120 D:20 A:14 D:21 A:13 TP 39113202 V70/XC90 2008...
  • Page 56: Data Communication Lin 1:2

    GN-W 3/111 27/3 54/10 GN-W GN-W 4/56 C:16 D:24 54/9 D:41 GN-W C:32 GN-W D:58 GN-W 4/46 SWSL A:92 6 CYL 3/254 18/4 54/1B 4/46 GN-W GN-W GN-W A:88 GN-W 4/46 3/131 SWSR DIESEL A:25 8CYL TP 39113202 V70/XC90 2008...
  • Page 57 GN-W D:32 GN-W 4/118 GN-W GN-W GN-W GN-W 54/3.1 54/3.1 13 27 4/86 A:12 54/23 54/22 12 10 10/2 10/1 LHCU RHCU LIN ABL LIN ABL 10/1 10/2 LHCU RHCU LIN ABL XC90 XC90 LIN ABL TP 39113202 V70/XC90 2008...
  • Page 58: Data Communication Most Xc90

    Control modules Data communication MOST XC90 16/139 16/145 16/105 RDAR 16/60 W/O PHM W/O RDAR PERFORMANCE 16/108 16/94 16/1 16/79 54/66.2 PERFORMANCE TP 39113202 V70/XC90 2008...
  • Page 59: Group 23 Fuel System Engine Management System, Diesel 1:3

    6/143 BN-SB 10 9 7 6 4/109 A:21 A:88 GN-W 6/26B:1 4 3 2 1 GN-SB A:64 7/162 GN-Y A:65 GN-W A:19 Y-SB A:87 7/165 A:85 A:82 A:15 20/22 20/23 BL-R 20/24 GN-SB 20/25 GN-W 20/26 TP 39113202 V70/XC90 2008...
  • Page 60 B:15 LHD 1 / RHD 6 GR-R B:47 LHD 5 / RHD 2 BL-W LHD 6 / RHD 1 BL-R GN-SB LHD 4 / RHD 3 53/329 GN-SB 53/394 BL-R 53/397 53/305 GN-SB 31/93 31/48 31/73 TP 39113202 V70/XC90 2008...
  • Page 61 BL-SB BL-Y A:33 8/98 A:23 GR-R A:93 7/166 BN-GR A:34 BN-SB A:36 VO-W A:42 6/118 GR-R A:81 VO-W BN-P A:40 BN-SB A:52 6/120 A:24 GN-SB A:72 A:67 BN-SB GN-R A:18 VO-W A:11 8/111 GR-R A:47 A:94 TP 39113202 V70/XC90 2008...
  • Page 62: Engine Management System, 5-Cyl. 1:2

    53/309 A:30 GN-W 31/88 53/328 53/360 20/5 A:28 9/32 A:29 GN-GR GN-W 20/6 A:51 GN-W 20/7 A:50 6/120 BL-R A:35 31/89 GN-Y A:36 A:43 A:25 GN-SB A:34 53/314 A:52 A:53 53/326 A:54 A:62 A:17 31/96 BL-R TP 39113202 V70/XC90 2008...
  • Page 63 LHD 2 / RHD 5 GR-W LHD 1 / RHD 6 B:25 BL-W LHD 5 / RHD 2 6/44 BL-R LHD 6 / RHD 1 LHD 4 / RHD 3 53/329 53/397 BL-R 53/305 31/93 BL-R 31/48 TP 39113202 V70/XC90 2008...
  • Page 64: Engine Management System, 5-Cyl. Turbo 1:2

    GN-W Y-SB A:67 20/4 A:30 A:48 7/25 31/88 GN-W A:66 20/5 53/328 A:50 4/71:4 GN-W 20/6 A:52 GN-W 20/7 A:51 6/120 A:36 BL-R 31/89 GN-Y A:19 A:59 A:35 A:20 GN-SB A:53 53/326 A:54 A:63 31/96 BL-R TP 39113202 V70/XC90 2008...
  • Page 65 LHD 2 / RHD 5 B:17 BN-SB LHD 1 / RHD 6 GR-W B:25 LHD 5 / RHD 2 BL-W 6/44 LHD 6 / RHD 1 BL-R LHD 4 / RHD 3 53/329 53/397 BL-R 53/305 31/93 BL-R 31/48 TP 39113202 V70/XC90 2008...
  • Page 66: Engine Management System, 6-Cyl. 1:2

    A:58 53/360 A:62 GN-W 20/4 A:57 53/3006 GN-W 20/6 A:56 A:24 GN-R 7/81 A:23 BN-SB A:69 VO-W 31/88 31/89 6/139 VO-W A:38 GN-R 6/140 VO-SB A:39 GR-R 54/1B A:92 GN-W 6/26 B:1 GN-GR 53/396 GN-GR BL-R TP 39113202 V70/XC90 2008...
  • Page 67 BN-SB 6/33 B:32 GR-W LHD 1 / RHD 6 B:26 LHD 5 / RHD 2 BL-W LHD 6 / RHD 1 BL-R LHD 4 / RHD 3 53/329 53/397 GN-GR GN-GR BL-R 53/305 31/93 31/2 31/48 TP 39113202 V70/XC90 2008...
  • Page 68: Engine Management System, Bi-Fuel 1:2

    A:30 53/360 GN-W 31/88 53/328 20/5 A:28 A:29 GN-W 20/6 A:51 GN-W 20/7 9/32 A:50 A:39 BN-SB 31/89 4/50 A:56 BL-R GN-Y A:38 A:37 HISPEED A:55 A:36 A:53 53/326 A:54 A:62 31/91 31/96 BL-R GN-GR GN-GR TP 39113202 V70/XC90 2008...
  • Page 69 8/90 8/88 B:44 GN-W 2/22:4 54/54 54/3.1 B:46 5/1:2 B:48 54/7 B:32 P-SB P-SB 53/604 B:50 7/51 GR-R BN-SB B:17 6/105 GR-W BL-W B:25 BL-R 6/44 53/329 BL-R 53/305 53/397 31/93 BL-R GN-GR 31/73 GN-GR 31/48 TP 39113202 V70/XC90 2008...
  • Page 70: Engine Management System, 8-Cyl. 1:2

    CYL 4 A:62 A:54 53/360 GN-W 31/88 A:55 20/50 CYL 5 6/120 A:75 GN-W 20/51 CYL 6 A:74 A:11 A:67 GN-W A:24 20/52 CYL 7 A:65 31/89 A:16 GN-W 20/53 CYL 8 31/121 31/100 GN-GR GN-SB BL-R TP 39113202 V70/XC90 2008...
  • Page 71 LHD 2 / RHD 5 6/33 B:32 LHD 1 / RHD 6 GR-W 7/73 B:28 BL-W LHD 5 / RHD 2 LHD 6 / RHD 1 BL-R LHD 4 / RHD 3 53/329 GN-GR 53/397 GN-SB 53/305 31/93 BL-R 31/48 TP 39113202 V70/XC90 2008...
  • Page 72: Emission Control, 5-Cyl

    8/18 GN-GR BL-GN 54/34 5CYL W/O T B:40 7/15 53/304 A:69 Bi-Fuel GN-BN GN-BN A:18 BL-R BL-SB A:42 GN-R A:41 7/82 GN-BN A:11 A:24 53/319 BN-SB BN-SB A:61 Bi-Fuel A:57 7/172 Bi-Fuel A:65 Bi-Fuel A:47 B:13 TP 39113202 V70/XC90 2008...
  • Page 73: Emission Control, 5-Cyl. Turbo

    A:13 8/18 5CYL T GN-GR 6/67 7/15 A:18 GN-BN A:42 A:41 GN-SB A:28 BL-SB A:24 GN-R 54/34 7/82 GN-R GN-BN A:61 54/3.2 A:62 B:40 53/304 BL-SB B:13 53/375 A:29 7/173 A:65 53/376 BL-SB A:27 7/172 A:47 TP 39113202 V70/XC90 2008...
  • Page 74: Emission Control, 6-Cyl

    GN-R A:31 A:32 54/34 7/82 A:89 GN-BN A:41 GN-R 54/3.2 A:45 BN-SB B:46 53/304 7/103 A:76 BL-SB B:23 GN-BN A:10 BN-SB B:41 7/104 B:54 A:88 GN-BN A:40 BN-SB A:18 A:12 7/173 A:33 BL-SB A:11 7/172 A:34 TP 39113202 V70/XC90 2008...
  • Page 75: Emission Control, 8-Cyl

    8/118 B:58 GN-GR A:91 7/188 7/15 A:76 A:33 GN-BN A:28 A:29 7/189 A:31 7/82 A:77 GN-BN A:26 A:27 7/172 A:72 53/304 53/375 7/103 53/376 A:88 A:34 GN-BN A:40 A:22 7/173 7/104 A:89 A:32 GN-BN A:41 A:45 TP 39113202 V70/XC90 2008...
  • Page 76: Group 26 Cooling System Cooling Fan, 5-Cyl

    VO-W VO-W 5 CYL T B:13 4/46 4/71 54/1B 5 CYL W/O T 7/16 GR-R A:40 BN-SB BN-SB A:61 53/319 6/29 BN-SB B:13 A:21 BN-GR 5 CYL A:58 VO-W VO-W W/O T 53/332 A:55 A:37 31/2 TP 39113202 V70/XC90 2008...
  • Page 77: Cooling Fan, Diesel, 6-Cyl. & 8-Cyl

    4/46 DIESEL 7/16 A:60 GR-R A:56 BN-SB A:76 BN-SB A:79 BN-GR A:43 VO-W 4/71 B:58 DIESEL B:23 B:22 4/46 6/29 8 CYL B:49 7/16 A:68 A:12 BN-SB B:12 BN-GR 8 CYL B:19 VO-W B:45 B:58 31/96 TP 39113202 V70/XC90 2008...
  • Page 78: Group 27 Engine Control Cruise Control, 5-Cyl

    5CYL W/O T A:25 BL-R 5CYL W/O T 53/305 5CYL W/O T GN-SB 4/28 B:13 BL-R A:56 GN-Y A:38 AW55-51SN A:37 AW51AWD B:14 53/329 A:55 B:21 GN-W 3/156 4/50 53/397 54/3.1 GN-W Bi-Fuel GN-SB Bi-Fuel 31/91 31/93 31/84 TP 39113202 V70/XC90 2008...
  • Page 79: Cruise Control, Diesel, 6-Cyl. & 8-Cyl

    LHD 2 / RHD 5 A:67 B:47 GR-R LHD 3 / RHD 4 A:48 LHD 4 / RHD 3 GN-SB A:65 B:26 BL-W LHD 5 / RHD 2 LHD 6 / RHD 1 31/84 BL-R 31/93 TP 39113202 V70/XC90 2008...
  • Page 80: Group 32 Alternator And Voltage Regulator Power Supply

    C:13 53/3009 4/56 D:50 D:35 D:49 D:34 54/1B 5 CYL C:16 GN-W C:21 C:22 4/46 B:23 DIESEL A:88 GN-W B:22 DIESEL 4/46 B:45 8CYL A:25 B:58 8CYL 4/46 B:41 6CYL A:92 GN-W B:54 6CYL 31/53 17/17 TP 39113202 V70/XC90 2008...
  • Page 81: Group 33 Starting System Starting System, 5-Cyl

    GN-OR 54/1B GN-R GN-R BL-OR 5(87) 2(85) 53/3009 6/26A:1 17/17 4/56 C:22 C:21 D:60 D:15 D:49 D:16 BL-R D:34 53/443 AUTO C:28 BL-Y GN-R 8/37 4/46 B:23 7/123 B:15 53/324 53/331 5CYL B:13 53/397 31/53 31/93 TP 39113202 V70/XC90 2008...
  • Page 82: Starting System, Diesel, 6-Cyl. & 8-Cyl

    B:29 B:12 B:11 B:40 B:44 B:51 B:15 8CYL B:13 6CYL DIESEL/ B:23 4/28 54/57.1 6CYL/ B:34 DIESEL AUTO DIESEL 8CYL B:22 DIESEL AUTO/6CYL TF-80SC B:45 (AWD) 8CYL B:58 B:41 A:14 6CYL B:54 53/397 53/329 31/53 31/93 TP 39113202 V70/XC90 2008...
  • Page 83: High And Low Beams/Bi-Xenon & Daytime Running Lights V70

    Group 35 Lighting High and low beams/Bi-Xenon & Daytime running lights V70 11C/7 11C/9 11E/5 11E/4 11E/1 54/40D 4/56 53/399 D:49 D:34 53/425 11B/17 11B/16 GN-W D:58 D:41 GN-W BL-R B:27 B:28 3/254 3/111 B:23 53/398 54/22 54/23 53/438 BL-GN...
  • Page 84: High And Low Beams/Bi-Xenon & Daytime Running Lights Xc90

    4/56 D:49 D:34 53/425 11B/17 11B/16 GN-W D:58 D:41 BL-R GN-W B:27 B:28 3/254 3/111 B:23 53/398 53/438 10/1 10/2 MAIN MAIN BIFUNC BIFUNC A:6 A:1 A:3 A:5 54/22 54/23 53/301 53/303 53/397 31/84 31/93 31/94 TP 39113202 V70/XC90 2008...
  • Page 85: Active Headlights (Abl)

    18/4 7/91 4/118 4/68 GN-W GN-W GN-W GN-W 54/3.1 54/3.1 13 27 54/22 54/23 12 10 10/1 10/2 LHCU RHCU LIN ABL LIN ABL 10/1 10/2 LHCU RHCU LIN ABL XC90 XC90 LIN ABL 53/438 31/84 TP 39113202 V70/XC90 2008...
  • Page 86: Fog Lights

    4/56 D:41 GN-W B:17 B:18 53/438 D:50 D:35 D:49 D:34 10/5 10/6 4/58 C:14 C:13 53/301 10/18 10/17 XC90 XC90 XC90 10/46 10/53 53/303 53/397 10/18 10/17 10/53 10/46 53/601 53/604 31/94 31/72 31/73 31/84 31/93 TP 39113202 V70/XC90 2008...
  • Page 87: Brake Lights

    11E/1 54/40D B:11 D:50 D:35 D:34 D:49 C:34 A:15 GN-Y 4/58 A:18 XC90 XC90 10/19 C:14 C:13 10/3 53/606 XC90 10/17 10/18 XC90 XC90 10/50 XC90 XC90 10/43 10/18 10/17 10/50 10/43 53/601 53/604 31/72 31/73 TP 39113202 V70/XC90 2008...
  • Page 88: Reversing Lights

    Reversing lights 11E/1 4/56 D:50 D:35 Y-GR C:28 D:34 D:49 4/58 3/10 C:14 C:13 B:23 XC90 XC90 10/18 10/17 XC90 XC90 10/55 10/48 54/98 XC90 10/18 10/17 53/329 53/397 10/55 10/48 53/604 53/601 31/73 31/72 31/93 TP 39113202 V70/XC90 2008...
  • Page 89: Follow-Me-Home Lighting

    Group 35 Lighting Follow-me-home lighting 11C/5 11C/6 11C/5 11C/4 4/70 16/59 54/10 54/11 3/126 3/127 B:12 B:12 DDM/PDM PDM/DDM VO-SB 6/62 6/63 53/515 53/514 10/149 10/148 54/10 54/11 53/501 31/66 31/67 TP 39113202 V70/XC90 2008...
  • Page 90: Running/Parking Lights, Tail Lights & License Plate Lighting V70

