MULTIQUIP MQ Power DCA25USIXF Operation And Parts Manual page 89

ENCLOSURE ASSY. (DCA25USI2XF ONLY)
NO. PART NO.
31 0016906016
32 0207006000
33 0019208020
34 M1443302203
34A M1493305104
35 M1443400103
35A M1493305204
36 0207006000
37 0019208020
38 M1445200303
39 M1445600204
40 0207306000
40A 0041206000
41 M9113000002
42 0021806016
42A 0030006000
43 M9112100404
44 M9112100604
45 0016908020
46 M1463001902
46A M1493505603
47 0019208020
48 M3310600004
49 0019208020
50 M1453200802
51 0016908020
52 M1455100003
52A M1493410104
53 M1453004903
53A M1493409904
53B M1495501004
54 M1455000803
54A M1495501204
54B M1495501304
54C M1495401404
55 M1453005003
55A M1493410004
56 M1455300403
56A M1495401204
56B M1495401404
57 0207006000
DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 89
DCA25USI2XF — ECLOSURE ASSY.
DCA-25USI2XF— ENCLOSURE ASSY. (CONTINUED)
PART NAME
HEX, HEAD BOLT
HEX, NUT
HEX, HEAD BOLT
REAR COVER
ACOUSTIC SHEET
DUCT
ACOUSTIC SHEET
HEX, NUT
HEX, HEAD BOLT
REAR DOOR
WINDOW PLATE
HEX, NUT
WASHER, FLAT
DOOR HANDLE ASSY.
MACHINE SCREW
HEX, NUT
HINGE
HINGE
HEX, HEAD BOLT
ROOF PANEL
ACOUSTIC SHEET
HEX, HEAD BOLT
COVER
HEX, HEAD BOLT
SPLASHER PANEL
HEX, HEAD BOLT
SIDE PANEL
ACOUSTIC SHEET
SIDE DOOR
ACOUSTIC SHEET
ACOUSTIC SHEET
SIDE DOOR
ACOUSTIC SHEET
ACOUSTIC SHEET
ACOUSTIC SHEET
SIDE DOOR
ACOUSTIC SHEET
DUCT
ACOUSTIC SHEET
ACOUSTIC SHEET
HEX, NUT
QTY. REMARKS
1
2
4
1
1
1
1
7
6
1
1
10
10
1
4
4
2
2
8
1
1
23
1
4
1
4
1
1
1
1
1
1
1
1
1
1
1
1
3
1
6
1
