Lancom 7111 VPN Manual page 20

LANCOM 7111 VPN – LANCOM 8011 VPN
Chapter 2: Installation
Power This LED indicates that the device is operational. After the device has been
switched on, it will flash green for the duration of the self-test. After the self-
test, either an error is output by a flashing red light code or the device starts
and the LED remains lit green.
off
green
green
red/
green
red
Online The Online LED indicates the overall status of all WAN ports:
off
green
green
green
red
20
Flashing means, that the LED lights up very briefly in the respective col-
our and stay then clearly longer (approximately 10x longer) switched off.
Inverse flashing means the opposite. The LED lights permanently in the
respective colour and is only briefly interrupted.
Flickering means, that the LED is switched on and off in irregular inter-
vals.
blinking
constantly on
blinking alternately
blinking
The power LED flashes red/green in alternation until a configuration
password has been specified. Without a configuration password, the
configuration data of the LANCOM is insecure. Under normal circum-
stances, you would assign a configuration password during the basic
configuration (see instructions in the following chapter). For informa-
tion about a later assignment of the configuration password see the
section 'Security settings' →page 62.
flashing
inverse flashing
constantly on
constantly on
Device off
Self-test when powering up
Device ready for use
Device insecure: configuration password not assigned
Time or connect-charge reached
No active connection
Establishing first connection
Establishing further connection
At least one connection established
Error establishing the previous connection