    Group 35 Lighting Running/parking lights, tail lights & license plate lighting V70 3/111 4/56 D:50 15/31_A1:2 11E/4 11E/1 11C/7 11C/9 D:35 D:34 11B/19 11B/20 D:49 53/425 54/40D B:24 D:41 GN-W C:19 C:20 4/58 C:14 C:13 F:10 10/1 10/2 MAIN MAIN...
  • Page 91: Group 35 Lighting

    Group 35 Lighting Running/parking lights, tail lights & license plate lighting XC90 15/31_A1:2 11E/4 11C/9 11C/10 11E/1 53/425 11B/19 11B/20 54/40D B:24 4/58 C:14 10/11 10/12 C:13 F:10 10/71 10/73 54/22 3 54/23 TP 39113202 V70/XC90 2008...
  • Page 92: Interior Lighting V70

    10/126 3/126 C:13 B:12 BL-R DDM/PDM C:14 54/21 A:10 54/11 C:12 53/501 53/514 10/25 VO-W 54/10 54/20 53/601 53/505 53/583 3/74 3/76 54/13 53/503 54/13 54/10 53/405 54/20 53/500 31/67 31/72 31/98 31/6 31/66 31/46 31/83 TP 39113202 V70/XC90 2008...
  • Page 93: Interior Lighting Xc90

    54/21 54/11 10/114 C:13 A:10 C:14 8 20 3/126 B:12 53/501 10/172 DDM/PDM C:12 54/10 54/20 53/514 VO-W 10/173 3/74 3/76 53/503 53/505 54/10 54/13 53/606 54/13 53/405 54/20 53/500 31/98 31/83 31/6 31/66 31/46 31/67 TP 39113202 V70/XC90 2008...
  • Page 94: Beam Length Adjustment V70

    Group 35 Lighting Beam length adjustment V70 11E/4 11C/7 11C/9 54/40D 53/425 4/56 3/111 D:41 GN-W D:50 D:35 D:32 D:47 C:12 C:11 GN-R GN-BN 3/59 B:23 54/22 W/O Bi-X 6/38 53/398 54/23 GN-R 6/39 GN-R Bi-X 4/58 54/32 7/120 GN-R...
  • Page 95: Beam Length Adjustment Xc90

    GN-W D:50 D:35 C:12 C:11 GN-R GN-BN 3/59 B:23 54/22 W/O Bi-X 6/38 53/398 54/23 6/39 4/58 54/32 7/120 GN-R BL-R C:11 Bi-X Bi-X GR-W BN-W Bi-X 53/303 53/438 C:13 53/301 C:14 53/397 31/93 31/94 31/84 TP 39113202 V70/XC90 2008...
  • Page 96: Auxiliary Lights

    Group 35 Lighting, Accessories Auxiliary lights 11B/5 11B/4 3/112 3/60 4/56 C°/F° D:50 D:35 D:34 BN-W D:49 A:11 A:10 54/8 BN-W 2/64 10/69 10/65 31/70 TP 39113202 V70/XC90 2008...
  • Page 97: Group 36 Additional Electrical Equipment

    11C/7 11C/6 11C/12 11C/13 54/13 4/70 7/149 54/16 53/505 VO-W VO-W VO-W BL-W 4/56 54/13 53/503 D:11 C:31 BL-W D:53 D:38 D:34 54/13 D:49 D:58 XC90 LHD GN-W XC90 RHD 3/254 53/331 53/397 31/93 31/98 31/83 TP 39113202 V70/XC90 2008...
  • Page 98: Direction Indicators And Hazard Warning Flashers V70

    Group 36 Additional electrical equipment Direction indicators and hazard warning flashers V70 11E/4 11E/5 4/56 54/40D D:34 D:50 10/13 10/14 D:35 D:49 B:31 B:32 A:12 A:29 D:22 D:14 54/10 54/11 54/22 54/23 6/62 10/15 6/63 10/16 53/405 53/515 53/303 53/301...
  • Page 99: Direction Indicators And Hazard Warning Flashers Xc90

    D:14 54/22 54/23 6/62 10/15 6/63 10/16 53/405 53/301 53/514 53/515 53/303 4/58 A:21 A:20 C:14 C:13 B:11 B:10 53/397 54/11 54/10 10/18 10/17 10/54 10/47 53/501 53/601 53/604 31/93 31/66 31/72 31/73 31/67 31/6 31/94 TP 39113202 V70/XC90 2008...
  • Page 100: Wiper/Washer Windshield

    1(86) 3(30) B:21 BL-W C:31 2(85) 5(87) 4(87a) B:30 6/127 GN-Y 2/90 FST1 1(86) 3(30) 2(85) 5(87) 4(87a) XC90 LHD XC90 LHD XC90 RHD XC90 RHD XC90 LHD XC90 RHD GR-SB 53/331 53/302 53/397 31/93 31/1 TP 39113202 V70/XC90 2008...
  • Page 101: Wiper/Washer Headlights V70

    Group 36 Additional electrical equipment Wiper/washer Headlights V70 11E/4 11E/5 3/254 4/56 54/40D GN-W D:58 D:50 D:35 D:34 D:49 C:10 GN-Y B:29 B:21 B:19 B:30 6/127 31/93 31/1 TP 39113202 V70/XC90 2008...
  • Page 102: High Pressure Headlight Washer

    Group 36 Additional electrical equipment High pressure headlight washer 11B/3 11B/4 3/254 4/56 2/182 FST3 5(87) 4(87a) 1(86) D:58 D:50 GN-W D:35 3(30) 2(85) D:34 D:49 C:25 GN-SB C:10 GN-Y 6/104 6/104 53/302 31/1 TP 39113202 V70/XC90 2008...
  • Page 103: Wiper/Washer Rear Window

    Group 36 Additional electrical equipment Wiper/washer Rear window 11E/1 11E/4 11E/5 3/254 4/56 54/40D GN-W D:58 D:34 D:49 C:10 GN-Y D:35 D:50 B:29 B:21 6/127 B:30 4/58 C:14 C:13 XC90 53/302 54/50 53/601 31/72 31/1 TP 39113202 V70/XC90 2008...
  • Page 104: Horn

    11C/7 11C/9 11C/9 11C/10 11E/4 11E/5 4/56 D:50 D:35 D:58 GN-W D:34 53/425 D:49 54/40D D:17 3/254 B:15 3/37 18/4 54/4 16/11 R-SB 16/10 R-SB 16/10 R-SB 53/438 53/382 53/302 54/4 53/331 53/397 31/1 31/93 31/84 TP 39113202 V70/XC90 2008...
  • Page 105: Electronic Immobilizer

    Group 36 Additional electrical equipment Electronic immobilizer 11C/8 11C/7 11C/11 11C/9 16/65 4/56 D:49 BL-R 53/443 D:34 D:57 C:21 D:56 C:22 53/400 31/83 TP 39113202 V70/XC90 2008...
  • Page 106: Anti-Theft Alarm V70

    54/13 54/11 3/62 54/10 3/126 54/3.1 DDM/PDM 7/136 7/137 53/503 53/382 16/35 54/4 53/602 7/135 54/50 A:12 A:13 54/13 54/20 54/21 53/331 3/74 53/601 53/500 53/501 53/303 53/397 31/99 31/72 31/93 31/46 31/67 31/98 31/83 31/94 TP 39113202 V70/XC90 2008...
  • Page 107: Anti-Theft Alarm Xc90

    54/43 GR-W GR-W 53/606 54/13 54/11 53/508 54/10 3/126 54/3.1 54/3.1 DDM/PDM 53/503 7/158 16/35 3/62 GR-W 53/602 A:12 A:13 54/20 54/21 54/13 53/331 3/74 53/500 53/501 53/303 53/397 31/72 31/93 31/46 31/67 31/98 31/83 31/94 TP 39113202 V70/XC90 2008...
  • Page 108: Parking Assistance

    C:1/ C:6/ C:1/ C:6/ C:1/ C:6/ C:6/ C:7/ C:7/ C:10/ C:7/ C:10/ C:7/ C:10/ C:10/ C:8/ C:8/ C:11/ C:8/ C:11/ C:8/ C:11/ C:11/ C:12 C:12 C:12 C:12 7/131 LR/O 7/132 LR/I 7/133 RR/I 7/134 RR/O 31/72 TP 39113202 V70/XC90 2008...
  • Page 109: Alcohol Lock

    Group 36 Additional electrical equipment, Accessories Alcohol lock 11E/4 11C/7 11C/8 11C/9 11C/11 XC90 R-SB 3X/1 54/40D 11O/2 11O/1 R-SB BL-R 4/56 3X/1 D:60 D:15 53/408 4/58A:29 53/443 10X/29 D:49 D:34 2/240 BN-SB 10/29 2/241 53/405 31/6 TP 39113202 V70/XC90 2008...
  • Page 110: Accessory Electronic Module (Aem) 1:2

    Group 36 Additional electrical equipment, Accessories Accessory Electronic Module (AEM) 1:2 11E/1 4/58 4/78 B:22 D:30 D:19 53/604 C:14 C:13 4/56 D:50 D:35 D:49 D:34 31/73 TP 39113202 V70/XC90 2008...
  • Page 111 Output signal B:16 Alarm signal Output signal B:30 Antenna amplifier, audio Feed dimmer, RTI Japan Output signal B:33 Alarm signal Output signal RTI Japan Steering, X-feed B:34 Alarm signal Output signal Reverse gear signal, RTI Japan TP 39113202 V70/XC90 2008...
  • Page 112: Group 37 Wiring And Fuses Diagnostics System

    D:31 LOSPEED D:40 HISPEED D:46 D:55 LOSPEED HISPEED D:32 HISPEED D:47 LOSPEED D:34 LOSPEED D:49 LOSPEED D:35 LOSPEED D:50 LOSPEED D:36 LOSPEED D:51 LOSPEED D:37 LOSPEED D:52 LOSPEED D:38 LOSPEED D:53 LOSPEED D:39 LOSPEED D:54 31/84 TP 39113202 V70/XC90 2008...
  • Page 113: 12V Outlet

    Group 37 Wiring and fuses 12V outlet 11E/4 11E/1 4/56 4/58 54/40D A:17 B:31 D:50 D:35 C:14 D:34 C:13 D:49 D:12 10/161 17/19 54/134 53/406 53/604 9/25 9/25 31/10 31/73 TP 39113202 V70/XC90 2008...
  • Page 114: Tow Hitch Cable Harness, 4-Pin

    Group 37 Wiring and fuses Tow hitch cable harness, 4-pin 11E/1 4/110 17/37 Stop/Turn Right Stop/Turn Left A:11 Position A:10 Stop/Turn Signal A:12 Left Stop/Turn Signal Right 26/4 4/58 C:13 C:14 31/120 TP 39113202 V70/XC90 2008...
  • Page 115: Tow Hitch Cable Harness, 4/7-Pin

    Tow hitch cable harness, 4/7-pin 11E/1 4/110 17/38 17/37 Position Stop/Turn Right OR-W A:11 Stop/Turn Left A:10 Stop/Turn Signal A:12 Left Stop/Turn Signal Right 26/4 4/58 RESERVE: REVERSE LIGHTS RESERVE: EXT. D6 STOP LIGHTS / ELECTRICAL BRAKE C:13 C:14 31/120 TP 39113202 V70/XC90 2008...
  • Page 116: Tow Hitch Cable Harness, 7-Pin

    Group 37 Wiring and fuses, Accessories Tow hitch cable harness, 7-pin 11E/1 4/110 Turn Left 53/735 17/38 Fog Light Turn Right 53/734 Y-SB Position A:11 Stop Lights A:10 53/733 A:12 4/58 Reverse Lights EXT. D6 C:13 C:14 31/120 TP 39113202 V70/XC90 2008...
  • Page 117: Tow Hitch Cable Harness, 13-Pin

    Tow hitch cable harness, 13-pin 11E/1 4/110 Turn Left Fog Light Turn right 53/734 Y-SB Position Stop Lights A:11 A:10 A:12 4/58 17/39 Reverse Lights EXT. D6 C:13 C:14 53/733 RESERVE: INDICATION TRAILER RESERVE: CHARGING COMMON RETURN 31/120 TP 39113202 V70/XC90 2008...
  • Page 118: Accessory Usb Unit (Auu), Xc90

    Group 37 Wiring and fuses, Accessories Accessory USB unit (AUU), XC90 11E/4 11E/5 11C/9 4/56 54/40D D:52 D:37 D:58 EXT. D3 53/452 VO-W 54X/112 VO-W 53/454 54/112 VO-W 4/124 17/42 53/438 16/1 PERFORMANCE PERFORMANCE 16X/1C 16/105 16X/105D 31/84 TP 39113202 V70/XC90 2008...
  • Page 119: Group 38 Instruments Seat Belt Reminder

    Seat belt reminder 4/56 D:52 XC90 D:37 7/175 54/25 D:49 54/24 D:27 D:34 D:28 D:47 D:32 54/24 3/93 A:26/26 OR-SB A:25/25 B:25/53 B:23/51 B:24/52 54/25 B:26/54 3/94 C:25/81 C:26/82 OR-SB 4/16 7/32 7/31 BN-P BN-GR Y-GR 4/70 TP 39113202 V70/XC90 2008...
  • Page 120: Driver Information Module, 5-Cyl

    BL-W 5CYL W/O T A:68 B:13 7/35 53/397 BL-W A:40 5CYL T 6/31 6/33 BN-SB 53/332 5CYL T A:39 VO-W VO-W 7/130 7/143 A:58 5CYL W/O T VO-W B5244T5, B5254T2 USA, B5254T2 KOR 31/93 31/83 31/1 TP 39113202 V70/XC90 2008...
  • Page 121: Driver Information Module, Bi-Fuel

    54/54 C:10 7/11 A:14 A:18 54/36 54/3.1 7/156 4/46 B:46 A:39 BN-SB 6/33 53/400 7/73 7/143 Bi-Fuel 7/16 A:40 GR-R 53/329 A:61 BN-SB BN-SB A:55 53/319 A:37 7/25 53/397 53/302 A:48 A:66 B:13 31/93 31/83 31/1 TP 39113202 V70/XC90 2008...
  • Page 122: Driver Information Module, Diesel

    4/46 54/3.1 7/16 6/33 B:37 A:60 GR-R A:56 BN-SB B:35 53/400 7/130 7/143 7/73 DIESEL 54/100 7/25 53/329 GR-R GR-R A:77 A:53 53/302 B:22 7/166 53/397 BN-GR A:34 B:23 A:36 BN-SB A:42 VO-W 31/93 31/83 31/1 TP 39113202 V70/XC90 2008...
  • Page 123: Driver Information Module, 6-Cyl

    A:68 A:13 BN-SB B:12 53/400 7/130 7/143 7/73 7/25 A:30 6 CYL USA/KOR 6/31 6/33 53/329 7/130 7/143 7/35 A:63 BL-W 53/302 53/462 A:21 BN-SB BN-SB B:54 A:47 VO-W VO-W 53/397 53/332 B:41 31/93 31/83 31/1 TP 39113202 V70/XC90 2008...
  • Page 124: Driver Information Module, 8-Cyl

