Figure 2-3 Front Access Door - HP Surestore Tape Library Model 2/15 User Manual

2. Extend the rack's antitip rail and verify that the leveller feet are down.
WARNING
Failure to extend the antitip rail could result in personal injury
and/or damage to the library if the rack tips over.
3. Use the key to open the front access door. Remove the two screws that
Figure 2-3 Front Access Door
4. Slide the library out of the rack so that it is in the fully extended position.
5. Gently pull the SCSI and power cables back toward the rear of the rack.
secure the library to the rack.
Use a cable tie to secure them to the rail at the back of the rack. The cable
tie should be at about the same height as the top of the library.
Library Installation
Step 6: Connect Library to Host
2-11
