Refueling Procedure:
WARNING - RESPIRATORY HAZARDS
Diesel fuel and its vapors are dangerous
to your health and the surrounding
environment. Avoid skin contact and/or
inhaling fumes.
1. Level Tanks – Make sure fuel cells are level with the
ground. Failure to do so will cause fuel to spill from the
tank before reaching full capacity (Figure 32).
CAUTION - REFUELING THE GENERATOR
ALWAYS place trailer on firm level ground before refueling
to prevent spilling and maximize the amount of fuel that
can be pumped into the tank.
Figure 32. Only Fill on Level Ground
NOTICE
ONLY! use #2 diesel fuel when refueling.
PAGE 30 — DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11)
DCA-25USIXF/DCA-25USI2XF— SETUP
3. Open cabinet doors on the "right side" of the generator
(from generator control panel position). Remove fuel cap
and fill tank (Figure 33).
Figure 33. Fueling the Generator
3. NEVER overfill fuel tank – It is important to read the
fuel gauge when filling trailer fuel tank. DO NOT wait for
fuel to rise in filler neck (Figure 34).
Figure 34. Full Fuel Tank
CAUTION - REFUELING THE GENERATOR
DO NOT OVER-FILL fuel system. Leave room for fuel
expansion. Fuel expands when heated (Figure 35).
Figure 35. Fuel Expansion
