ISDN Chan 1 Data traffic on the ISDN B channels (separate per B channel with LANCOM
ISDN Chan 2
7111 VPN, for both ISDN B channels with LANCOM 8011 VPN):
off
green
green
green
green
green
COM Connection status of the serial configuration port:
(only LANCOM
8011 VPN)
off
green
green
LCD display
Only LANCOM The LCD display of the LANCOM 8011 VPN shows the following information
8011 VPN
in two lines with 16 characters in revolving alternation:
reactivated as required, and the ISDN status LED will once again light
up green.
blinking
flashing
inverse flashing
constantly on
flickering
constantly on
flickering
Device name
Firmware version
Temperature
Date and time
CPU usage
Memory usage
Number of VPN channels
Data transfer downstream
Data transfer upstream
LANCOM 7111 VPN – LANCOM 8011 VPN
No connection established
Dialling
Establishing first connection
Establishing further connection (only if B channel 1 and B
channel 2 share display)
Connection established via B channel
Data traffic (send or receive)
No session logged in
Serial configuration session logged in
Data transmission on serial configuration session
