- Page 1 NetVanta 1230 Series Fast Ethernet Switch Hardware Installation Guide 1703594G1 NetVanta 1234 1703595G1 NetVanta 1234P 1702599G1 NetVanta 1238P 61702594G1-34D July 2014...
- Page 2 To the Holder of the Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
- Page 3 NetVanta 1230 Series Hardware Installation Guide Conventions Conventions Notes provide additional useful information. Cautions signify information that could prevent service interruption or damage to the equipment. Warnings provide information that could prevent injury or endangerment to human life. 61702594G1-34D Copyright © 2014 ADTRAN, Inc.
- Page 4 These units contain no user-serviceable parts. They should only be serviced by qualified service personnel. Additional safety guidelines, such as Waste Electrical and Electronic Equipment (WEEE), are given in the document NetVanta Safety and Regulatory Information available at https://supportforums.adtran.com. Save These Important Safety Instructions Copyright © 2014 ADTRAN, Inc. 61702594G1-34D...
- Page 5 Denial of Service (DoS) attacks, loss or theft of data, and the unauthorized or illegal use of said equipment. ADTRAN OFFERS NO WARRANTIES, EITHER EXPRESSED OR IMPLIED, REGARDING THE PREVENTION, DETECTION, OR DETERRENCE OF TOLL FRAUD, NETWORKING ATTACKS, OR UNAUTHORIZED, ILLEGAL, OR IMPROPER USE OF ADTRAN EQUIPMENT OR SOFTWARE.
- Page 6 Service and Warranty NetVanta 1230 Series Hardware Installation Guide Copyright © 2014 ADTRAN, Inc. 61702594G1-34D...
-
Page 7: Table Of Contents
Connector Pin Definitions..........27 61702594G1-34D Copyright © 2014 ADTRAN, Inc. - Page 8 Table of Contents NetVanta 1230 Series Hardware Installation Guide Copyright © 2014 ADTRAN, Inc. 61702594G1-34D...
- Page 9 NetVanta 1234P Front Panel Layout ........
- Page 10 List of Figures NetVanta 1230 Series Hardware Installation Guide Copyright © 2014 ADTRAN, Inc. 61702594G1-34D...
- Page 11 Table A-3. 1000Base-T Gigabit Ethernet Port Pinouts ........28 61702594G1-34D Copyright © 2014 ADTRAN, Inc.
- Page 12 List of Tables NetVanta 1230 Series Hardware Installation Guide Copyright © 2014 ADTRAN, Inc. 61702594G1-34D...
-
Page 13: Introduction
INTRODUCTION The NetVanta 1230 Series includes the NetVanta 1234, NetVanta 1234P Power over Ethernet (PoE), and NetVanta 1238P (PoE). In this document, the term NetVanta 1230 means all of the units collectively. If a statement only applies to one particular switch, the text refers to that switch individually. -
Page 14: Physical Descriptions
IEEE-compliant PDs. NetVanta 1230P Series PoE supports legacy PoE. The NetVanta 1230P Series units support a maximum of 15.4 W per port. The NetVanta 1234P can carry a full PoE load on all 24 ports. The NetVanta 1238P can supply up to 370 W PoE spread over 48 ports. -
Page 15: Figure 1. Netvanta 1234 Front Panel Layout
Ethernet (RJ-45) interfaces numbered G1 and G2 and share status LEDs. (Use either the RJ-45 connectors for up 100/1000 Mbps copper connectivity or the SFP slots for 1 Gbps fiber connectivity. The SFP slots have precedence.) Slots G3 and G4 provide fiber connectivity at 1 or 2.5 Gbps. 61702594G1-34D Copyright © 2014 ADTRAN, Inc. -
Page 16: Figure 2. Netvanta 1234 Rear Panel Layout
Supplying Power to the Unit on page 25 for connection details. NetVanta 1234P Front Panel Design The NetVanta 1234P front panel is shown below. Table 1 on page 20 describes all of the LEDs, and Appendix A on page 27 shows the connector pinouts. -
Page 17: Figure 4. Netvanta 1234P Rear Panel Layout
