Library Rear Panel Features

Library Rear Panel Features
Figure 1-2 Rear Panel Features
1. Bus 1 SCSI ports (single-ended and differential). Drive 1 and the
2. SCSI interface mode switches specify term power, termination and
3. Bus 2 SCSI ports (single-ended and differential). Drive 2 is internally
4. SCSI bus status indicator label explains the SCSI bus status
5. Power connector connects the power cord to the library.
6. SCSI bus indicators indicate SCSI bus status. Each SCSI bus has an
1-6
6
5
5
4
robotics controller are internally connected to Bus 1.
differential settings for each SCSI bus.
connected to Bus 2 (two-drive library only)
indicators.
indicator.
1
2
3