    PDM/DDM 54/36 A:18 A:14 4/46 54/3.1 7/16 B:55 A:68 A:12 B:43 53/400 6/31 6/33 A:16 7/73 7/130 7/143 7/25 A:30 8 CYL 53/329 54/133 7/35 A:63 53/302 A:17 B:58 53/397 B:45 54/129 A:47 31/93 31/83 31/1 TP 39113202 V70/XC90 2008...
  • Page 125: Group 39 Other

    Group 39 Other Audio with auxiliary amplifier V70 1:2 11E/4 11C/10 11C/11 4/56 54/40D D:52 16/1 D:37 D:58 53/448 A:12 D:47 D:32 D:50 31/84 D:35 54/144 MELBUS 17/40.2 54/134.2 4/16 BL-W + ANT 16/16 AM/FM 16/50 16/68 16/67 54/145 A:10...
  • Page 126 Group 39 Other Audio with auxiliary amplifier V70 2:2 11E/1 16/2 B:11 GR-W AMPLIFIER B:12 GR-R GR-R GR-W 54/14 6 5 12 11 54/11 54/10 10 9 53/524 GR-W 53/523 53/525 GR-W 54/43 53/526 54/43 53/654 54/43 53/653 54/20 54/21...
  • Page 127: Audio V70

    GR-R GR-R + LF 16/4 - LF 54/20 53/523 GR-W GR-W GR-W + LR 16/6 - LR 53/524 54/43 GR-W GR-W 16/57 BL-W + ANT 16/16 A:12 31/84 16/50 3/131 3/254 18/4 SWSL SWSR 4/16 4/56D:58 TP 39113202 V70/XC90 2008...
  • Page 128: Audio Xc90

    C:13 BN-GR GR-R A:10 C:15 BN-GR C:17 BN-GR C:16 Y-GR BN-GR C:14 VO-W 16/112 GR-W C:18 BN-GR GR-R C:20 BN-GR C:22 BN-GR A:10 C:21 Y-GR C:10 BN-GR C:19 VO-W 3/131 3/254 18/4 SWSL SWSR 4/56D:58 31/84 TP 39113202 V70/XC90 2008...
  • Page 129: Audio Performance Xc90

    D:52 53/454 EXT. D3 D:37 54/40D 16/1 17/40 GR-R 54/134 A:10 D:58 A:14 A:11 GR-R A:12 A:13 16/16 16/71 16/54 16/50 FM SUB FM MAIN/AM 16/55 GR-R 53/438 16/4 16/6 54/20 54/10 GR-W GR-R GR-W 31/84 TP 39113202 V70/XC90 2008...
  • Page 130: Road Traffic Information Module (Rti) V70

    Group 39 Other Road Traffic Information module (RTI) V70 4/56 4/58 11E/4 D:58 11E/1 11C/11 11C/12 D:37 D:35 C:14 D:52 D:50 C:13 54/40D 16/73 16/74 16/16 16/71 16/50 16/54 16/68 16/67 16/45 16/46 16/36 B:10 A:13 53/423 A:15 C:10 B:10...
  • Page 131: Portable Navigation System

    Group 39 Other, Accessories Portable navigation system 11E/1 11E/4 54/40D 4/56 16/45 9X/1 FUSE 2A NAVI A:17 PORTABLE D:50 D:35 D:34 D:49 53/406 31/10 TP 39113202 V70/XC90 2008...
  • Page 132: Road Traffic Information Module (Rti) Xc90

    Road Traffic Information module (RTI) XC90 11E/4 11E/5 11C/9 4/56 54/40D D:52 D:37 D:50 D:35 EXT. D3 16X/1B 16/1 53/452 VO-W 54X/112 VO-W 53/454 16X/1C 54/112 VO-W 53/438 31/84 VO-W A:1 A:3 16/108 16/46 VO-W VO-W B:10 B:10 TP 39113202 V70/XC90 2008...
  • Page 133: Handsfree V70

    Group 39 Other, Accessories Handsfree V70 16/1 (54/14) 16X/1A BL-W GR-R A:10 A:11 A:12 16X/1B, 54X/14 GR-R GR-R GR-R GR-R GR-W B:11 GR-W B:12 16/93 UNIVERSAL GR-W 4/78 B:11 16/127 16/64 16/126 TP 39113202 V70/XC90 2008...
  • Page 134: Handsfree Xc90

    Group 39 Other, Accessories Handsfree XC90 16/105 16X/105B GR-R GR-R GR-R B:10 GR-R GR-R B:11 GR-R GR-R B:12 GR-W B:13 GR-W B:16 VO-W 54/112 VO-W 54X/112 16/93 UNIVERSAL 16/64 16/127 4/78 GR-W B:11 16/126 TP 39113202 V70/XC90 2008...
  • Page 135: Handsfree Max V70

    Group 39 Other, Accessories Handsfree MAX V70 16/1 (54/14) 16X/1A BL-W GR-R A:10 A:11 A:12 16X/1B, 54X/14 GR-R GR-R GR-R GR-R GR-W B:11 GR-W B:12 16/93 GR-W GR-SB GR-SB 4/78 B:11 16/127 16/126 16/64 TP 39113202 V70/XC90 2008...
  • Page 136: Handsfree Max Xc90

    Group 39 Other, Accessories Handsfree MAX XC90 16/105 16X/105B GR-R GR-R GR-R B:10 GR-R GR-R B:11 GR-R GR-R B:12 GR-W B:13 GR-W B:16 VO-W 54/112 VO-W 54X/112 16/93 16/127 4/78 GR-W B:11 16/126 16/64 TP 39113202 V70/XC90 2008...
  • Page 137: Cd Changer V70

    Group 39 Other, Accessories CD changer V70 4/58 4/56 11E/1 11E/4 11C/10 11C/11 D:37 54/40D D:52 C:14 D:35 C:13 D:50 16/15 16/1 CHANGER A:12 16/45 D:1 R-W 16X/45D 53/602 53/448 31/72 31/120 31/84 TP 39113202 V70/XC90 2008...
  • Page 138: Rti & Cd Changer V70

    Group 39 Other, Accessories RTI & CD changer V70 4/56 4/58 11E/4 D:58 11E/1 D:37 D:35 C:14 D:52 D:50 C:13 54/40D D:20 D:21 16/15 16/1 16X/1A CHANGER BL-W A:10 GR-R A:11 A:12 16/45 16/46 53/736 53/737 TP 39113202 V70/XC90 2008...
  • Page 139: Mp3 Player V70

    Group 39 Other, Accessories MP3 player V70 4/58 11E/1 D:21 D:20 C:14 C:13 16/149 16/1 16/45 16X/45D 53/602 31/72 TP 39113202 V70/XC90 2008...
  • Page 140: Cellular Phone V70

    Group 39 Other Cellular phone V70 11C/11 11C/13 54/24 16/78 54/25 GR-R 16/77 A:1S 16/60 16/63 16/62 16/64 54/143 GSM/GPS HANDSET 4/56 D:52 D:37 D:19 53/438 D:58 3/131 3/254 18/4 SWSL SWSR GN-W 31/84 TP 39113202 V70/XC90 2008...
  • Page 141: Subwoofer V70

    B:12 GR-W 53/448 54/14 7 12 11 31/84 53/524 GR-W 53/525 GR-W 53/523 53/526 54/43 54/43 16X/58 16X/57 54/20 54/21 16/57 16/6 16/5 16/58 GR-W GR-W 16/79 12 11 8 4/58 C:14 C:13 B:17 B:18 31/120 TP 39113202 V70/XC90 2008...
  • Page 142: Subwoofer Xc90

    Group 39 Other, Accessories Subwoofer XC90 11E/1 4/58 C:14 C:13 B:19 EXT. D5 16/79 31/120 TP 39113202 V70/XC90 2008...
  • Page 143: Satellite Radio V70

    Group 39 Other, Accessories Satellite radio V70 11E/1 4/58 D:20 D:21 C:13 C:14 16/153 B:27 16/145 SDARS BL-R A:15 16/1 W/O RTI 16/45 31/120 TP 39113202 V70/XC90 2008...
  • Page 144: Satellite Radio Xc90

    Group 39 Other, Accessories Satellite radio XC90 11C/9 16/153 16/145 RDAR VO-W 53/452 53/438 16/105 16/1 16/94 31/84 TP 39113202 V70/XC90 2008...
  • Page 145: Rear Seat Entertainment V70 1:2

    Group 39 Other Rear seat entertainment V70 1:2 4/56 A:17 D:52 D:37 11E/4 11C/11 D:58 16/2 54/40D 16X/2A 16X/2B 54/14 54/11 16/3 GR-R GR-R GR-R GR-R 16/56 GR-R 16/55 GR-R 16/4 GR-R GR-R GR-R GR-R 54/10 16/122 B:11 SB-W B:12...
  • Page 146 Group 39 Other Rear seat entertainment V70 2:2 11E/1 11E/2 4/58 9X/25 C:13 C:14 4/56D:12 31/10 11M/1 11M/2 53/1405 10X/18A 54/137A 31/72 10/18 53/1403 9/25 54/1401 10/55 53/1404 10/161 16/122 16/82 54/1401 D:16 D:17 GR-R GR-R 16/81A 54/1401 54/274 54/276...
  • Page 147: Rear Seat Entertainment Xc90

    E:12 E:11 E:10 16/123.3 AV-IN VO-GR VO-GR W-SB D:21 54/1402 16/81B 54/277 54/140 D:18 RCA RCA RCA E:13 D:19 E:14 VO-GR VO-GR E:15 E:16 E:17 E:18 D:23 E:20 E:19 D:24 E:22 D:10 E:23 E:24 54/1401 31/84 TP 39113202 V70/XC90 2008...
  • Page 148: Rear Seat Entertainment Xc90

    E:12 E:11 E:10 16/123.3 AV-IN VO-GR VO-GR W-SB D:21 54/1402 16/81B 54/277 54/140 D:18 RCA RCA RCA E:13 D:19 E:14 VO-GR VO-GR E:15 E:16 E:17 E:18 D:23 E:20 E:19 D:24 E:22 D:10 E:23 E:24 54/1401 31/84 TP 39113202 V70/XC90 2008...
  • Page 149: Infotainment Xc90

    A:16 31/73 VO-W 3/267 A:15 A:14 BN-R 31/84 16/108 A:1 C:2 C:1 16/46 BL-W 3/131 4/56D:58 3/254 GN-W 18/4 SWSL SWSR 3/135 OR-SB A:13 BL-BN CALL B:10 B:10 16/71 53/400 16/54 FM SUB 31/83 MMM EU/OS TP 39113202 V70/XC90 2008...
  • Page 150: Rear Seat Entertainment Roof Mounted Xc90

    Group 39 Other, Accessories Rear seat entertainment roof mounted XC90 11E/1 4/58 C:13 C:14 D:34 54/98 10/18 53/604 16/82 31/73 TP 39113202 V70/XC90 2008...
  • Page 151: Parking Camera, Xc90

    GR-R D:35 11E/4 11E/5 D:52 FUSE 5A D:37 C:13 54/40D C:14 53/454 EXT. D3 D:19 D:30 11C/9 53/452 53/400 16X/108A 16/108 16X/108B 16/46 B:10 4/120 A:15 A:13 A:14 B:2 B:3 B:5 B:6 B:4 27/6 31/120 31/83 TP 39113202 V70/XC90 2008...
  • Page 152: Aem & Parking Camera, Xc90

    4/56 B:22 11E/1 EXT. D6 GR-R D:50 FUSE 5A D:35 C:13 D:52 C:14 D:37 D:19 D:30 11C/9 53/452 53/400 4/78 16/108 16X/108B 16/46 B:10 4/120 A:15 A:13 A:14 B:2 B:3 B:5 B:6 B:4 27/6 31/120 31/83 TP 39113202 V70/XC90 2008...
  • Page 153: Group 43 Transmission Automatic Transmission Aw55-51Sn/Aw51Awd

    C:21 D:32 D:47 B:13 54/40D C:28 BL-Y B:20 VO-W EXT. D2 4/28 AW 55-51SN / AW 51AWD PRNDL SW ENC 8/37 54/3.1 53/303 C PA 7/62 7/61 7/74 3/71 3/156 3/155 53/397 BN-SB 53/331 31/93 31/94 TP 39113202 V70/XC90 2008...
  • Page 154: Automatic Transmission Tf-80Sc Awd, 8-Cyl

    53/352 SLC3G B:22 A:14 53/353 HISPEED 8/71 SLTG 8/40 SLUG C:21 C:22 4/56 8/38 D:16 A:11 C:13 BL-R 8/39 GN-W D:47 D:32 D:23 A:25 EXT. D2 3/156 8/36 3/155 VO-W BL-W GN-W 53/329 54/3.1 53/397 31/93 TP 39113202 V70/XC90 2008...
  • Page 155: Automatic Transmission Tf-80Sc/Tf-80Sc Awd 6-Cyl. & Diesel

    A:14 53/353 HISPEED 8/71 SLTG 8/40 SLUG C:21 C:22 4/56 8/38 D:16 A:11 C:13 BL-R BL-R 8/39 GN-W GN-W D:47 D:32 4/16 D:23 A:25 EXT. D2 3/156 8/36 3/155 VO-W BL-W GN-W 53/329 54/3.1 53/397 31/93 TP 39113202 V70/XC90 2008...
  • Page 156: Geartronic Aw55-51 Sn/Aw51 Awd

    11E/4 11E/5 4/56 C:22 54/40D C:21 D:32 D:23 BL-W D:47 A:25 VO-W EXT. D2 B:20 EXT. D2 4/28 3/156 A:35 VO-W AW 55-51SN / B:13 AW 51AWD 54/3.1 B:21 GN-W GN-W B:14 A:54 A:53 53/303 31/94 TP 39113202 V70/XC90 2008...
  • Page 157: Shift Lock Aw51 & Manual

    3/156 4/28 54/3.1 B:21 AUTO AUTO GN-W GN-W AW 55-51SN / AW 51AWD AUTO 8/36 AUTO AUTO B:13 B:14 A:53 A:54 54/3.1 AUTO AUTO 53/329 MAN (M66) MAN (M66) 8/134 MAN (M66) 53/397 53/303 31/93 31/94 TP 39113202 V70/XC90 2008...
  • Page 158: Differential Electronic Module (Dem)

    Group 43 Transmission Differential Electronic Module (DEM) 11E/1 4/58 C:14 C:13 A:14 54/74 4/82 BL-R 31/46 TP 39113202 V70/XC90 2008...
  • Page 159: Group 59 Brake System Brake Control System

    18/4 7/124 7/91 7/129 54/55 RHD DSTC GN-BN 4/68 53/331 GN-W GR-W DSTC GN-BN DSTC GN-W DSTC GR-W 7/139 54/56 RHD DSTC 53/397 BL-BN OR-W 53/438 GR-OR DSTC BL-BN DSTC OR-W DSTC GR-OR 31/95 31/84 31/93 TP 39113202 V70/XC90 2008...
  • Page 160: Group 64 Steering Electronic Power Steering

    Group 64 Steering Electronic power steering 11E/4 54/40D 4/56 6/71 4/99 C:17 GN-W B:23 53/398 D:49 D:34 C:21 C:22 53/329 53/397 31/93 TP 39113202 V70/XC90 2008...
  • Page 161: Group 76 Shock Absorbers Four-C V70

