Library Operation
Removing Tape Cartridges from the Library
5. Unlock the access door using the key, then open the door.
NOTE
Do not let the door fall open. Damage to the door straps may occur.
Figure 4-6 Opening the Front Access Door
6. Remove the desired magazine by pushing the button at the top of the
Figure 4-7 Removing Magazines
7. If necessary, remove tapes from the magazine. Press the button on top of
4-18
magazine handle (see Figure 4-7) and pulling out the magazine.
the magazine, then pull out the tape.
