Classical IP Interface

To Configure a Classical IP Interface
1. Select Network Connection Administration: ATM.
The ATM Administration page is displayed with configuration information
for each port.
2. Select Configure a Classical IP interface for the required ATM port.
An administration page for the selected interface is displayed.
3. Enter the information in the form using Table 9-3.
Table 9-3
ARP Configuration
ARP Server Prefix
ARP Server Address
Remote Host Address
Host Address
Netmask
4. Restart the Netra server using System Administration: Restart and
Shutdown.
ATM Administration
Information for ATM Classical IP Interface
The server or client ARP configuration. Standalone allows
a back-to-back configuration.
Choices: Server, Client, Standalone
The 13-byte prefix of the ARP server switch. If the ARP
server is on the same switch as the Netra server, no entry is
required. If there is no entry in this field, the local switch
prefix is used.
•This field is required only when the ARP Configuration
field is set to Client.
The 7-byte local portion of the ATM address of the ARP
server. If there is no entry in this field, the default local
server is assumed. (There are also 256 addresses reserved by
Sun: SUNMACSEL0-255.)
•This field must remain blank if the ARP Configuration
field is set to Standalone.
The remote host address for the machine to which the Netra
server is connected. The remote host address and the host
address must be on the same subnet.
•This field is required only when the ARP Configuration
field is set to Standalone.
The host address for the network interface. This address
should be unique on the system.
The netmask address that determines the network with
which the host address is associated.
Example: 255.255.255.0