    BN-W A:10 VO-W VO-W 7/87 A:22 7/88 53/354 7/118 A:12 53/355 7/119 A:27 A:17 Y-VO 7/89 53/570 A:19 A:13 A:15 53/569 A:16 8/23 54/107 GN-GR GN-GR A:23 7/121 A:14 A:25 7/120 A:28 8/22 GN-GR GN-GR 31/10 TP 39113202 V70/XC90 2008...
  • Page 162: Group 83 Doors And Openings Central Locking System V70

    Group 83 Doors and openings Central locking system V70 3/112 3/173 11C/8 11C/7 11C/5 11C/4 11E/1 A:11 C°/F° 4/56 4/58 A:10 3/73 D:35 C:14 D:50 C:13 X 15 D:15 A:23 54/11 4/70 D:53 A:24 D:38 A:27 16/59 D:39 54/10 3/78...
  • Page 163: Central Locking System Xc90

    A:11 3/80 A:11 3/82 B:2 B:6 54/43 3/85 3/86 54/10 54/20 54/21 54/11 2/138 2/139 3/74 4 2 5 4 2 5 VO-W VO-W 3/77 53/500 3/76 54/21 3/75 53/501 3/86 54/20 3/85 31/67 31/66 31/46 TP 39113202 V70/XC90 2008...
  • Page 164: Power Windows

    A:19 A:24 A:23 A:16 A:19 A:24 A:23 A:16 GN-BN B:30 GN-BN A:19 6/58 6/60 54/43 54/20 54/21 53/514 53/515 54/10 GN-BN GN-BN 54/11 3/85 3/86 10/152 10/151 54/20 54/21 53/500 53/501 6/92 6/93 31/67 31/66 31/46 TP 39113202 V70/XC90 2008...
  • Page 165: Power Sunroof

    Group 83 Doors and openings Power sunroof 11C/7 11C/13 3/25 5 1 3 3/117 4/70 C:11 4/33 53/503 VO-W 53/505 54/13 53/583 A:10 54/13 54/13 6/15 53/405 31/83 31/6 31/98 TP 39113202 V70/XC90 2008...
  • Page 166: Group 84 Exterior Decorative Elements, Etc

    3/112 3/171 C°/F° XC90 XC90 54/10 54/11 53/514 53/515 3/127 3/126 B:12 B:12 PDM/DDM DDM/PDM A:26 A:27 A:28 A:9 A:10 A:25 A:26 A:27 A:28 A:29 A:9 A:10 A:25 A:29 54/11 54/10 6/63 6/62 53/501 31/67 31/66 TP 39113202 V70/XC90 2008...
  • Page 167: Blind Spot Information System

    Group 84 Exterior decorative elements, etc. Blind spot information system 11E/4 54/40D GN-W 54/11 GN-W GN-W 4/56 54/10 53/515 D:24 53/514 6/62 6/63 27/4 27/3 54/11 54/10 54/10 54/11 BL-R BL-R 53/501 31/66 31/67 TP 39113202 V70/XC90 2008...
  • Page 168: Heated Exterior Rearview Mirrors

    54/40D 3/112 XC90 XC90 C°/F° 4/56 54/10 54/11 A:10 A:11 54/11 BL-R 54/10 3/127 3/126 B:12 B:12 DDM/PDM PDM/DDM B:11 B:11 6/62 6/63 9/33 27/3 9/34 27/4 53/515 53/514 BLIS BLIS 54/11 54/10 53/501 31/67 31/66 TP 39113202 V70/XC90 2008...
  • Page 169: Heated Rear Window

    Group 84 Exterior decorative elements, etc. Heated rear window 11E/1 3/112 4/58 C°/F° C:14 C:13 A:10 A:11 XC90 54/50 53/601 31/72 TP 39113202 V70/XC90 2008...
  • Page 170: Group 85 Interior Equipment Power Driver's Seat

    RHD 2 VO-W C:10 VO-SB C:11 FORWARD BACK 6/18 LHD 2 RHD 1 LHD 1 BL-Y RHD 2 C:16 Y-SB FORWARD BACK C:12 6/17 C:13 E:10 BL-SB E:11 DOWN BL-R C:14 E:12 C:15 BL-SB DOWN 31/46 31/67 TP 39113202 V70/XC90 2008...
  • Page 171: Power Passenger Seat

    Group 85 Interior equipment Power passenger seat 11E/4 11C/3 11C/4 11C/2 54/40D 3/27 4/56 6/65 BL-SB DOWN 6/66 Y-SB DOWN A:22 6/20 VO-SB FORWARD BACK 6/64 GN-SB FORWARD 54/25 STOP LOGIC BACK 54/24 GN-R BL-R 53/501 53/500 31/67 31/46 TP 39113202 V70/XC90 2008...
  • Page 172: Heated Seats

    Heated seats 11E/4 4/56 54/40D D:49 D:34 A:19 A:18 3/112 3/91 A:10 C°/F° A:11 54/132 3/92 GN-W GN-W A:12 GN-W GN-W 54/24 54/25 9/12 9/13 9/16 9/17 7/110 7/111 9/18 9/19 54/24 54/25 53/500 53/501 31/46 31/67 TP 39113202 V70/XC90 2008...
  • Page 173: Group 87 Climate Control System Rear Climate Control System Xc90

    Group 87 Climate control system Rear climate control system XC90 11E/1 4/58 C:13 C:14 B:19 EXT. D5 6/76 REAR 53/601 31/72 TP 39113202 V70/XC90 2008...
  • Page 174: Climate Control System, 5-Cyl. 1:2

    B:38 GR-R A:40 5 CYL 7/16 W/O T A:61 BN-SB BN-SB 53/319 BN-SB B:13 A:21 BN-GR A:58 VO-W VO-W 53/332 A:55 A:37 B:11 3/112 C°/F° 4/31 6/28 7/41 54/132 A:13 EVAP A:10 7/10 A:11 31/10 31/6 TP 39113202 V70/XC90 2008...
  • Page 175 7/12 Y-GN D:42 C:22 C:21 D:32 6/96 D:47 EXT. D1 A:10 RHD MCC 53/461 Y-GN 6/102 53/458 53/460 53/459 6/48 54/132 Y-GN 3/112 C°/F° 6/69 6/103 Y-GN 7/159 A:12 GN-W Y-GN VO-W GN-W A:16 53/438 31/84 TP 39113202 V70/XC90 2008...
  • Page 176: Climate Control System, Diesel, 6-Cyl. & 8-Cyl. 1:2

    B:31 VO-W B:41 B:54 B:16 4/46 BL-GN B:53 B:16 A:49 8 CYL A:68 7/16 A:12 BN-SB B:12 BN-GR B:19 VO-W B:45 B:58 B:54 3/112 C°/F° 4/31 6/28 7/41 54/132 A:13 EVAP 7/10 A:10 A:11 31/10 31/6 TP 39113202 V70/XC90 2008...
  • Page 177 7/12 Y-GN D:42 C:22 C:21 D:32 6/96 D:47 EXT. D1 A:10 RHD MCC 53/461 Y-GN 6/102 53/458 53/460 53/459 6/48 54/132 Y-GN 3/112 C°/F° 6/69 6/103 Y-GN 7/159 A:12 GN-W Y-GN VO-W GN-W A:16 53/438 31/84 TP 39113202 V70/XC90 2008...
  • Page 178: Parking Heater, Auxiliary Heater

    7/143 D:45 7/130, 7/143 GND 54/40D EXT. D1 B:10 D:49 D:34 C:21 C:22 C:32 54/9 GN-W GN-W VO-W VO-W BL-SB 6/73 W-SB 54/9 54/3.1 6/35 9/30 OVERHEAT FLAME TEMP GLOW 54/9 53/501 53/331 53/397 31/67 31/93 TP 39113202 V70/XC90 2008...
  • Page 179: Relay, Electric Engine Heater

    Group 87 Climate control system, Accessories Relay, electric engine heater 11E/1 4/58 B:22 4/78 D:30 D:19 2/192 RELAY 53/604 31/102 31/73 TP 39113202 V70/XC90 2008...
  • Page 180: Remote Parking Heater Start V70

    Group 87 Climate control system, Accessories Remote parking heater start V70 11E/1 4/58 B:22 D:19 D:30 4X/78A 4/78 4/106 10/218 53/604 2/191 31/73 TP 39113202 V70/XC90 2008...
  • Page 181: Parking Heater Call Start V70

    Group 87 Climate control system, Accessories Parking heater call start V70 11E/1 4/58 B:22 4/78 D:30 D:19 53/604 4/107 31/73 TP 39113202 V70/XC90 2008...
  • Page 182: Auxiliary Heater V70

    Group 87 Climate control system, Accessories Auxiliary heater V70 4/56 11E/4 11E/5 54/36 D:43 11B/4 7/130 D:44 7/143 D:45 7/130, 7/143 GND 54/40D EXT. D1 B:10 D:49 D:34 C:21 C:22 C:32 54/9 GN-W GN-W VO-W VO-W 6/73 54/9 53/331 53/397 31/93 TP 39113202 V70/XC90 2008...
  • Page 183: Group 88 Internal Equipment Remote Garage Door Opener

    Group 88 Internal equipment Remote garage door opener 11C/7 11C/6 11C/12 11C/13 54/13 4/70 10/114 4/76 53/505 VO-W VO-W 54/13 54/13 53/503 53/583 53/405 31/6 31/83 31/98 TP 39113202 V70/XC90 2008...
  • Page 184: Supplemental Restraint System Module (Srs) V70

    Group 88 Internal equipment Supplemental Restraint System module (SRS) V70 11E/4 11C/8 11C/7 11E/5 A:1-A:28 = 1-28 B:1-B:28 = 29-56 54/40D C:1-C:28 = 57-84 BL-R 53/443 4/56 18/4 8/30 3/157 EU/OS B:28/56 B:8/36 B:22/50 B:7/35 OR-W BL-OR B:9/37 8/61 B:10/38...
  • Page 185: Supplemental Restraint System Module (Srs) Xc90

    8/62 C:24/80 A:14/14 C:23/79 GN-OR GN-OR 8/95 54/43B C:13/69 8/66 54/40B OR-W OR-W C:14/70 A:21/21 OR-SB A:22/22 OR-SB 8/97 C:11/67 C:12/68 GR-OR GR-OR 8/99 54/43B 8/67 USA/CDN B:15/43 OR-SB C:21/77 OR-SB C:22/78 OR-W B:16/44 USA/CDN 31/67 TP 39113202 V70/XC90 2008...
  • Page 186: Connectors

