LANCOM 800+ – LANCOM DSL/I- 10+ – LANCOM DSL/I- 1611 Office
The LANtools and the LANCAPI functions also require a Windows
operating system. A web browser is required for access to WEBconfig.
2.3

Introducing the LANCOM router

This section introduces your device. We will give you an overview of all status
displays, connections and switches.
While the information in this section is useful for the installation of the
device, it is not absolutely essential. You may therefore skip this sec-
tion for the time being and go straight forward to 'Hardware installa-
tion' →page 28.
2.3.1

Status displays

The front and the rear panels (LANCOM DSL/I-10+) of the unit feature a series
The various LANCOM router models have different numbers of indicators on
the front panel depending on their functionality.
Meanings of the LEDs
In the following sections we will use different terms to describe the behaviour
of the LEDs:
Blinking means, that the LED is switched on or off at regular intervals in
the respective indicated colour.
Flashing means, that the LED lights up very briefly in the respective col-
our and stay then clearly longer (approximately 10x longer) switched off.
Inverse flashing means the opposite. The LED lights permanently in the
respective colour and is only briefly interrupted.
Flickering means, that the LED is switched on and off in irregular inter-
vals.
Chapter 2: Installation
21
