CONTROL BOX ASSY. (DCAUSI2XF ONLY)
NO. PART NO.
37 M1223000603
38 0601807641
39 0601808985
40 0601801040
41 0601806859
42 0601801041
43 0601840073
44 0601840121
45 0602103092
45A 0601810245
46 8970444180
46A 8944024980
47 0602103092
47A 0601810245
48 0602120095
49 0602122093
50 0602123090
51 0602121080
52 0602125090
53 9826800370
54 0601831330
55 0602103092
55A 0601810245
56 M1225100004
57 0027105010
58 0027105010
59 M9220100004
60 0080200007
61 0601851727
62 M1246703604
DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 61
DCA25USI2XF — CONTROL BOX ASSY.
PART NAME
CONTROL PANEL ...............................................1 .............
FREQUENCY METER, 45~65Hz 240V
AC AMMETER, 0~50A/100A:5A
CHANGE-OVER SWITCH, AMMETER
AC VOLTMETER, 0~600V
CHANGE-OVER SWITCH, AMMETER
RHEOSTAT(VR), 2W 1K OHM
KNOB
ALARM LAMP
BULB, DC18V
STARTER SWITCH .............................................1 ............. REPLACES P/N 0602100009
KEY, IGNITION SWITCH
PREHEAT LAMP
BULB, DC18V
TACHOMETER
OIL PRESSURE GAUGE
WATER TEMPERATURE GAUGE
CHARGING AMMETER
FUEL GAUGE
PANEL LIGHT ......................................................1 ............. REPLACES P/N 0601810141
SWITCH, PANEL LIGHT
ALARM LAMP
BULB, DC18V
STOPPER
MACHINE SCREW
MACHINE SCREW
SET SCREW
SNAP RING
GROMMET
WIRE HARNESS, GENERATOR
QTY. REMARKS
1
1
1
1
1
1
1
3
3
1
1
1
1
1
1
1
1
1
1
1
1
2
4
2
2
1
1
1
