5. Remove the thirteen 1/4-in. hex-head screws
from the top of the heat shield.
6. Lift up the top heat shield.

Oven Temperature Sensor

The resistance of the temperature sensor is:
Ω at room temperature
• 1080
Ω at clean temperature
• 2650
To remove the oven temperature sensor:
1. Remove the main rear access panel. (See
.)
Access Panels
2. Remove the two 1/4-in. hex-head screws that
attach the sensor to the broiler element bracket.
3. Disconnect the sensor wiring harness from the
back of the oven.
4. Carefully pull the sensor and sensor wiring
Note: When reinstalling the sensor, use a small flat-
bladed screwdriver to push and guide the sensor
wire harness into the oven liner.
1 of 13
Broil Element
The broil element will not work if the temperature
probe is plugged in. The broil element terminals are
located behind the main rear access panel.
The broil elements are rated at:
•
Rear
•
•
•
To remove the broil element:
1.
IMPORTANT: The lower wattage elements use
3/16-in. terminal connections. The higher wattage
elements use 1/4-in. terminal connections.
2. Disconnect the wires from the broil element.
Disconnect
3. Remove the two 1/4-in. hex-head screws that
– 35 –
harness from the oven liner.
Upper oven broil element (inner) - 1700 watts
Upper oven broil element (outer) - 1050 watts
Lower oven broil element (inner) - 2200 watts
Lower oven broil element (outer) - 750 watts
Remove the main rear access panel. (See
)
Access Panels.
attach the temperature sensor to the broiler
element bracket.
Rear
(Continued next page)
