2.3
Introducing LANCOM router
This section introduces your device. We will give you an overview of all status
displays, connections and switches.
2.3.1
Status displays
The front panel of the unit feature a series of light emitting diodes (LEDs) that
provide information on the status of the device. On the LANCOM 8011 VPN a
two-lined display additionally shows information on the status.
Front side
The various LANCOM router models have different numbers of indicators on
the front panel depending on their functionality.
LANCOM 8011 VPN
Meanings of the LEDs
In the following sections we will use different terms to describe the behaviour
of the LEDs:
Operating system that supports TCP/IP, e.g. Windows XP, Windows Mil-
lennium Edition (Me), Windows 2000, Windows 98, Windows 95, Win-
dows NT, Linux, BSD Unix, Apple Mac OS, OS/2, BeOS.
Access to the LAN via the TCP/IP protocol.
The LANtools and the LANCAPI functions also require a Windows
operating system. A web browser is required for access to WEBconfig.
While the information in this section is useful for the installation of the
device, it is not absolutely essential. You may therefore skip this sec-
tion for the time being and go straight forward to 'Hardware installa-
tion' →page 24.
Blinking means, that the LED is switched on or off at regular intervals in
the respective indicated colour.
LANCOM 7111 VPN – LANCOM 8011 VPN
ETH4
LANCOM 8011 VPN
Firmware 3.40
Chapter 2: Installation
ETH3
ETH2
ETH1
WAN
ISDN
COM
19
L