    Fuse in engine compartment GN-SB (ECM) fuse box 4/50:6 Electronic Throttle Module (ETM) 53/314 Branching point 54/1C 2-pin gray Engine compartment harness Diesel engine harness 11A/1:2 Main fuse in engine compart- 4/109:11 Glow plug control module ment fuse box TP 39113202 V70/XC90 2008...
  • Page 187 Rear Electronic Module 54/4:3 Connector, V70 (REM) 3/62:1 Hood alarm contact, XC90 54/13:15 Connector 16/35:2 Siren Control Module (SCM) 5/1:6 Driver Information Module 7/4:1 Brake fluid level sensor (DIM) 6/35:1 Fuel pump, auxiliary heater 54/9:2 Connector continues TP 39113202 V70/XC90 2008...
  • Page 188 Suspension Module (SUM), VO-W 7/87:1 Acceleration sensor, Four-C, VO-W front left, V70 4/84A:12 Suspension Module (SUM), 7/118:2 Acceleration sensor, shock absorber, Four-C, front left, V70 4/84A:6 Suspension Module (SUM), 8/20:1 Shock absorber, Four-C, front left, V70 4/84A:7 Suspension Module (SUM), BL-R 8/20:2...
  • Page 189 Engine compartment harness Engine harness, Bi-Fuel 4/46B:39 Engine Control Module 8/75:1 Valve, fuel cut-off DFCO (ECM) 4/46B:50 Engine Control Module P-SB 6/105:2 Fuel distributor, gas P-SB (ECM) 4/46B:32 Engine Control Module 6/105:1 Fuel distributor, gas (ECM) TP 39113202 V70/XC90 2008...
  • Page 190 Left power exterior rearview mirror 4/56A:12 Central Electronic Module 10/15:12 Direction indicator, front left GN-W (CEM), XC90 fender, XC90 4/58A:21 Rear Electronic Module (REM), XC90 4/58C:12 Rear Electronic Module 3/74:3 Left-hand front door lock unit (REM) continues TP 39113202 V70/XC90 2008...
  • Page 191 Passenger compartment harness Front left door harness 16/1A:5 Integrated Audio Module 16/4:1 Left-hand front door speaker GR-R (IAM) 16/1B:1 Audio Module (AUM), V70 GR-R 54/14:1 Connector, V70 16/105B:9 Audio Module (AUD), XC90 16X/105B:9 Connector interface, original car, V70 16/1A:12 Integrated Audio Module...
  • Page 192 Connectors 54/11:7-12 - 54/12 V70 54/11 12-pin black Passenger compartment harness Front right door harness 4/56A:29 Central Electronic Module 10/16:12 Direction indicator, front right GN-W (CEM), XC90 door, XC90 4/58A:20 Rear Electronic Module (REM), XC90 54/43:4 Connector 3/75:3 Right-hand front door lock unit...
  • Page 193 22-pin black Passenger compartment harness Roof harness 11C/6:2 Fuses in the passenger com- 4/70:1 Upper Electronic Module (UEM) partment fuse box, V70 11C/12:2 Fuses in the passenger com- partment fuse box, XC90 11C/6:2 Fuses in the passenger com- 4/70:11 Upper Electronic Module (UEM)
  • Page 194 Ground connection, left- 53/503 Branching point hand side A-post 11C/7:2 Fuses in the passenger com- 4/33A:1 Sun Roof Module (SRM) partment fuse box, V70 11C/13:2 Fuses in the passenger com- partment fuse box, XC90 53/405 Branching point 53/583 Branching point...
  • Page 195 Rear Electronic Module 3/76:6 Lock unit, left rear door (REM) 4/58A:23 Rear Electronic Module 3/76:4 Lock unit, left rear door (REM) 53/500 Branching point 3/76:1 Lock unit, left rear door 3/85:2 Power window switch, left rear door TP 39113202 V70/XC90 2008...
  • Page 196 BL-GN (CEM) 4/56C:1 Central Electronic Module GR-W 10/1A:5 Lamp housing, front left (CEM) 4/56C:12 Central Electronic Module 6/38:2 Motor, left headlight adjustment GN-R GN-R (CEM) 4/56B:27 Central Electronic Module 10/1A:1 Lamp housing, front left (CEM) continues TP 39113202 V70/XC90 2008...
  • Page 197 Connectors 54/22:8-12 V70 - 54/22 XC90 54/22 12-pin black, V70 Engine compartment harness Harness, front left lamp housing 4/56B:31 Central Electronic Module 10/13:1 Direction indicator, front left (CEM) 53/301 Branching point 6/38:1 Motor, left headlight adjustment 10/1A:4 Lamp housing, front left...
  • Page 198 Direction indicator, front right (CEM) 53/303 Branching point 6/39:1 Motor, right headlight adjust- ment 10/2A:4 Lamp housing, front right 10/14:2 Direction indicator, front right 10/73:2 Side running light, front right 54/3.1:25 Connector GN-W 10/2A:7 Lamp housing, front right TP 39113202 V70/XC90 2008...
  • Page 199 Passenger compartment harness Front left seat harness 53/500 Branching point 9/12A:1 Seat Heating Module (SHM), left-hand 4/56A:19 Central Electronic Module 9/12A:4 Seat Heating Module (SHM), (CEM) left-hand 54/132:2 Connector GN-W 9/12A:2 Seat Heating Module (SHM), left-hand continues TP 39113202 V70/XC90 2008...
  • Page 200 4/52B:1 Power Seat Module (PSM), 53/437 Branching point, LHD VO-W 11C/1:2 Fuses in the passenger 4/52A:1 Power Seat Module (PSM), V70 BL-R compartment fuse box, V70 3/27:1 Switch unit, power passenger 11C/2:2 Fuses in the passenger seat, V70 RHD compartment fuse box, V70...
  • Page 201 Front right side airbag igniter System module (SRS) 4/9C:3/59 Supplemental Restraint BL-OR 8/52:2 Front right side airbag igniter System module (SRS) 16/60:5 Phone Module (PHM), V70 16/78:1 Cellular phone speaker, V70 GR-R 4/9C:1/57 Supplemental Restraint GN-W 7/93:E Occupant Weight Sensor...
  • Page 202 54/25:15-20 - 54/32 54/25 20-pin black Passenger compartment harness Front right seat harness 11C/1:2 Fuses in the passenger 4/52A:1 Power Seat Module (PSM), V70 BL-R compartment fuse box, V70 3/27:1 Switch unit, power passenger 11C/2:2 Fuses in the passenger seat, V70 LHD...
  • Page 203 6/33:2 Fuel pump (CEM) 6/33:E Fuel pump 31/48 Ground connection 53/579 Branching point 6/33 Fuel pump 4/56A:16 Central Electronic Module 4/83:2 Control module fuel pump (CEM) 6/33 Fuel pump 54/3.1:8 Connector 4/83:1 Control module fuel pump TP 39113202 V70/XC90 2008...
  • Page 204 Left-hand inflatable curtain tem module (SRS) igniter, third row of seats 54/40C 2-pin black Passenger compartment harness Cargo compartment harness 53/415 Branching point 11E/6:2 Main fuses at battery 53/403 Branching point 11E/7:2 Main fuses at battery TP 39113202 V70/XC90 2008...
  • Page 205 4/58D:28 Rear Electronic Module (REM) 53/524 Branching point 16/57:2 Speaker, left-hand D-post 53/655 Branching point, V70 53/523 Branching point GR-W 16/57:1 Speaker, left-hand D-post GR-W 53/654 Branching point, V70 54/21:7 Connector 4/58D:4 Rear Electronic Module (REM) TP 39113202 V70/XC90 2008...
  • Page 206 54/50 2-pin gray Cargo compartment harness Trunk lid/tailgate harness 53/601 Branching point 6/32:3 Rear window wiper motor, V70 7/137C:1 Glass breakage sensor, tail- gate, V70 9/2C:1 Heated rear window, V70 6/32:3 Rear window wiper motor,...
  • Page 207 Brake pressure sensor harness 4/16:21 Brake Control Module (BCM) BL-BN 7/139:1 Brake pressure sensor 1 4/16:23 Brake Control Module (BCM) OR-W 7/139:2 Brake pressure sensor 1 4/16:22 Brake Control Module (BCM) GR-OR 7/139:3 Brake pressure sensor 1 TP 39113202 V70/XC90 2008...
  • Page 208 Rear Electronic Module 4/82:1 Differential Electronic Module BL-R (REM) (DEM) 4/56D:32 Central Electronic Module 4/82:8 Differential Electronic Module (CEM) (DEM) 53/584 Branching point 54/3.1:11 Connector 31/46 Ground connection 4/82:2 Differential Electronic Module (DEM) 4/82:4 Differential Electronic Module (DEM) TP 39113202 V70/XC90 2008...
  • Page 209 Rear Electronic Module 8/89:1 Solenoid, fuel tank, Bi-Fuel, (REM) front left 54/54:7 Connector 8/90:1 Solenoid, fuel tank, Bi-Fuel, front right 53/604 Branching point 8/89:2 Solenoid, fuel tank, Bi-Fuel, front left 8/90:2 Solenoid, fuel tank, Bi-Fuel, front right TP 39113202 V70/XC90 2008...
  • Page 210 GN-GR left 4/84A:1 Suspension Module (SUM) 8/22:2 Shock absorber, Four-C, rear left 54/112 4-pin gray, XC90 Passenger compartment harness Infotainment harness 53/452 Branching point VO-W 30-feed 53/454 Branching point Extended D-feed 53/438 Branching point Ground connection TP 39113202 V70/XC90 2008...
  • Page 211 3/112A:13 Climate Control Module 7/41:3 Temperature sensor evaporator (CCM) 3/112A:7 Climate Control Module GN-W 53/460 Branching point (CCM) 6/96:2 Damper Motor Module (DMM), 54/25:4 Connector temperature, right-hand side, RHD MCC 53/438 Branching point 53/459 Branching point TP 39113202 V70/XC90 2008...
  • Page 212 RSE adapter harness RSE cabin harness 53/1405 Branching point 16/122:2 Rear Audio Separation module (RAS) 11M/2:2 Fuse in spare fuse holder, 53/1403 Branching point cargo compartment 11M/1:2 Fuse in spare fuse holder, 53/1404 Branching point cargo compartment TP 39113202 V70/XC90 2008...
  • Page 213 54/1402:14 Connector 54/277:4 Connector 54/1402:15 Connector 54/277:5 Connector 54/1402:16 Connector 54/277:6 Connector 54/1402:17 Connector 54/277:7 Connector 54/1402:18 Connector 54/277:8 Connector 54/1402:19 Connector 54/277:9 Connector 54/1402:20 Connector 54/277:10 Connector 54/1402:21 Connector 54/277:11 Connector 54/1402:22 Connector 54/277:12 Connector TP 39113202 V70/XC90 2008...
  • Page 214 54/1402:4 Connector 54/277:4 Connector 54/1402:5 Connector 54/277:5 Connector 54/1402:1 Connector 54/277:6 Connector 54/1402:11 Connector 54/277:7 Connector 54/1402:12 Connector 54/277:8 Connector 54/1402:13 Connector 54/277:9 Connector 54/1402:14 Connector 54/277:10 Connector 54/1402:15 Connector 54/277:11 Connector 54/1402:16 Connector 54/277:12 Connector TP 39113202 V70/XC90 2008...
  • Page 215 Screen, LH head restraint 54/139:8 Connector 16/81A:2 Screen, LH head restraint 54/139:9 Connector 16/81A:4 Screen, LH head restraint 54/139:10 Connector 16/81A:3 Screen, LH head restraint 54/139:11 Connector 16/81A:5 Screen, LH head restraint 54/139:12 Connector 16/81A:11 Screen, LH head restraint TP 39113202 V70/XC90 2008...
  • Page 216 Screen, RH head restraint 54/140:8 Connector 16/81B:2 Screen, RH head restraint 54/140:9 Connector 16/81B:4 Screen, RH head restraint 54/140:10 Connector 16/81B:3 Screen, RH head restraint 54/140:11 Connector 16/81B:5 Screen, RH head restraint 54/140:12 Connector 16/81B:11 Screen, RH head restraint TP 39113202 V70/XC90 2008...
  • Page 217 (PAM) 4/86B:8 Parking Assistance Module 54/1300:2 Connector (PAM) 4/86B:7 Parking Assistance Module 54/1300:3 Connector (PAM) 4/86B:6 Parking Assistance Module 54/1300:4 Connector (PAM) 4/86B:5 Parking Assistance Module 54/1300:5 Connector (PAM) 4/86B:1 Parking Assistance Module 54/1300:6 Connector (PAM) TP 39113202 V70/XC90 2008...
  • Page 218 16/109A:4 DVD player/control module 11C/8 Fuses in passenger compart- ment fuse box 16/109A:8 DVD player/control module 54/438 Connector 16/109A:7 DVD player/control module 4/56A:6 Central Electronic Module (CEM) 16/109A:6 DVD player/control module 4/56D:12 Central Electronic Module (CEM) TP 39113202 V70/XC90 2008...
  • Page 219 54/274:12 Connector 16/82E:5 DVD player/control module 54/274:11 Connector 16/82E:6 DVD player/control module 54/274:10 Connector 16/82E:8 DVD player/control module 54/274:9 Connector 16/82E:7 DVD player/control module 54/274:8 Connector 16/82E:10 DVD player/control module 54/274:7 Connector 16/82E:11 DVD player/control module TP 39113202 V70/XC90 2008...
  • Page 220 16/190E:23 DVD player/control module 54/140:7 Connector 16/190E:22 DVD player/control module 54/140:8 Connector 16/190E:19 DVD player/control module 54/140:9 Connector 16/190E:20 DVD player/control module 54/140:10 Connector 16/190E:18 DVD player/control module 54/140:11 Connector 16/190E:17 DVD player/control module 54/140:12 Connector TP 39113202 V70/XC90 2008...
  • Page 221: Branching Points

    8/19:1 8/28:1 GN-GR GN-GR 54/1B 8/18:1 53/309 P20589_53-304_V70 P20589_53-309 53/304 5-cyl. T. 53/309 6-cyl. GN-GR 8/125:1 GN-BN 7/82:1 GN-GR GN-BN GN-BN 8/126:1 54/1B 7/15:3 53/304 GN-GR GN-GR 8/19:1 8/3B:2 GN-GR GN-GR 54/1B 8/18:1 53/309 P20589_53-304_XC90 P20589_53-309_6CYL TP 39113202 V70/XC90 2008...
  • Page 222 5CYL T 20/47:1 20/52:1 53/319 BN-SB BN-SB A:61 7/8:1 5CYL W/O T GN-W GN-W 5CYL W/O T BN-SB 20/48:1 20/53:1 7/17:5 BN-SB 7/35:2 5CYL W/O T BN-SB BN-SB 7/81:2 GN-W GN-W 7/201:3 20/49:1 20/14:1 BI-FUEL P20589_53-319 P20485_53-328 TP 39113202 V70/XC90 2008...
  • Page 223 EXC 6 CYL VO-W 7/8:3 53/332 5CYL T VO-W VO-W 7/35:1 7/17:4 P20589_53-332 53/335 53/359 20/46:2 53/335 20/49:2 GN-GR GN-GR 8/120:3 8/113:1 GN-GR GN-GR 54/1B 6/143:1 4/46A:64 20/51:2 53/359 GN-GR GN-GR 8/64:2 4/109:6 20/52:2 P20589_53-335 P20485_53-359 TP 39113202 V70/XC90 2008...
  • Page 224 53/375 7/188:1 4/46A:72 53/394 GN-SB GN-SB 7/189:1 GN-SB P20485_53-375 P20589_53-394 53/376 53/395 8 CYL 4/46B:1 DIESEL/6 CYL 4/46B:4 4/46B:2 7/173:2 8 CYL 53/395 4/46B:3 7/172:2 4/46A:65 53/376 DIESEL/6 CYL 8 CYL 4/46B:6 4/46B:5 31/2 P20477_53-376 P20589_53-395 TP 39113202 V70/XC90 2008...
  • Page 225 3/157:1 4/9B:27/55 11B/1 11B/2 11B/17 11B/16 P20589_53-399 P20589_53-408 53/400 53/415 11C/6 11C/4 11C/2 11C/1 11C/3 XC90 MMM 5/1:4 16/108A:5 53/400 XC90 MMM 16/46A:4 16/65:7 11E/6 XC90 GPS 54/40C XC90 MMM 16/139A:5 16/46A:5 53/415 31/83 P20477_53-400 P20477_53-415 TP 39113202 V70/XC90 2008...
  • Page 226 53/436 C:21 D:36 High High D:32 D:35 P20589_53-430 P20589_53-436 53/431 53/437 4/56 VO-W 54/24 VO-W 54/25 VO-W VO-W 4/56A:10 3/112A:1 53/437 VO-W 5/1:3 HS CAN D:46 53/431 C:22 VO-W 54/132 D:47 USA/CDN VO-W 54/25 P20589_53-431 P20477_53-437 TP 39113202 V70/XC90 2008...
  • Page 227 7/159:1 6/103:1 31/84 P20477_53-448 P20477_53-458 53/449 53/459 53/459 6/95:3 6/48:3 6/69:3 OR-W OR-SB 6/96:3 8/66:2 4/9A:22/22 53/449 6/102:3 54/132 6/103:3 7/159:3 P20589_53-449 P20477_53-459 53/450 53/460 6/96:2 54/132 6/102:2 8/66:1 4/9A:21/21 53/460 53/450 6/48:2 7/159:2 P20589_53-450 P20589_53-460 TP 39113202 V70/XC90 2008...
  • Page 228 4/70:22 53/509 31/46 P20589_53-500 P20477_53-509 53/501 53/514 6/35:2 54/11 54/25 53/514 3/126B:5 54/10 54/21 53/501 6/62:6 31/67 P20589_53-501 P20589_53-514 53/503 53/515 XC90 7/158:5 54/16 6/63:6 53/503 53/515 7/122:5 54/11 54/13 3/127B:5 4/70:20 4/33A:5 31/98 P20589_53-503 P20589_53-515 TP 39113202 V70/XC90 2008...
  • Page 229 54/107 7/89:3 V70 W/O AMP 54/20 16/1B:8 4/84A:13 54/3.1 53/524 53/569 54/43 P20589_53-524 P20477_53-569 53/525 53/570 V70 W/O AMP GR-W 16/1B:11 7/89:2 V70 AMP GR-W GR-W 54/14 54/21 4/84A:19 54/3.1 53/525 53/570 GR-W 54/43 P20589_53-525 P20477_53-570 TP 39113202 V70/XC90 2008...
  • Page 230 4/58F:5 2WD HCM FOUR-C 54/3.1 53/568 10/3:2 4/56D:47 54/74 3/78:6 10/173:4 HCM AWD/FOUR-C HCM W/O FOUR-C P20477_53-585 P20477_53-606 53/601 53/652 53/601 54/50 10/18A:6 53/652 XC90 GR-W GR-W 10/18B:4 54/43 16/58:1 6/76A:2 GR-W 16/79:11 31/72 P20589_53-601 P20477_53-652 TP 39113202 V70/XC90 2008...
  • Page 231 53/735 16/79:8 Y-SB 4/58E:H P20477_53-655 P20477_53-735 53/663 53/736 4/58 53/736 16/46A:1 16/15:2 4/58B:8 16/46A:2 16/45D:1 C:14 D:30 53/663 D:21 P20589_53-663 P20477_53-736 53/664 53/737 4/58 53/737 16/15:1 16/46A:4 16/45D:5 16/46A:5 C:13 D:19 53/664 D:20 31/120 P20589_53-664 P20477_53-737 TP 39113202 V70/XC90 2008...
  • Page 232 16/122:9 10/18A:4 53/1400 53/1405 54/137A 54/1401 10X/18A 16X/2A 53-1400_V70_93 53-1405_93 53/1401 53/3006 20/5:4 20/7:4 16/122:9 20/6:4 20/8:4 53/3006 53/1401 54/1401 16/82A:8 31/89 53-X7E_93 P20477_53-3006 53/1402 53/3009 16/122:1 53/3009 53/1402 54/1401 6/25:1 17/17 16/82A:4 6/26A:1 53-1402 P20477_53-3009 TP 39113202 V70/XC90 2008...
  • Page 233: Cable Harness Routine In Vehicle Engine Harness Gasoline

