Connecting Network and Power Sources

Note
There are two ways to connect your phone to the network and a power source.
Your system administrator can tell you which of the following methods best
suits your teleconferencing needs:
• Power over Ethernet (PoE)
• AC Power

Power over Ethernet

Power over Ethernet is the default connection for your phone.
AC power adapters are not included in the PoE package. If you require one, see
your system administrator.
The following figure shows how to connect your phone to the network using
a PoE source.
1
To connect the phone using a PoE source:
1. Connect one end of the 25-foot Network Cable to the LAN jack on the
phone.
2. Connect the other end of the 25-foot Network Cable to an available LAN
port on the wall or hub/switch device port.
Getting Started with Your Phone
2
25-foot Network Cable
1 - 3
