Door Hinge Receivers

To remove the door hinge receivers:
1. Remove the side access panels. (See
)
Panels.
2. Carefully lift the insulation from the outside of
the oven.
3. Remove the two T20 Torx screws that hold each
hinge receiver to the oven frame.
4. Push the hinge receiver through the opening in
the oven frame and remove from the rear.
Note: Upon reassembly, ensure the displaced
insulation around the oven and components is
returned to its original position.

Meat Probe and Outlet

The meat probe outlet is located on the top of the
oven cavity, near the front. The meat probe outlet is
connected to the electronic oven control. The meat
probe has a resistance value of 30K-50K Ω at room
temperature.
To remove the meat probe outlet:
1. Open the lower oven door.
2. Remove the two 1/4-in. hex-head screws that
attach the meat probe outlet to the top of the
oven cavity.
3. Pull the outlet and wiring down from the oven
wall.
Note: When replacing the meat probe outlet, cut
the probe wires and splice the new probe using
Side Access
approved heat-resistant connectors.

Oven Light Assembly

The oven has two light assemblies in each oven
cavity. The light assemblies are located on the top
rear of the oven. The lights come on when the door
is opened or when the oven is in a cooking cycle.
The oven lights do not come on during self-cleaning
or if the Sabbath Feature is set.
Each light assembly consists of a removable light
cover, a light bulb socket, and a light bulb.
To remove an oven light assembly:
1. Remove the main rear access panel. (See
Access Panels
2. Remove the three 1/4-in. hex-head screws that
attach the panel securing the lighting assembly
wires to the rear of the oven.
– 42 –
Cut Here
Cut Here
.)
(Continued Next Page)
