Sun Microsystems Netra User Manual page 103

Table 13-1 Information for Modem Remote Host Connection (Continued)
Login String The UUCP-style chat script to log in to the remote PPP
server once the modem connection is established. Example:
\" in: LOGIN\r\c word: PASSWORD\r\c\"
Timeout (minutes) The time, in minutes, after which an idle connection is
terminated. Example: 5
Use Remote Host As Select this option if you want the remote host address to be
Default Route added to the route table as the default destination. This
default route is removed when the connection is terminated.
Serial Port Name The name of the serial port on the Netra server through
which to connect to the remote host. Choices: ports with
connected modems.
Connection Speed The bits-per-second speed at which the serial port on the
Netra server should communicate with the modem. (Use
38400 for maximum throughput.) Choices: 38400, 19200, and
9600
To Modify or Delete A Remote Host Connection
1. Select Network Connection Administration: Modem.
The Modem Administration page is displayed.
2. Select one of the following:
•
To modify an existing remote host connection, select Modify, and make the
changes in the form using Table 13-1.
•
To delete a remote host connection, select Delete; then confirm the delete
operation.
Modem Administration
13
13-3
