LAN – connect the LANCOM router to your LAN or to an individual PC. For
that purpose, plug the included network cable (green plugs) into the LAN
connector of the device
ing socket of your local network, into a free socket of a hub/switch or into
the network socket of an individual PC.
The LAN connector identifies automatically the transfer rate (10/100
Mbps) of the connected network device (autosensing). A parallel connec-
tion of devices with different speeds and types is possible.
You should never have more than one unconfigured LANCOM router
in a network segment at any given time. All unconfigured LANCOM
router devices use the same IP address (with the final digits '254'),
which would result in an address conflict. To avoid problems, always
configure multiple LANCOM router devices one at a time, immediately
assigning each device a unique IP address (one that does not end with
'254').
WAN – connect the WAN port
blue plug) e. g. with the ethernet port of a DSL modem or of a cable
modem.
ISDN – to connect the LANCOM router to the ISDN, plug one end of the
supplied ISDN connector cable (light blue plugs) in the ISDN/S
the router and the other end into an ISDN/S
to-point mode connection.
Configuration port – you may optionally connect the router directly to
the serial port (RS-232, V.24) of a PC. Use the cable supplied for this pur-
pose. Connect the configuration port of the LANCOM
port of the PC.
Connect to power – Connect socket
using the included power adapter and switch it on
With the LANCOM 7111 VPN only use the included power supply unit!
Using an unsuitable power supply unit may cause damage or injury.
Operational? – After a short device self-test the Power LED will be per-
manently lit. Green LAN LEDs indicate the LAN sockets that have function-
ing connections.
LANCOM 7111 VPN – LANCOM 8011 VPN
and the other end into a free network connect-
with the included connector cable (dark
multi-device mode or point-
0
of the unit to a power supply
Chapter 2: Installation
port of
0
with a free serial
.
