PARTS PROVIDED

Locate the parts packed with the hood.

CHECK INSTALLATION HARDWARE

Count screws/
components. Screws
shown actual size.
6 wood
screws for
hood liner
8 wood
screws for
insert
sleeve
2 wing nuts
with lock
washers for
blower motor
REMOTE MOUNTING OF THE CONTROL (WIRED)
Blanking plate for
remote control
opening*
*NOTE: To be used
on custom hood
when controls are
remotely mounted.
30 ft. of 4-wire cord
(straight-pinned)
with connector/converter
NOTE: Not for
telecommunications
(telephone) network.
Installation Preparation
5 nuts for damper plate
assembly
(not located in hardware
bag–you must save nuts
when you remove damper
plate from inset hood
while unpacking parts)
6 insert sleeve chassis
plugs, 1 (optional) house
wire hole plug, 2 rubber
grommets, 4 insert sleeve
washers
Control wall bracket
Control Control
mounting mounting
plate bracket
Connector/
Converter
2 wall
2 mounting plate
bracket
screws
screws
Hood liner (packed in
separate carton)
Insert sleeve
(30 and 36 Wide Models)
(42 and 48 Wide Models)
12
Filters
Blower motor
Dual blower motor
Damper plate
