Step 6: Connect Library to Host

1. Ensure the host system has been properly shut down and powered off.
2. Connect the SCSI cables.
The SCSI bus configuration was determined when the SCSI interface
mode switch was set (see the connection diagram on page 2-8). Using this
configuration, connect the library to the host. Make sure:
• The differential port is used.
• The last device in the SCSI bus is terminated.
3. Make sure the power switch on the library front panel is switched off (0
position).
4. Plug the power cord into the power port on the back of the library.
Stand-alone installations: Go to "Step 7: Connect Power" on page 2-13.
Rack mount installations: Go to the next section, "Routing SCSI and Power
Cables on Rack Mounted Libraries."