NetVanta 1234P Rear Panel Design The NetVanta 1234 rear panel is shown below. AC INPUT Figure 4. NetVanta 1234P Rear Panel Layout NetVanta 1234P Rear Panel Interfaces Power Connection The rear panel has a power input to the AC universal power supply. Please refer to... -
Page 18: Figure 5. Netvanta 1238P Front Panel Layout
Ethernet (RJ-45) interfaces numbered G1 and G2 and share status LEDs. (Use either the RJ-45 connectors for up 100/1000 Mbps copper connectivity or the SFP slots for 1 Gbps fiber connectivity. The SFP slots have precedence.) Slots G3 and G4 provide fiber connectivity at 1 or 2.5 Gbps. Copyright © 2014 ADTRAN, Inc. 61702594G1-34D... -
Page 19: Figure 6. Netvanta 1238P Rear Panel Layout
NetVanta 1238P Rear Panel Interfaces Power Connection The rear panel has a power input to the AC universal power supply. Please refer to Supplying Power to the Unit on page 25 for connection details. 61702594G1-34D Copyright © 2014 ADTRAN, Inc. -
Page 20: Table 1. Front Panel Led Descriptions
(1 - 24 NetVanta Green (solid) Powered device is connected. 1234P) (1 - 48 NetVanta Green (flashing) The port has detected a PoE fault. 1238P) Ports G1 through G4 are always in link/activity mode. Copyright © 2014 ADTRAN, Inc. 61702594G1-34D... -
Page 21: Product Specifications
Console Port: DB-9, female Environmental Specifications Storage Temperature: -20C to 70C Operating Temperature: 0C to 50C Relative Humidity: Up to 95 percent, noncondensing 61702594G1-34D Copyright © 2014 ADTRAN, Inc. -
Page 22: Unit Installation
ADTRAN unit to Ethernet cables that run outside the building, ADTRAN's Ethernet Port Protection Device (EPPD) (P/N 1700502G1) must be connected between the unit and the outside plant cable. Use of any Ethernet protector other than ADTRAN's for this purpose will void the user's warranty. -
Page 23: Mounting Options
Apply power to the unit (refer to Supplying Power to the Unit on page 25). To avoid damaging the unit, use only the screws included in the shipment when attaching mounting ears to the chassis. 61702594G1-34D Copyright © 2014 ADTRAN, Inc. - Page 24 Have an assistant hold the unit in position as you install two #6 to #10 (1 inch or greater in length) wood screws through the unit’s brackets and into the mounted board (see Figure 7 on page 25). Proceed to the steps given in Supplying Power to the Unit on page Copyright © 2014 ADTRAN, Inc. 61702594G1-34D...
-
Page 25: Supplying Power To The Unit
If you must use an extension cable, use a 3-wire cable with properly grounded plugs. After the NetVanta is powered on, the LED indicators will flash momentarily. This flashing represents a reset of the system. 61702594G1-34D Copyright © 2014 ADTRAN, Inc. - Page 26 ADTRAN Support Community. For details on the CLI, refer to the AOS Command Reference Guide. All other related documents are also available online at https://supportforums.adtran.com. Copyright © 2014 ADTRAN, Inc. 61702594G1-34D...
-
Page 27: Appendix A. Connector Pin Definitions
Unused Receive Negative 7, 8 — Unused Table A-2. SFP Slot Pinouts Name Name RX_LOS RGND RGND RX_DAT- RGND RX_DAT+ MOD_DEF(0) RGND MOD_DEF(1) VddR MOD_DEF(2) VddT TX_DISABLE TGND TGND TX_DAT+ TGND TX_DAT- TX_FAULT TGND 61702594G1-34D Copyright © 2014 ADTRAN, Inc. -
Page 28: Table A-3. 1000Base-T Gigabit Ethernet Port Pinouts
NetVanta 1230 Series Hardware Installation Guide Table A-3. 1000Base-T Gigabit Ethernet Port Pinouts Name Description TRD0+ Transmit/Receive Positive TRD0- Transmit/Receive Negative TRD1+ Transmit/Receive Positive TRD2+ Transmit/Receive Positive TRD2- Transmit/Receive Negative TRD1- Transmit/Receive Negative TRD3+ Transmit/Receive Positive TRD3- Transmit/Receive Negative Copyright © 2014 ADTRAN, Inc. 61702594G1-34D...