    Cable harness routine in vehicle Engine harness Gasoline 53/332 53/314 53/315 54/1B 53/326 53/328 53/332 XC90 53/319 53/304 53/376 53/309 53/375 Turbo, 5 cyl w/o Turbo 5 cyl 53/375 53/376 Turbo, 5 cyl w/o Turbo 53/360 54/7 Bi-Fuel 54/53 Turbo TP 39113202 V70/XC90 2008...
  • Page 234: Engine Harness Gasoline 6-Cyl

    Cable harness routine in vehicle Engine harness Gasoline 6-cyl 53/328 53/3006 53/360 53/3003 54/1B 53/315 53/309 53/462 53/304 53/3009 53/3002 53/332 TP 39113202 V70/XC90 2008...
  • Page 235: Engine Harness Diesel

    Cable harness routine in vehicle Engine harness Diesel 53/335 54/1B 54/100 54/1C TP 39113202 V70/XC90 2008...
  • Page 236: Engine Compartment Harness Lhd, V70

    Cable harness routine in vehicle Engine compartment harness LHD, V70 53/303 53/302 53/355 53/324 53/354 53/398 54/23 54/3.1 54/7 Bi-Fuel 53/305 54/1B 53/394 54/3.2 54/57.1 53/329 53/384 53/397 53/395 53/301 53/352 54/4 53/331 54/9 54/22 54/1C 54/8 53/353 TP 39113202 V70/XC90 2008...
  • Page 237: Engine Compartment Harness Rhd, V70

    Cable harness routine in vehicle Engine compartment harness RHD, V70 54/3.1 53/303 53/302 53/355 53/324 53/354 53/398 54/55 54/23 54/7 54/56 Bi-Fuel 53/394 54/57.1 53/329 53/384 53/397 53/301 53/331 53/395 53/353 53/352 54/4 54/22 54/9 54/8 54/1C TP 39113202 V70/XC90 2008...
  • Page 238: Engine Compartment Harness Lhd, Xc90

    Cable harness routine in vehicle Engine compartment harness LHD, XC90 53/324 53/303 53/398 53/302 54/1B 54/23 53/394 54/3.1 54/57.1 54/3.2 54/122 53/329 53/396 53/384 54/8 53/397 53/331 54/1C 53/352 54/113 54/22 54/9 53/395 53/301 53/353 TP 39113202 V70/XC90 2008...
  • Page 239: Engine Compartment Harness Rhd, Xc90

    Cable harness routine in vehicle Engine compartment harness RHD, XC90 54/3.1 53/324 53/303 53/398 53/302 54/55 54/56 54/23 54/1B 53/394 53/329 54/57.1 53/331 53/384 54/8 54/122 53/397 54/1C 54/113 53/395 54/22 53/352 53/353 54/9 53/301 TP 39113202 V70/XC90 2008...
  • Page 240: Passenger Compartment Harness Lhd, V70

    Cable harness routine in vehicle Passenger compartment harness LHD, V70 54/39 54/43 54/21 54/40C 54/34 54/40D 54/36 53/443 54/107 53/525, 53/433, 53/434 53/526 53/406 54/32 53/567, 53/568 54/74 53/501 54/25 54/134.2 54/14 54/11 54/20 54/132 53/425 53/448 54/13 54/12 53/449, 53/450...
  • Page 241: Passenger Compartment Harness Rhd, V70

    Cable harness routine in vehicle Passenger compartment harness RHD, V70 54/39 54/43 54/40C 54/21 53/415 54/40D 53/403 54/36 53/425 54/107 54/11 53/501 53/437 54/32 54/74 54/132 53/567, 53/568 53/408 54/25 54/134.2 54/14 54/3.1 54/20 53/448 53/449, 53/450 53/525, 53/526 54/13...
  • Page 242: Passenger Compartment Harness Lhd, Xc90

    54/117 53/501 54/34 54/40D 54/134 53/500 54/12 53/434, 54/1401 53/433 54/11 54/132 54/139 54/13 53/408 54/24 53/448 54/74 53/438 54/32 53/454 53/405 53/443 54/10 53/400 54/20 53/437 53/425 53/415 54/3.1 53/403 53/584, 53/585 54/3.2 53/523, 53/524 TP 39113202 V70/XC90 2008...
  • Page 243: Passenger Compartment Harness Rhd, Xc90

    54/66.2 53/438 54/32 53/501 54/140 54/117 54/74 54/11 53/415 54/1401 54/134 53/425 53/403 53/437 54/139 54/132 54/24 54/3.1 54/13 53/433, 53/434 54/12 54/112 54/10 53/443 53/500 54/20 53/405 53/408 53/400 53/523, 53/524 53/525, 53/526 53/584, 53/585 TP 39113202 V70/XC90 2008...
  • Page 244: Cargo Compartment Harness V70

    Cable harness routine in vehicle Cargo compartment harness V70 53/604 53/654, 53/655 53/605 53/652, 53/653 54/40D 54/40C 54/54 54/50 54/106 54/35 53/579 54/43 54/36 53/602 53/601 TP 39113202 V70/XC90 2008...
  • Page 245: Cargo Compartment Harness Xc90

    Cable harness routine in vehicle Cargo compartment harness XC90 54/98 53/601 53/604 53/602 54/40D 54/66.1 54/40C 54/43B 54/66.2 54/43 53/579 54/35 54/50 54/36 54/40B TP 39113202 V70/XC90 2008...
  • Page 246: Roof Harness & Inflatable Curtain Harness V70

    Cable harness routine in vehicle Roof harness & Inflatable curtain harness V70 53/505 53/503 53/583 54/45 54/16 53/505 54/44 54/13 Tailgate harness V70 54/50 TP 39113202 V70/XC90 2008...
  • Page 247: Roof Harness Xc90

    Cable harness routine in vehicle Roof harness XC90 54/16 53/576 53/575 53/577 53/508 53/509 53/503 53/583 53/505 54/13 Tailgate harness XC90 53/606 54/50 TP 39113202 V70/XC90 2008...
  • Page 248: Door Harness V70

    Cable harness routine in vehicle Door harness V70 53/514 54/20 54/10 53/515 54/21 54/11 TP 39113202 V70/XC90 2008...
  • Page 249: Door Harness Xc90

    Cable harness routine in vehicle Door harness XC90 53/514 53/515 54/10 54/11 54/21 54/20 TP 39113202 V70/XC90 2008...
  • Page 250: Bi-Fuel Harnesses V70

    Cable harness routine in vehicle Bi-Fuel harnesses V70 54/54 54/106 TP 39113202 V70/XC90 2008...
  • Page 251: Rear Seat Entertainment V70

    Cable harness routine in vehicle Rear seat entertainment V70 16/2B 16/2A 16X/2A 16X/2B 53/1400 54/274 54/275 53/1403 16/122 54/1401 54/1402 16/123 53/1404 54/137A 16/82E 16/82D 16/82A 9X/25 9/25 11E/2 53/1405 10/18 10X/18 TP 39113202 V70/XC90 2008...
  • Page 252: Component Illustrations

