SISTF10xx-111-LR(T) Industrial Media Converter

Fiber cable and optic specifications

Fiber cable Cable physical characteristics must meet or exceed IEEE 802.3™ specifications.
characteristics
Parameter
Bit Error Rate:
Single mode fiber:
Multimode fiber:
Multimode fiber:
Fiber optic The following shows the fiber optic specification:
specifications
Fiber Cable
SISTF1011-111-LR(T)
Fiber-optic transmitter power:
Fiber-optic receiver sensitivity:
Link budget:
SISTF1013-111-LR(T)
Fiber-optic transmitter power:
Fiber-optic receiver sensitivity:
Link budget:
SISTF1014-111-LR(T)
Fiber-optic transmitter power:
Fiber-optic receiver sensitivity:
Link budget:
Note:
24-Hour Technical Support: 1-800-260-1312 International: 00-1-952-941-7600
The fiber optic transmitters on this device meet Class I Laser safety requirements per
IEC-825/CDRH standards and comply with 21CFR1040.10 and 21CFR1040.11.
Specification
-9
<10
9 µm
62.5/125 µm
100/140, 85/140, 50/125 µm
Specifications
1300 nm multimode
min: -20.0 dBm max: -14.0 dBm
min: -31.0 dBm max: 0.0 dBm
11.0dB
1300 nm multimode
min: -20.0 dBm max: -14.0 dBm
min: -30.0 dBm max: 0.0 dBm
11.0dB
1310 nm single mode
min: -15.0 dBm max: -8.0 dBm
min: -34.0 dBm max: 0.0 dBm
19.0 dB
Transition Networks
