Table Of Contents - Compuprint 10200 User Manual

Compuprint Products Information ....................... ii
FCC Notes.............................................................. iii
Canadian D.O.C. Radio Interference Regulation iii
EEC Regulations ................................................... iii
Table of Contents.................................................. iv
Getting to Know Your Printer ............................... 1
Printer Features .................................................................... 1
Unpacking Your Printer ........................................................ 2
Removal of the Shipment Locks.......................................... 6
Connecting the Ground Cable ............................................. 8
Printer Parts .......................................................................... 9
Front View ........................................................................ 9
Rear View .......................................................................10
Left Side View ................................................................11
Inside View .....................................................................11
Setting Up Your Printer ....................................... 12
Choosing a Suitable Location ............................................12
Ribbon Cartridge Installation..............................................13
Front2 Push Tractor Installation.........................................18
Removing the Front2 Push Tractor ...............................21
Host Computer Connection................................................22
Software Driver Selection...................................................23
Power Connection ..............................................................24
Selecting the Display Language ......................... 26
Configuring the Printer........................................ 27
Operator Panel Presentation .............................................27
Display Messages ..........................................................28
Indicators ........................................................................33
Function Keys .................................................................34
Printer Setups .....................................................................39
Entering the Printer Setups ............................................39
Moving within the Printer Setups ...................................39
T a b l e o f C o
T a b l e o f C o
Paper Handling................................................... 113
Printer Maintenance and Troubleshooting...... 129
Options ............................................................... 140
Printer Specifications ........................................ 141
n t e n t s
n t e n t s
Leaving the Printer Setups ............................................ 40
Power-On Configuration .................................................... 41
Entering the Power-On Configuration ........................... 41
Program Setup ................................................................... 79
Entering the Program Setup .......................................... 79
How to Select the Paper Path.......................................... 103
How to Use the Tear-Off Function................................... 104
Selection of the Paper Size ......................................... 104
Adjusting the Tear-Off Position ................................... 105
Selection of the Tear-Off Mode ................................... 106
How to Lock/Unlock the Printer Setups........................... 107
How to Handle the Paper Parking................................... 108
Paper Specifications ........................................................ 113
Fanfold Paper ............................................................... 113
Fanfold Paper Loading..................................................... 114
Loading Paper Using the Front1 Tractor .................... 114
Loading Paper Using the Front2 Tractor .................... 124
Cleaning the Printer.......................................................... 129
Replacing the Ribbon Cartridge ...................................... 130
Printing the Self Test ........................................................ 132
Error Handling................................................................... 133
Repacking the Printer for Shipment ................................ 136
LAN Interface Board......................................................... 140
Front2 Push Tractor ......................................................... 140
Printer Cabinet.................................................................. 140