    FST3 FST3 FMA3 FMA2 FST2 FMA3 FMA2 FST2 FMA1 FST1 FMA1 FST1 2/32 2/91 P20485_2-32 P20485_2-91 2/35 Relay, starter motor 2/138 Deadlock relay, left rear door, V70 FST3 FMA3 FMA2 FST2 FMA1 FST1 2/35 P20485_2-35 P204_2-138_V70 TP 39113202 V70/XC90 2008...
  • Page 253 2/138 XC90 - 3/1 V70 2/138 Deadlock relay, left rear door, XC90 2/192 Relay, electric engine heater V70 P204_2-138_XC90 P204_2-192 _V70 2/139 Deadlock relay, right rear door V70 2/192 Relay, electric engine heater XC90 P204_2-139_V70 P204_2-192 _XC90 2/139 Deadlock relay, right rear door XC90...
  • Page 254 Component illustrations 3/1 XC90 - 3/25 V70 Switch, heated rear window/exterior rearview mirrors XC90 Ignition switch XC90 P204_3-1_XC90 P204_3-8 _XC90 Steering Wheel Switch Left (SWSL) Brake light contact V70 P204_3-4_V70 P204_3-9_V70 Steering Wheel Switch Left (SWSL) XC90 Brake light contact XC90...
  • Page 255 Component illustrations 3/25 XC90 - 3/60 V70 3/25 Power sunroof switch XC90 3/47 Parking brake contact V70 P204_3-25_XC90 P204_3-47_V70 3/26 Switch unit, power driver’s seat 3/47 Parking brake contact XC90 3/47 P204_3-26 P204_3-47_XC90 3/27 Switch unit, power passenger seat 3/59...
  • Page 256 MENU PQRS WXYZ REAR REAR P204_3-60_XC90 P204_3-73_XC90 3/62 Hood alarm contact V70 3/74 Lock unit, left front door, V70 P204_3-62_V70 P204_3-74_V70 3/62 Hood alarm contact XC90 3/74 Lock unit, left front door, XC90 P204_3-62_XC90 P204_3-74_XC90 3/71 Gear selector contacts AW51...
  • Page 257 Component illustrations 3/76 V70 - 3/82 XC90 3/76 Lock unit, left rear door V70 3/78 Lock unit, tailgate XC90 P204_3-76_V70 P204_3-78_XC90 3/76 Lock unit, left rear door, XC90 3/80 Switch, central locking, left V70 P204_3-76_XC90 P204_3-80_V70 3/77 Lock unit, right rear door, V70...
  • Page 258 3/92 Switch, right heated seat XC90 P204_3-86_V70 P204_3-92_XC90 3/86 Power window switch, right rear door XC90 3/93 Belt buckle contact, left seat V70 P204_3-86_XC90 P204_3-93_V70 3/91 Switch, left heated seat V70 3/93 Belt buckle contact, left seat XC90 P204_3-91_V70 P204_3-93_XC90...
  • Page 259 Component illustrations 3/94 V70 - 3/117 XC90 3/94 Belt buckle contact, right seat V70 3/111 Light Switch Module (LSM), XC90 P204_3-94_V70 P204_3-111_XC90 3/94 Belt buckle contact, right seat XC90 3/112 Climate Control Module (CCM) V70 P204_3-94_XC90 P204_3-112_V70 3/95 Spin control switch V70...
  • Page 260 3/155 Program selector, automatic trans- (PDM)/(DDM), XC90 mission XC90 AM FM MY KEY POWER SOUND ENTER EXIT MENU PQRS WXYZ P204_3-127_XC90 P204_3-155_XC90 3/131 Steering Wheel Switch Right (SWSR) 3/156 Gear Selector Module (GSM) V70 P204_3-131_V70 P204_3-156_V70 TP 39113202 V70/XC90 2008...
  • Page 261 Component illustrations 3/156 XC90 - 3/225 3/156 Gear Selector Module (GSM) XC90 3/173 Switch, tailgate private lock V70 AM FM MY KEY POWER SOUND ENTER EXIT MENU PQRS WXYZ P204_3-156_XC90 P204_3-173_V70 3/157 Switch, passenger side airbag V70 3/173 Switch, tailgate private lock XC90...
  • Page 262 P204_4-7_XC90 Supplemental Restraint System mod- ule (SRS) 3/255 Position sensor, driver’s seat P204_3-255 P204_4-9 3/256 Position sensor, passenger seat 4/16 Brake Control Module (BCM) V70 P204_3-256 P204_4-16_V70 3/267 Switch unit, telematics 4/16 Brake Control Module (BCM) XC90 3-267 P204_4-16_XC90 Combustion Preheater Module (CPM)
  • Page 263 P204_4-28_V70 4_46_6CYL 4/31 Fan control module 4/46 Engine Control Module (ECM) 8-cyl. P204_4-31 P20485_4-46 4/33 Sun Roof Module (SRM) V70 4/46 Engine Control Module (ECM) Diesel P204_4-33_V70 4-46_I5D_88 4/33 Sun Roof Module (SRM) XC90 4/50 Electronic Throttle Module (ETM) P204_4-33_XC90...
  • Page 264 Component illustrations 4/56 - 4/78 V70 4/56 Central Electronic Module (CEM) 4/70 Upper Electronic Module (UEM) V70 P204_4-56 P204_4-70_V70 4/58 Rear Electronic Module (REM), V70 4/70 Upper Electronic Module (UEM) XC90 P204_4-58_V70 P204_4-70_XC90 4/58 Rear Electronic Module (REM), XC90 4/71...
  • Page 265 4/78 XC90 - 4/106 4/78 Accessory Electronic Module (AEM) XC90 4/84 Suspension Module (SUM) P204_4-78_XC90 P204_4-84_V70 4/82 Differential Electronic Module (DEM) 4/86 Parking Assistance Module (PAM) V70 P204_4-82_V70 P204_4-86_V70 4/82 Differential Electronic Module (DEM) 4/86 Parking Assistance Module (PAM) XC90 XC90 P204_4-82_XC90 P204_4-86_XC90...
  • Page 266 P204_4-107 P204_4-120 4/109 Glow plug control module 4/124 Accessory USB unit (AUU) 4-124 4-109_88 4/110 Trailer module V70 Driver Information Module (DIM) V70 P204_4-110_V70 P204_5-1_V70 4/110 Trailer module XC90 Driver Information Module (DIM) XC90 P204_4-110_XC90 P204_5-1_XC90 4/118 Headlight Control Module (HCM...
  • Page 267 P204_6-17 6/18 Motor driver’s seat, up/down rear edge Left-hand headlight wiper motor P204_6-4_V70 P204_6-18 6/15 Sunroof motor V70 6/19 Motor driver’s seat, fore/aft P204_6-15_V70 P204_6-19 6/15 Sunroof motor XC90 6/20 Motor passenger seat, fore/aft P204_6-15_XC90 P204_6-20 TP 39113202 V70/XC90 2008...
  • Page 268 Component illustrations 6/25 V70 - 6/33 XC90 6/25 Starter motor V70 6/29 Motor, electric cooling fan P204_6-25_V70 P204_6-29_XC90 6/25 Starter motor XC90 6/32 Rear window wiper motor V70 P204_6-25_XC90 P204_6-32_V70 6/26 Alternator Control Module (ACM) V70 6/32 Rear window wiper motor XC90...
  • Page 269 6/35 Fuel pump, auxiliary heater XC90 P204_6-35_XC90 P204_6-44_V70 6/48 Damper Motor Module (DMM), recirculation 6/37 Lock motor, fuel filler flap V70 P204_6-37_V70 P204_6-48 6/37 Lock motor, fuel filler flap XC90 6/58 Front left power window motor, V70 P204_6-37_XC90 P204_6-58_V70...
  • Page 270 Component illustrations 6/60 V70 - 6/67 V70 6/63 Right power exterior rearview mirror, XC90 6/60 Front right power window motor, V70 P204_6-60_V70 6/60 Front right power window motor, XC90 6/64 Motor passenger seat, backrest angle P204_6-60_XC90 P204_6-64 6/62 Left power exterior rearview mirror,...
  • Page 271 Pump, fuel leakage control, XC90 6/76 Climate control system, rear P204_6-67_XC90 P204_6-76 6/69 Damper Motor Module (DMM), ventila- tion/floor/defroster 6/92 Rear left power window motor, V70 P204_6-92_V70 P204_6-69 6/71 Valve, speed-dependent power steer- 6/92 Rear left power window motor, XC90 6-71 P204_6-92_XC90...
  • Page 272 6/102 Damper Motor Module (DMM), defroster 6/113 Coolant pump, 8-Cyl. P20485_6-113 P204_6-102 6/103 Damper Motor Module (DMM), floor/ventilation 6/114 Vacuum pump P204_6-114 P204_6-103 6/104 High pressure headlight washer V70 6/118 Regulator motor, swirl throttle P204_6-104_V70 P205_6-118 TP 39113202 V70/XC90 2008...
  • Page 273 6_139 6/140 Lower actuating motor, intake mani- fold 6/120 Throttle body motor, 8-Cyl. P20485_6-120 6_140 6/120 Throttle body motor Diesel 6/143 Regulator motor, Turbo P205_6-143 6-120_I5D_88 6/127 Washer motor V70 Brake fluid level sensor P204_6-127_V70 P204_7-4 TP 39113202 V70/XC90 2008...
  • Page 274 Component illustrations 7/5 V70 - 7/11 XC90 Pressure sensor, climate control sys- tem XC90 Washer fluid level sensor V70 P204_7-5_V70 P204_7-8_XC90 Pressure sensor, climate control sys- tem, 8-Cyl. Washer fluid level sensor XC90 P204_7-5_XC90 P20485_7-8 Oil pressure monitor V70 7/10...
  • Page 275 5 3 1 P204_7-15 P204_7-16_XC90 7/15 Front heated oxygen sensor, bank 2, 6-cyl. 7/16 Coolant temperature sensor, 8-Cyl. 7_15_6CYL P20485_7-16 7/15 Front heated oxygen sensor, bank 2, 8-cyl. 7/17 Mass air flow sensor (MAF) V70 P20485_7-15 P204_7-17_V70 TP 39113202 V70/XC90 2008...
  • Page 276 P204_7-25_V70 P20485_7-17 7/23 Rear knock sensor 7/25 Impulse sensor, 6-cyl. 7/23 P276_7-23 7_25_6CYL 7/23 Rear knock sensor, 8-Cyl. 7/25 Impulse sensor, 8-Cyl. P20485_7-25 P204_7-23 7/24 Front knock sensor 7/31 Sensor ABS, front left 7/24 P276_7-24 P276_7-31 TP 39113202 V70/XC90 2008...
  • Page 277 P204_7-35 P204_7-57 7/41 Temperature sensor evaporator 7/61 Input speed sensor AW51 7/61 P204_7-61_AW 51 P204_7-41 7/51 Accelerator pedal sensor V70 7/61 Input speed sensor TF-80SC P204_7-51_V70 P20485_7-61 7/51 Accelerator pedal sensor XC90 7/62 Output speed sensor AW51 7/62 AM FM...
  • Page 278 Intake manifold pressure sensor, 5- Cyl. 7/62 Output speed sensor TF-80SC P204_7-81_V70 P20485_7-62 7/81 Intake manifold pressure sensor, 6- Cyl. 7/73 Coolant level sensor V70 P204_7-73_V70 7_81_6CYL 7/81 Intake manifold pressure sensor, 8- Cyl. 7/73 Coolant level sensor XC90 P204_7-73_XC90 P20485_7-81...
  • Page 279 Acceleration sensor, Four-C, front left 7/93 Occupant Weight Sensor (OWS) P204_7-87 P204_7-93 7/88 Acceleration sensor, Four-C, front right 7/100 Inclination Sensor Module (ISM) V70 P204_7-88 P204_7-100_V70 7/89 Acceleration sensor, Four-C, rear left 7/100 Inclination Sensor Module (ISM) XC90 P204_7-89 P204_7-100_XC90 7/103 Front heated oxygen sensor, bank 1, 6-Cyl.
  • Page 280 Component illustrations 7/103 8-Cyl. - 7/110 7/103 Rear heated oxygen sensor, bank 2, 8- Cyl. 7/108 Side impact sensor, rear left V70 P204_7-108_V70 P20485_7-103 7/104 Rear heated oxygen sensor, bank 1, 6- Cyl. 7/108 Side impact sensor, rear left XC90...
  • Page 281 7/111 Right-hand seat temperature sensor 7/111 P204_7-111 P204_7-118 7/119 Acceleration sensor, shock absorber, Four-C, front right 7/115 Side impact sensor, front left V70 P204_7-115_V70 P204_7-119 7/120 Rear left angle sensor, Four-C/Bi- Xenon V70 7/115 Side impact sensor, front left XC90...
  • Page 282 7/129 Brake pressure sensor 2 V70 P204_7-122_XC90 P204_7-129_V70 7/123 Clutch pedal sensor V70 7/129 Brake pressure sensor 2 XC90 P204_7-123_V70 P204_7-129_XC90 7/123 Clutch pedal sensor XC90 7/130 Fuel level sensor, ejector side V70 AM FM MY KEY POWER SOUND ENTER EXIT MENU...
  • Page 283 7/139 Brake pressure sensor 1 XC90 RR/O RR/I LR/I LR/O 7-131_7-134 P204_7-139_XC90 7/135 Glass breakage sensor, left-hand 7/143 Fuel level sensor, pump side V70 7/135 P204_7-135_V70 P204_7-143_V70 7/136 Glass breakage sensor, right-hand 7/143 Sensor fuel level, pump side XC90 7/136 P204_7-136_V70...
  • Page 284 7/156 Pressure and temperature sensor fuel P204_7-156 P204_7-165 7/158 Mass Movement Sensor (MMS), rear 7/166 Oil level sensor, Diesel P204_7-158_XC90 P204_7-166_I5D 7/172 Position sensor camshaft, intake side 5-Cyl. 7/159 Air Quality Sensor (AQS) P204_7-159 7-172 TP 39113202 V70/XC90 2008...
  • Page 285 Diesel seat belt reminder 7/175 7-173_Diesel P204_7-175_XC90 7/173 Position sensor camshaft, outlet side 5-Cyl. 7/178 Front impact sensor, right P204_7-178 7-173 7/173 Position sensor camshaft, outlet side 6-Cyl. 7/179 Front impact sensor, left 7-173_6CYL P204_7-179 TP 39113202 V70/XC90 2008...
  • Page 286 7/190 Temperature sensor, catalytic con- Electromagnetic clutch, climate con- verter trol system XC90 7-190_89 P204_8-3_XC90 Electromagnetic clutch, climate con- trol system, 8-Cyl. 7/191 Temperature sensor, particle filter 7-191_89 P20485_8-3 7/201 Pressure and temperature sensor, 8/6-10 Injectors, Diesel P204_7-201 P204_8-6-10_DIESEL TP 39113202 V70/XC90 2008...
  • Page 287 EVAP valve XC90 8/20 Shock absorber, Four-C, front left P204_8-18_XC90 P204_8-20 8/18 EVAP valve, 8-Cyl. 8/21 Shock absorber, Four-C, front right P204_8-21 P20485_8-18 8/19 Solenoid, variable valve timing, intake 8/22 Shock absorber, Four-C, rear left P204_8-19_V70 P204_8-22 TP 39113202 V70/XC90 2008...
  • Page 288 Igniter passenger side airbag stage 2, XC90 8/28 Turbocharger control valve XC90 P204_8-28_XC90 P204_8-31-32_XC90 8/30 Airbag igniter, driver’s side 8/33 Front left belt tensioner igniter V70 P204_8-33_V70 P204_8-30 8/31 Igniter, passenger side airbag V70 8/33 Front left belt tensioner igniter XC90 P204_8-31-32_V70 P204_8-33_XC90...
  • Page 289 Component illustrations 8/34 V70 - 8/40 AW51 8/34 Front right belt tensioner igniter V70 8/38 Shift solenoid 1 AW51 P204_8-34_V70 P204_8-38-41_AW51 8/34 Front right seat belt tensioner igniter XC90 8/38 Shift solenoid 1 TF-80SC P204_8-34_XC90 P20485_8-38 8/36 Solenoid shift lock...
  • Page 290 8/40 Lock-up solenoid TF-80SC 8/51 Front left side airbag igniter XC90 P204_8-51_XC90 P20485_8-40 8/41 Pressure solenoid AW51 8/52 Front right side airbag igniter V70 P204_8-38-41_AW51 P204_8-52_V70 8/46 Activation unit DSTC V70 8/52 Front right side airbag igniter XC90 8/46 P204_8-46_V70...
  • Page 291 Component illustrations 8/61 - 8/71 AW51 8/61 Igniter, airbag stage 2, driver’s side 8/66 Left inflatable curtain igniter, V70 P204_8-66_V70 P204_8-61 8/62 Belt tensioner igniter, center rear seat 8/66 Left inflatable curtain igniter, XC90 P204_8-62_V70 P204_8-66_XC90 8/62 Belt tensioner igniter, center rear...
  • Page 292 8/84 Switch, vacuum pump P204_8-71-74 P204_8-84 8/85 Thermostatic switch and fuel filter heating V70 8/74 Shift solenoid 5 AW51 P204_8-71-74 P204_8-85_V70 8/85 Thermostatic switch and fuel filter heating XC90 8/75 Valve, fuel cut-off DFCO P204_8-75_V70 P204_8-85_XC90 TP 39113202 V70/XC90 2008...
  • Page 293 Fuel pressure control valve, Diesel P205_8-98_I5D P204_8-90_V70 8/94 Left belt tensioner igniter, third row of seats 8/99 Igniter, steering column P204_8-94_XC90 P204_8-99_XC90 8/95 Right belt tensioner igniter, third row of seats 8/107 Valve, variable intake, 8-Cyl. P204_8-95_XC90 P20485_8-107 TP 39113202 V70/XC90 2008...
  • Page 294 1, 8-cyl. 8/125 Solenoid front cam profile P20485_8-117 8_125 8/118 Solenoid, variable valve timing, exhaust, bank 1, 8-Cyl. 8/126 Solenoid rear cam profile P20485_8-118 8_126 8/120 EGR valve 8/134 Solenoid, reverse interlock, manual 8-120_88 P204_8-134 TP 39113202 V70/XC90 2008...
  • Page 295 Component illustrations 8/142 TF-80SC - 9/12 8/142 Linear pressure solenoid SLB1 TF- 80SC Outlet 12V front V70 P204_9-1_V70 8-142_AWD_88 8/143 Linear pressure solenoid SLC1 TF- 80SC Outlet 12V front XC90 AM FM MY KEY POWER SOUND ENTER EXIT MENU PQRS...
  • Page 296 Component illustrations 9/13 - 9/32 9/13 Seat Heating Module (SHM), right- hand 9/25 Outlet 12V rear V70 P204_9-25_V70 P204_9-13 9/16 Left-hand backrest heating element 9/25 Outlet 12V rear XC90 9/16 P204_9-16 P204_9-25_XC90 9/17 Right-hand backrest heating element 9/30 Auxiliary heater V70...
  • Page 297 P204_10-2_XC90 9/34 Right heated exterior rearview mirror 10/3 License plate lighting V70 9/34 P204_9-34 P204_10-3_V70 10/1 Left front lamp housing, V70 10/3 License plate lighting XC90 P204_10-1_V70 P204_10-3_XC90 10/1 Left front lamp housing, XC90 10/5 Fog light, front left V70...
  • Page 298 10/12 Running/parking light, front right XC90 10/6 Fog light, front right V70 P204_10-6_V70 P204_10-12_XC90 10/6 Fog light, front right XC90 10/13 Direction indicator, front left V70 P204_10-6_XC90 P204_10-13_V70 10/11 Running/parking light, front left V70 10/13 Direction indicator, front left XC90 P204_10-13_XC90 P204_10-11_V70...
  • Page 299 10-15 P204_10-18_XC90 10/16 Direction indicator, right door mirror 10/19 Auxiliary brake light V70 10-16 P204_10-19_V70 10/17 Lamp housing, rear right V70 10/19 Auxiliary brake light XC90 P204_10-17_V70 P204_10-19_XC90 10/17 Lamp housing, rear right XC90 10/25 Ceiling light, cargo compartment P204_10-17_XC90...
  • Page 300 MY KEY SOUND ENTER EXIT MENU P204_10-29_XC90 P204_10-45_V70 10/43 Right brake light V70 10/46 Fog light, right rear V70 P204_10-43_V70 P204_10-46_V70 10/43 Right brake light XC90 10/46 Fog light, rear right XC90 P204_10-43_XC90 P204_10-46_XC90 10/44 Tail light 1, right, V70...
  • Page 301 P204_10-48_V70 P204_10-51_XC90 10/48 Right reversing light XC90 10/52 Tail light 2, left P204_10-48_XC90 P204_10-52_V70 10/50 Left brake light V70 10/53 Fog light, rear left V70 P204_10-50_V70 P204_10-53_V70 10/50 Left brake light XC90 10/53 Fog light, left rear XC90 P204_10-50_XC90 P204_10-53_XC90...
  • Page 302 Component illustrations 10/54 XC90 - 10/68 V70 10/54 Direction indicator, rear left, XC90 10/65 Auxiliary light, front right V70 P204_10-54_XC90 P204_10-65_V70 10/55 Left reversing light V70 10/65 Auxiliary light, front right XC90 P204_10-55_V70 P204_10-65_XC90 10/55 Left reversing light XC90 10/66 Right low beam V70...
  • Page 303 Component illustrations 10/68 XC90 - 10/114 V70 10/68 Left high beam XC90 10/71 Side running light, front left V70 P204_10-68_XC90 P204_10-71-V70 10/69 Auxiliary light, front left V70 10/71 Side running light, front XC90 P204_10-69_V70 P204_10-71_XC90 10/69 Auxiliary light, front left XC90...
  • Page 304 Component illustrations 10/114 XC90 -10/150 V70 10/114 Vanity mirror lighting, left XC90 10/126 Courtesy lighting, front right V70 P204_10-114_XC90 P204_10-126_V70 10/115 Vanity mirror lighting, right V70 10/126 Courtesy lighting, front right XC90 P204_10-115_V70 P204_10-126_XC90 10/115 Vanity mirror lighting, right XC90...
  • Page 305 XC90 10/173 Cargo compartment lighting, tailgate 25 32 13 17 P204_10-173_XC90 P204_11C_XC90 10/218 Indicator light, remote start 11E/no. Main fuses at the battery V70 11E/7 11E/1 P204_10-218_V70 P204_11E_V70 11A/no. Main fuses in engine compartment fuse box 11E/no. Main fuses at the battery XC90...
  • Page 306 Component illustrations 11L/no V70 - 16/3 XC90 11L/no. Fuse in fuse holder cargo compart- ment V70 16/1 Audio Module (AUM) V70 P204_16-1_V70 P20485_11L_V70 11L/no. Fuse in fuse holder cargo compart- ment V90 16/1 Integrated Audio Module (IAM) XC90 P204_16-1_XC90 P20485_11L_XC90 11M/no.
  • Page 307 Component illustrations 16/4 V70 - 16/5 16/4 Speaker, front left door V70 16/6 Speaker, left rear door XC90 P204_16-4_V70 P204_16-6_XC90 16/4 Speaker, front left door XC90 16/10 Horn 1, V70 P204_16-4_XC90 P204_16-10_V70 16/5 Speaker, right rear door V70 16/10 Horn 1, XC90...
  • Page 308 Component illustrations 16/16 V70 - 16/46 V70 16/16 LH window antenna amplifier 1, V70 16/35 Siren (SCM) XC90 P204_16-16_V70 P204_16-35_XC90 16/16 LH window antenna amplifier 1, XC90 16/36 TV receiver P204_16-16_XC90 P204_16-36_V70 16/26 Speaker, dashboard middle V70 16/45 Road Traffic Information module (RTI)
  • Page 309 16/46 XC90 - 16/56 XC90 16/46 Multimedia display XC90 16/54 Window antenna, rear right XC90 P204_16-46_XC90 16-54_XC90 16/47 GPS antenna, RTI 16/55 Treble speaker, left front door V70 P204_16-47_V70 P204_16-55_V70 16/50 Window antenna, rear left V70 16/55 Treble speaker, left front door, XC90 16/50...
  • Page 310 P204_16-57_XC90 P204_16-62_V70 16/58 Speaker, right D-post V70 16/62 Handset, cellular phone XC90 P204_16-58_V70 P204_16-62_XC90 16/58 Speaker, right D-post XC90 16/63 GPS antenna, cellular phone V70 P204_16-58_XC90 P204_16-63_V70 16/60 Phone Module (PHM), V70 16/63 GPS antenna, cellular phone XC90 P204_16-60_V70 P204_16-63_XC90...
  • Page 311 16/64 V70 - 16/74 16/64 Cellular phone antenna V70 16/68 Antenna, bumper P204_16-64_V70 P204_16-68_V70 16/64 Cellular phone antenna XC90 16/71 RH window antenna amplifier 1, V70 P204_16-64_XC90 P204_16-71_V70 16/65 Antenna ring/ignition switch lighting, 16/71 Window antenna amplifier 1, right XC90...
  • Page 312 Component illustrations 16/77 V70 - 16/93 V70 16/77 Microphone, cellular phone V70 16/81A Screen, LH head restraint P204_16-77_V70 16-81A 16/77 Microphone, cellular phone XC90 16/81B Screen, RH head restraint P204_16-77_XC90 16-81B 16/78 Speaker, cellular phone 16/82 DVD player/control module V70...
  • Page 313 16/112 Outlet, rear right headphones P204_16-94_XC90 P204_16-112_XC90 16/105 Audio Module (AUD) 16/122 Rear Audio Separation module (RAS) P204_16-105_XC90 16-122 16/108 Multimedia Module (MMM) 16/123 External equipment input (AUX) P204_16-108_XC90 16-123 16/109 DVD player/control module 16/123.3RSE-AUX input 16-109 16-123.3 TP 39113202 V70/XC90 2008...
  • Page 314 PQRS WXYZ P204_16-126_XC90 16-145_XC90 16/127 Microphone, cellular phone hands- free, V70 16/149 MP3 player P204_16-127_V70 P204_16-149_V70 16/127 Microphone, cellular phone handsfree XC90 16/153 Satellite radio receiver antenna, V70 AM FM MY KEY POWER SOUND ENTER EXIT MENU PQRS WXYZ P204_16-127_XC90...
  • Page 315 Component illustrations 17/13 V70 - 17/38 XC90 USA 17/37 4-pin outlet, tow hitch cable harness 17/13 Data link connector, V70 4 3 2 1 P204_17-13_V70 P204_17-37_V70 17/37 4-pin outlet, tow hitch cable harness XC90 17/13 Data link connector, XC90 P204_17-13_XC90...
  • Page 316 Component illustrations 17/39 V70 - 20/16 17/39 13-pin outlet, tow hitch cable harness 17/42 USB-port P204_17-39_V70 17-42 17/39 13-pin outlet, tow hitch cable harness XC90 18/4 Contact reel V70 P204_17-39_XC90 P204_18-4_V70 17/40 External equipment input (AUX) 18/4 Contact reel XC90...
  • Page 317 Component illustrations 20/22 - 31/2 V70 20/22-26Glow plug 27/4 Right Camera Module (RCM) P204_20-22-26 P20485_27-4 20/46-53Spark plug with ignition coil, 8-Cyl. 27/6 Camera CYL 2 CYL 4 CYL 6 CYL 8 BANK 2 CYL 1 CYL 3 CYL 5 CYL 7...
  • Page 318 Ground connection, left MacPherson 31/10 Ground connection, right-hand side strut tower XC90 A-post, XC90 P204_31-2_XC90 P204_31-10_XC90 31/44 Ground connection, left-hand side mem- ber, lower engine compartment V70 31/4 Ground connection, engine P204_31-44_V70 P204_31-4 31/6 Ground connection, left-hand side A- 31/44 Ground connection, left-hand side mem-...
  • Page 319 Component illustrations 31/47 V70 - 31/67 XC90 31/47 Ground connection, rear left seat riser 31/53 Ground connection, firewall, XC90 P204_31-47_V70 P204_31-53_XC90 31/47 Ground connection, rear left seat riser 31/66 Ground connection, front left seat XC90 riser V70 P204_31-47_XC90 P204_31-66_V70 31/48 Ground connection, rear right seat...
  • Page 320 Component illustrations 31/70 V70 - 31/84 XC90 31/70 Ground connection, left-hand side mem- 31/73 Ground connection, rear right seat ber, lower engine compartment V70 riser XC90 P204_31-70_V70 P204_31-73_XC90 31/70 Ground connection, left-hand side mem- 31/83 Ground connection, left-hand side A-...
  • Page 321 P204_31-91 31/89 Ground connection, engine ignition 31/93 Ground connection, left MacPherson coils, group 2 strut tower V70 P204_31-89 P204_31-93_V70 31/89 Ground connection, engine ignition 31/93 Ground connection, left MacPherson coils, 6-cyl. strut tower XC90 31_89_6CYL P204_31-93_XC90 TP 39113202 V70/XC90 2008...
  • Page 322 Component illustrations 31/94 V70 - 31/100 31/94 Ground connection, right MacPher- 31/96 Ground connection, right MacPher- son strut tower V70 son strut tower XC90 P204_31-94_V70 P204_31-96_XC90 31/94 Ground connection, right MacPher- 31/98 Ground connection, upper windshield son strut tower XC90...
  • Page 323 Component illustrations 31/102 V70 - 54/3.1 XC90 31/102 Ground connection, front member, 54/1B Connector V70 P204_31-102_V70 54-1B_V70_89 31/102 Ground connection, front member, XC90 54/1B Connector XC90 P204_31-102_XC90 54-1B_XC90_89 31/120 Ground connection, cargo compart- ment V70 54/1C Connector 54-1C_89 P204_31-120_V70 31/120 Ground connection, cargo compart- ment XC90 54/3.1 Connector V70...
  • Page 324 Component illustrations 54/3.2 V70 - 54/10 XC90 54/3.2 Connector V70 54/8 Connector XC90 P205_54-8_XC90 P205_54-3.2 54/3.2 Connector XC90 54/9 Connector V70 P205_54-9 P205_54-3.2_XC90 54/4 Connector 54/9 Connector XC90 P205_54-9_XC90 P205_54-4 54/7 Connector 54/10 Connector V70 P205_54-7 54-10_V70_89 54/8 Connector V70...
  • Page 325 Component illustrations 54/11 V70 - 54/21 54/11 Connector V70 54/13 Connector XC90 54-11_V70_89 54-13_XC90_89 54/11 Connector XC90 54/14 Connector P205_54-11_XC90 P205_54-14 54/12 Connector V70 54/16 Connector P205_54-12 P204_54-16 54/12 Connector XC90 54/20 Connector 54-12_XC90_89 P204_54-20 54/13 Connector V70 54/21 Connector...
  • Page 326 Component illustrations 54/22 V70 - 54/36 V70 54/22 Connector V70 54/25 Connector 54-22_V70_89 P204_54-25 54/22 Connector XC90 54/32 Connector 54-22_XC90 P204_54-32 54/23 Connector V70 54/34 Connector P204_54-34 54-23_V70_89 54/23 Connector XC90 54/35 Connector 54-23_XC90 P204_54-35 54/24 Connector 54/36 Connector V70...
  • Page 327 Component illustrations 54/36 - 54/50 V70 54/36 Connector XC90 54/40D Connector V70 54-36_XC90 54-40D_V70 54/39 Connector 54/40D Connector XC90 54-39_V70 54-40D_XC90 54/40B Connector 54/43 Connector 54-40B_XC90 P204_54-43 54/40C Connector V70 54/43B Connector 54-40C_V70 P204_54-43B_XC90 54/40C Connector XC90 54/50 Connector V70...
  • Page 328 54/50 XC90 - 54/66.1 54/50 Connector XC90 54/56 Connector V70 P204_54-50_XC90 P205_54-56 54/53 Connector 54/56 Connector XC90 P205_54-53 54-56_XC90_89 54/54 Connector 54/57.1Connector V70 P204_54-54 54-57.1_V70_89 54/55 Connector V70 54/57.1Connector XC90 P205_54-55 54-57.1_XC90_89 54/55 Connector XC90 54/66.1Connector 54-55_XC90_89 P204_54-66.1_XC90 TP 39113202 V70/XC90 2008...
  • Page 329 Component illustrations 54/66.2 - 54/122 54/66.2Connector 54/107 Connector P204_54-66.2_XC90 P204_54-107 54/74 Connector 54/112 Connector P205_54-74 P204_54-112_XC90 54/98 Connector 54/113 Connector P204_54-98_XC90 P204_54-113_XC90 54/100 Connector 54/117 Connector 54-100_89 P204_54-117_XC90 54/106 Connector 54/122 Connector P204_54-106_V70 P204_54-122_XC90 TP 39113202 V70/XC90 2008...
  • Page 330 Component illustrations 54/132 V70 - 54/276 54/132 Connector V70 54/139 Connector P205_54-132 54-139_XC90 54/132 Connector XC90 54/140 Connector 54-132_XC90_89 54-140_XC90 54/134 Connector 54/274 Connector 54-134_XC90 54-274_V70 54/134.2Connector 54/275 Connector 54-134.2 54-275_V70 54/137AConnector 54/276 Connector 3 2 1 54-137A_V70 54-276 TP 39113202 V70/XC90 2008...
  • Page 331 54/277 - 54/1400 XC90 54/277 Connector 54/1401Connector V70 54-277 54-1401_V70 54/1300 Connector V70 54/1401Connector XC90 54-1401_XC90 P204_54-1300 _V70 54/1300 Connector XC90 54/1402Connector V70 54-1402_V70 P204_54-1300 _XC90 54/1400 Connector V70 54/1402Connector XC90 P204_54-1400_V70 54-1402_XC90 54/1400 Connector XC90 P204_54-1400_XC90 TP 39113202 V70/XC90 2008...
  • Page 332 16X/45 Connector interface, original car 16X/57 Connector interface, original car 16X/58 Connector interface, original car 16X/105 Connector interface, original car 16X/108 Connector interface, original car 17X/40 Connector interface, original car 54X/no. Connector interface, original car Connecting rail to 15/31 TP 39113202 V70/XC90 2008...
  • Page 333: Index 1:2

