OPTION MODULES

The NetVanta 1600 Series option module slots support two 10 Gbps uplink or stacking ports. They will support
several XAUI-compliant interface modules (XIMs) designed to meet a variety of stacking and networking
requirements. XIMs plug directly into the option module slots located on the rear of the base unit. The
NetVanta 1600 Series currently supports the following XIM:
• NetVanta Dual Stacking XIM (P/N 1700470F1) on page 26
• NetVanta Dual SFP+ XIM (P/N 1700471F1) on page 27
• NetVanta Dual SFP XIM (P/N 1700473F1) on page 28
This section describes the module, provides shipping contents, specifications, and features. Refer to
XAUI Interface Modules on page 33

XAUI Interface Module Shipping Contents

NetVanta Dual Stacking XIM (1700470F1)
Shipments of the NetVanta Dual Stacking XIM include the following items:
• Dual Stacking XIM
• Quick start guide
NetVanta Dual SFP+ XIM (1700471F1)
Shipments of the NetVanta Dual SFP+ XIM include the following items:
• Dual SFP+ XIM
• Quick start guide
NetVanta Dual SFP XIM (1700473F1)
Shipments of the NetVanta Dual SFP XIM include the following items:
• Dual SFP XIM
• Quick start guide
61700568F1-34D
for information on card installation.
