ADTRAN NETVANTA 1131 Quick Start Manual

N V 1131 R
ET ANTA
P/N 1700530F1, 1700532F1 (RPS C
G S
ETTING TARTED
The NetVanta 1131 RPS/EPS has three RPS outputs and one EPS output for use with RPS/EPS
equipped NetVanta switches. Important: Refer to the NetVanta 1131 product on
for a list of supported switches. The RPS outputs provide redundant or backup power for a
switch's internal power supply. The EPS output provides backup power for a Power over Ethernet
(PoE) switch's internal PoE supply, as well as extended or supplemental power to provide full
PoE for 48-port switches (up to 740 W of power).
The NetVanta 1131 does not activate RPS power until a failure is detected on the switch for which
it is providing redundancy. Once RPS power is being supplied to a switch, if a second switch fails,
the power will not transfer to the second switch. In the event that multiple connected switches
lose power simultaneously, RPS power will be supplied to the first failed switch detected.
The NetVanta 1131 is housed in a 1U-high, metal enclosure that can be wall mounted, rack
mounted singly using the rackmount brackets, or rack mounted two side by side using the
optional dual mounting tray (P/N 1700534F1).
R M
ACK OUNTING THE
The NetVanta 1131 can be installed into a 19-inch equipment rack by following these steps:
•
•
•
•
•
•
•
Quick Start Guide, 61700530F1-13D, April 2014
EDUNDANT
The NetVanta 1131 and the NetVanta switch with which it is associated
should be installed in a restricted access location as described in
UL 60950-1.
N V
ET ANTA
The NetVanta 1131 is intended to be installed, maintained, and serviced
by qualified service personnel only and is for use with NetVanta
switches only.
If installed in a closed or multi-unit rack assembly, the operating
ambient temperature of the rack environment may be greater than room
ambient temperature. Therefore, consideration should be given to
installing the equipment in an environment compatible with the
specified 50°C maximum ambient temperature.
Installation of the equipment in a rack should be such that the amount
of air flow required for safe operation of the equipment is not
compromised.
Be careful not to compromise the stability of the equipment mounting
rack when installing this product.
Consideration should be given to the connection of the equipment to the
supply circuit and the effect that overloading the circuit might have on
overcurrent protection and supply wiring. Appropriate consideration
of equipment nameplate ratings should be used when addressing this
concern.
Reliable grounding of rack-mounted equipment should be maintained.
Particular attention should be given to supply connections other than
direct connections to the branch circuit (e.g., use of power strips).
This equipment incorporates double pole/neutral fusing. If the neutral
fuse opens and the line fuse does not open, voltage could still be present
in the unit. Line and neutral are provided with fuses for overcurrent
protection.
/E
XTENDED
), 1700533F1 (EPS C
ABLE
1131
P S
OWER UPPLY
)
ABLE
www.adtran.com