    Data communication high speed CAN ......52 Heated seats ............. 172 Data communication LIN ..........56 High and low beams (Bi-Xenon) XC90 ......84 Data communication low speed CAN V70 .... 54 High and low beams V70 ..........83 TP 39113202 V70/XC90 2008...
  • Page 334: Table Of Contents

    Starting system, Group 33 ........81 Steering, Group 64 ............ 160 Other, Group 39 ............125 Subwoofer ............141 Supplemental Restraint System module (SRS) V70 . 184 Supplemental Restraint System module (SRS) XC90 Parking assistance ............ 108 Parking camera ............151 Parking heater ............
  • Page 335: List Of Components 1:10

    Steering Wheel Switch Left (SWSL) XC90 3/82 Switch, central locking, right XC90 Switch, hazard warning flashers 3/85 Power window switch, left rear door V70 Switch, heated rear window/exterior rearview 3/85 Power window switch, left rear door XC90 mirrors V70 3/86...
  • Page 336 Passenger/Driver Door Module 4/50 Electronic Throttle Module (ETM) (PDM)/(DDM), XC90 4/52 Power Seat Module (PSM) 3/131 Steering Wheel Switch Right (SWSR) V70 4/56 Central Electronic Module (CEM) 3/131 Steering Wheel Switch Right (SWSR) XC90 4/58 Rear Electronic Module (REM), V70...
  • Page 337 6/25 Starter motor V70 6/76 Climate control system, rear 6/25 Starter motor XC90 6/92 Rear left power window motor, V70 6/26 Alternator Control Module (ACM) V70 6/92 Rear left power window motor, XC90 6/26 Alternator Control Module (ACM) XC90 6/93...
  • Page 338 Oil pressure monitor V70 7/73 Coolant level sensor XC90 Oil pressure monitor XC90 7/74 Fluid temperature sensor, automatic trans- Pressure sensor, climate control system V70 mission AW51 Pressure sensor, climate control system 7/74 Fluid temperature sensor, automatic trans- XC90 mission TF-80SC...
  • Page 339 Igniter, passenger side airbag V70 7/172 Position sensor camshaft, intake side 8/31 Igniter, passenger side airbag XC90 5-Cyl. 8/32 Igniter, airbag stage 2, passenger side V70 7/172 Position sensor camshaft, intake side 8/32 Igniter passenger side airbag stage 2, XC90 6-Cyl. 8/33...
  • Page 340 8/146- 8/61 Igniter, airbag stage 2, driver’s side 8/153 Injection valves, 8-Cyl. 8/62 Belt tensioner igniter, center rear seat V70 8/62 Belt tensioner igniter, center rear XC90 Outlet 12V front V70 8/64 Solenoid valve, engine pad, Diesel V70 Outlet 12V front XC90...
  • Page 341 Left brake light XC90 11E/no. Main fuses at the battery XC90 10/51 Tail light 1, left, V70 11L/no. Fuse in fuse holder cargo compartment V70 10/51 Tail light 1 left XC90 11L/no. Fuse in fuse holder cargo compartment V90 10/52 Tail light 2, left 11M/no.
  • Page 342 GPS antenna, cellular phone V70 17/19 12V outlet, cargo compartment XC90 16/63 GPS antenna, cellular phone XC90 17/37 4-pin outlet, tow hitch cable harness V70 16/64 Cellular phone antenna V70 17/37 4-pin outlet, tow hitch cable harness XC90 16/64 Cellular phone antenna XC90...
  • Page 343 Ground connection, left-hand side member, tower XC90 lower engine compartment XC90 31/94 Ground connection, right MacPherson strut 31/46 Ground connection, rear left seat riser V70 tower V70 31/46 Ground connection, rear left seat riser XC90 31/94 Ground connection, right MacPherson strut...
  • Page 344 Connector XC90 16X/105 Connector interface, original car 54/53 Connector 16X/108 Connector interface, original car 54/54 Connector 17X/40 Connector interface, original car 54/55 Connector V70 54X/no. Connector interface, original car 54/55 Connector XC90 Connecting rail to 15/31 TP 39113202 V70/XC90 2008...

This manual is also suitable for:

Xc902008 v702008 xc90

Table of Contents

Save PDF
